INSTRUCTION
MANUAL
Gas Detector
DEGA NS III LCD
Reproduc�on of this manual, or any part thereof, in any form, without the prior permission of DEGA.CZ s.r.o. is
prohibited
DEGA CZ s.r.o. reserves the right to alter the specifica�ons of the hardware and so�ware described in this
manual at any �me and without prior no�ce
DEGA CZ s.r.o. bears no liable for any damage resul�ng from use of this device

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS III LCD and is the answer not in the manual?

Questions and answers

Related Manuals for DEGA NS III LCD

Summary of Contents for DEGA NS III LCD

  • Page 1 Gas Detector DEGA NS III LCD Reproduc�on of this manual, or any part thereof, in any form, without the prior permission of DEGA.CZ s.r.o. is prohibited DEGA CZ s.r.o. reserves the right to alter the specifica�ons of the hardware and so�ware described in this manual at any �me and without prior no�ce...

  • Page 2: Table Of Contents

    Replacement of the sensor module............................. 7 Replacement of the ba�ery..............................7 Connec�ng the detector via current loop to the controler DEGA UPA II/DEGA UPA III............7 Connec�ng the sensor via RS485 to the controller DEGA UKAIII/DEGA UPA III ..............7 Installa�on of wiring for RS485 ............................

  • Page 3: Technical Data And Informa�On

    Use the detector only with the appropriate cer�fied DEGA products The device is cer�fied as func�onally and technically qualified only with original "DEGA" accessories. In case of using the device with any other products the manufacturer is not liable for any damages that may occur.

  • Page 4: Opera�Onal Condi�Ons

    Flow of ambient air: max. 2 m/s - flow directly to the sensor in not allowed Protec�on level with a cover: IP 54, with a DEGA WATER CAP IP 66 cover Loca�on: BE3N2 - explosive atmoshpheres - zone 1 (2 G)

  • Page 5: Product Descrip�On

    Their disadvatage is their low selec�vity - the sensor largly responds to other gases for which it is not calibrated. DEGA NSx-PL III LCD PID with a photoioniza�on sensor (PID) The sensi�ve scanning method for detec�on of a wide range of VOC - vola�le organic compounds. The sensor does not selec�vely detect all VOCs in the air at concentra�ons in ppm.

  • Page 6: Instala�On, Assembly And Disassembly Of The Detector

    Jumper connector of the Expanding contact Expanding contact the terminal block communica�on protocol relay 2 relay 3 RS485 (DEGA/MODBUS) DIP switch for the Programming Ba�ery CR2032 LCD display connector RS485 address connector Status LED Instala�on, assembly and disassembly of the detector Before assembling, read the valid instala�on standarts EN 60079-29-2 (Selec�on, instala�on, use and maintenance of...

  • Page 7: Replacement Of The Sensor Module

    Panasonic BR2032 4. Connec�ng the detector via current loop to the controler DEGA UPA II/DEGA UPA III Connect one detector to each channel of the controler as shown in the picture below 5. Connec�ng the sensor via RS485 to the controller DEGA UKAIII/DEGA UPA III Note: Connec�on of transmi�ers with control panel only by DEGA protocol, not MODBUS protocol.

  • Page 8: Se�Ng The Rs485 Adress Of The Detector

    120R. Plug a jumper on the JP2 connector of the last device on the bus to include the 120R termina�ng resistor. In the default configuara�on, the jumper connector is not plugged. 9. Communica�on protocol switch DEGA/MODBUS Plugging a jumper in the JP1 connector will sw�ch from the DEGA communica�on protocol to the MODBUS communica�on protocol. Detector func�ons The detector's motherboard is equipped by status LEDs, which help in detec�ng problems during the installa�on.

  • Page 9: Monitoring The Calibra�On Periods

    4. Monitoring the calibra�on periods The detector con�nuously checks the calibra�on validity of the connected sensor. A�er 12 months since the last calibra�on (Max. calibra�on interval) the LED "ERR" starts flashing and an inscrip�on starts flashing on the LCD display. The connected sensor must be calibrated immediately. The detector will transmit the informa�on about the ending calibra�on via current loop.

  • Page 10: History Menu „Hist

    Main menu structure: Enter the menu by holding the magnet for 5 s History->-Informa�on->-Se�ngs->- Test->- Exit |-----------------------<------------------------------| Menu Display Descrip�on History Browsing the alarm history Informa�on Informa�on about detecto r se�ngs Se�ngs Detector configura�on Test Tes�ng the detec tor fu ncions Exit Return to normal ope...

  • Page 11: Informa�On Menu „Inf

    Exit Return to the main menu 2. Informa�on menu „INF“ Informa�on about se�ngs. Sequen�ally displays the following informa�on. Access previous informa�on by pressing „ “ Menu Display Descrip�on Dat e of next Displays the date of the next calibra�on calibra�on Date of l ast Displa ys the dat e of the last calibra�on calibra�on...

  • Page 12: Se�Ngs Menu „Set

    3. Se�ngs menu „SET“ Protected by password 0004. By entering a wrong password, the detector returns to measurement mode. The password can be changed in the menu SET -> PSWD. Menu Display Descrip�on Calibra�on Sensor calibra�on Se�ng the alarms Se�ng the alar ms Se�ng the range of the 20 mA Se�ng the range of the 20 mA current loop...
  • Page 13 d) Using „ “ select the concentra�on for alarm 4 Confirm „ “ e) Using „ “ switch between „YES“ - save se�ngs, or „NO“ - return to the Se�ngs menu. Confirm the selected op�on „ “ Se�ng the range of the 20 mA current loop a) Using „...

  • Page 14: Test Menu „Test

    4. Test menu „TEST“ Protected by password 0004. By enetering a wrong password, the detector returns to measurement mode. The password can be changed in the menu SET -> PSWD. Menu 4-20 mA current loop Using „ “ set the output current in a 4-22 mA range. Return to Test menu test „...

  • Page 15: Opera�On

    The exact interval depends on the purity of the environment, required accuracy and the occurrence of disturbing gases in the atmosphere. The calibra�on interval can be changed by the DEGA Config so�ware. Perform calibra�on only at cer�fied service centers with a valid cer�ficate of competence or the manufacturer.

  • Page 16: Gas Specifica�Ons

    Gas specifica�ons Add-on modules Product code Name Product descrip�on 40200003 DEGA NS III Relay Modul Inter nal 4 -relay, 2 50 V/10 A 40200010 DEGA NS III RS485 Internal output RS485 40200011 DEGA NS III Buzzer Internal buzzer on PCB, 4 VDC, 7 V DC, 30 mA, 88 dB...

  • Page 17: A�Achments

    Type 2 sensor type ID not found in the Contact the manufacturer - FW update required table se�ng LMP91000 CRC does not match these nsor Sensor error - solve via DEGA Config EEPROM LMP91000 does not respond Sensor error - contact the manufacturer The set sensor ID does not match with Checking the configura�on of the sensor required -...

  • Page 18: Signaliza�On Transmi�Ed By The Current Loop 4-20 Ma

    1 s 2 mA current Malfunc�on: Current output will be set to 0,5 mA Mainternace: Current output will be set to 1 mA 5. Package content 1 x NS III LCD body 1 x NS III LCD sensor unit...

  • Page 19: General Warranty Terms And Condi�Ons

    • contrary to the advice provided in the instruc�on manual DEGA products that have been used in associa�on with other than original DEGA products, including consumables and • accessories bearing addi�onal parts or consumables (e.g.
