TEMPLE & WEBSTER AAACDBCR Assembly Instructions

Read these instructions and follow steps carefully to ensure you assemble
the product correctly and avoid damages.Check that all parts and
hardware have been provided before assembling the product.Place all
contents on a clean, soft-flat surface to avoid scratching the produc
△
CAUTION:
!
Only tighten bolts to 80% at first.Once all parts have been assembled fully tighten all hardware
To prevent damage to threads ,do not use a power tool and do not overtighten bolts.
Use two people to lift and turn the product when assembling.
Do not attempt with only one person and do not roll on to legs.
Keep all hardware and small parts away from children.
ASSEMBLY INSTRUCTIONS
AAACDBCR/AAACKBCR/AAACQBCR/AAACQBGY
PART LIST
ITEM DESCRIPION
t
A HEADBOARD
B SIDE RAIL
C FOOTBOARD
D CENTRE RAIL
E BED LEG
F SUPPORT LEGS
G SLATS
HARDWARE LIST
QTY
ITE M DESCRIPION
1PC
1
JCBC SCREW M8*30MM
2PCS
2
FELT
1PC
3
JCBC SCREW M6*20MM
1PC
4
BRACKET
4PC S
5
PAN HEAD WOOD SCREW M4*16MM
2PCS
6
PAN HEAD WOOD SCREW M4*30MM
2PCS
7
POTHOOK
8 JCBC SCREW M6*15MM
9 M5 ALLEN KEY(BALL SHAPE)LONG
QTY
16PCS
4PCS
4PCS
4PCS
4PCS
20PCS
2PCS
2PCS
1PC
