Yale Z-Wave Plus v2 Installation Instructions

Smart Module Installation
Z-Wave Plus
Models: YRD410, YRD420, YRD430, YRD450, YRD420-F, YRD450-F
NOTE: Anytime you add or remove a Smart Module from your lock, the batteries must be removed.
1
If your lock is already installed,
remove the batteries.
Smart Module Installation
Z-Wave Plus
Models: YRD216, YRD226, YRD256, YRL226, YRL216
1
If your lock is already installed,
remove the batteries.
We're here to help, 24/7 1-855-213-5841
v2 Assure Lock
™
2
Insert the Yale Z-Wave Plus™ v2
Smart Module into the battery
compartment slot.
Reinsert the batteries.
v2 Assure Lock
™
2
Insert the Yale Z-Wave Plus™ v2
Smart Module into the battery
compartment slot.
Reinsert the batteries.
support@yalelock.com
2
®
3
Open the Yale Access App and
navigate to your lock model.
3a. Select 'Lock Settings'.
3b. Select 'Yale Smart Module'.
3c. Follow steps in the app
to complete set-up.
®
3
If you have SmartStart enabled
with your Z-Wave™ system,
follow in-app prompts to add a
new device. If you do not have
SmartStart or are not sure,
follow the steps below.
3a. Enter your locks master entry
code, followed by the
7
3b. Press the key followed by
the
1
3c. Press the key followed by
the
support.shopyalehome.com
If prompted,
scan QR code
4
To remove the Yale Z-Wave Plus™ v2
smart module from your system,
select the disconnect Z-Wave™
option from lock settings
in the Yale Access App.
Anytime you add or remove a
Smart Module from your lock,
the batteries must be removed
4
To remove the Z-Wave Plus™ v2
Smart Module from your system,
open the smart home
or alarm app and follow the
instructions for removing a device.
4a. Enter your locks master entry
code, followed by the
7
4b. Press the key followed by the
1
4c. Press the key followed by the
Anytime you add or remove a
Smart Module from your lock,
the batteries must be removed
ISL-0000-00-000
AYR-MOD-ZW3-4-MNL-0050
