Phone Configuration
Language Settings
The default language of the phone is English. It supports several kinds of languages, users can
choose a prefer one to use.
Click Control->Phone Set->Language->OK to pop up the pull-down menu, press Up/Down
navigation keys to choose the language, then press【OK】to confirm the change.
Configuring via Web Page
Press【OK】button on the keypad of the phone to enter the Device Status page and find out the
IP address of the IP video phone. Enter it (for example http://192.168.3.35) into the address bar
of web browser.
The default login name and password are admin/admin.
Note: Please locate your PC in the same network segment of the IP phone(192.168.3.X) to access the web
configuration page. Please consult your network administrator or service provider for help.
Network Settings:
Choose Network - > WAN
DHCP(Obtain an IP Address Automatically): By default the phone attempts to contact a DHCP
Server in your network in order to obtain its valid network settings, e.g. IP address, sub mask,
gateway, DNS server, etc.
PPPoE(Behind xDSL Modem): If you are using the xDSL Modem, you can connect your phone
to the internet via PPPoE mode. Please contact your ISP for the User Name and Password for
internet access.
Static IP(Use the Following IP Address): If your phone cannot contact a DHCP Server for any
reason, you need to enter the network settings manually via Static IP Address. Please contact
your internet administrator for more details.
Note: Using the wrong network parameters may result in inaccessibility of your phone and may also have
an impact on your network performance! Please contact your network administrator!
Account Setting:
Choose Account - > Account
Parameter:
Phone Number:
Provided by users' ISP.
Account Name:
User account information, provided by VoIP service provider.vely.
Password:
The password for the account, It is provided by ISP for registration.
Server:
Server for registration, provided by ISP.
Port:
The port of SIP Server, 5060 by default.
Note: Please contact your service provider for more account details.
Configuring via Keypad
Network Setting: Click Control -> Advanced -> WAN. Then input the password to enter the
internet relating configuration page. The default password is 123.
Account Setting: Click Control -> Advanced ->Account. Then input the password to enter and
configure the account settings. The default password is 123.
You can refer to the above "Configuring via Web Page" for the parameter details.
Configuring the phone
IP Video Phone
Quick Installation
