INSTRUCTION
MANUAL
Gas Detection Transmitter
DEGA NBx-yL III
Reproduction of this manual, or any part thereof, in any form, without the prior permission of DEGA.CZ s.r.o. is prohibited
DEGA CZ s.r.o. reserves the right to alter the specifications of the hardware and software described in this manual at any time
and without prior notice
DEGA CZ s.r.o. bears no liable for any damage resulting from use of this device.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB*-*IL III Series and is the answer not in the manual?

Questions and answers

Related Manuals for DEGA NB*-*IL III Series

Summary of Contents for DEGA NB*-*IL III Series

  • Page 1 Reproduction of this manual, or any part thereof, in any form, without the prior permission of DEGA.CZ s.r.o. is prohibited DEGA CZ s.r.o. reserves the right to alter the specifications of the hardware and software described in this manual at any time and without prior notice DEGA CZ s.r.o.

  • Page 2: Table Of Contents

    Replacement of the sensor module ............................5 Connecting the transmitter via current loop to the controler DEGA UPA IIDEGA UPA III a DEGA UDA III......5 Connecting the sensor via RS485 to the controller DEGA UPA III/UDA III ................6 Installation of wiring for RS485 .............................

  • Page 3: Technical Data And Information

    Use the transmitter only with the appropriate certified DEGA products The device is certified as functionally and technically qualified only with original "DEGA" accessories. In case of using the device with any other products the manufacturer is not liable for any damages that may occur.

  • Page 4: Operational Conditions

    Series of detectors Type of detected gas Sensor type with linear output Third generation product with new DEGA design DEGA NBx-EL III with an electrochemical sensor They operate on the principle of change of electrical parameters on the electrodes stored in electrolyte, due to oxidation/reduction reactions of the detected gas on it's surface.

  • Page 5: Assembly And Disassembly Of The Transmitter

    Screw the two 3mm hexagons screws and put back the cover. Screw the cover. 3. Connecting the transmitter via current loop to the controler DEGA UPA IIDEGA UPA III a DEGA UDA III Connect one transmitter to each channel of the controler as shown in the picture below...

  • Page 6: Connecting The Sensor Via Rs485 To The Controller Dega Upa Iii/Uda Iii

    4. Connecting the sensor via RS485 to the controller DEGA UPA III/UDA III 1. Installation of wiring for RS485 Wiring must be done using bus topology and according to the RS485 principles. Maximum number of connected transmitters per controler channel is 16 (may be less depending on the configuration of the controller), while the total length of the connecting cable (electrical distance between the controller and the last transmitter) should not exceed 1200 meters.

  • Page 7: Transmitter Functions

    2. Gas detection The transmitter continuously measures the detected gas concentration in the atmoshpere and converts it's current value into a 4-20 mA signal or transmits it's value to the evaluation unit via DEGA protocol. 3. Malfunction If a malfunction of the electronics or the sensor is found during operation, the transmitter will continue transmitting via current loop 0,5mA.

  • Page 8: Operation

    For the „functional control“ do not use means for testing fire alarm detectors! Perform calibration only at certified service centers with a valid certificate of competence or the manufacturer. For the Czech Republic only DEGA CZ s.r.o. Accessories 1. Additional bushing DEGA BUSHING for NBxIII Basic types of transmitters 1.

  • Page 9: Transmitters With An Electrochemical Sensor Nbx-El Iii

    : 8h/7,1 ppm 1. st. 6,5 ppm, 2. st. 8 ppm Hydrogen sulfide 3. st. 10 ppm, 4. st. 13 ppm Hydrogen sulfide DEGA NBH2S-EL III H LCD RE 0-100 ppm 0-15ppm 0,1 ppm 15 ppm For high humidity 1.

  • Page 10: Transmitters With An Infrared Sensor Nbx-Il Iii

    Ethylene oxide 1. st. 0,5 ppm, 2. st. 0,8 ppm Ethylene oxide DEGA NBC2H4-EL III 0 – 10 ppm 0-1,5 ppm 0,1 ppm 3. st. 1,2 ppm, 4. st. 1,5 ppm 2 ppm Hydrogen 1. st. 100 ppm, 2. st. 200 ppm...

  • Page 11: Transmitters With A Pid Sensor Nsx-Pl Iii Pid

    1. st. 5% LEL, 2. st.10% LEL DEGA NBH-SL III Hydrogen (H 0-100% LEL 0-20 % LEL 0,1 % Hydrogen 0,8% 3. st. 15% LEL, 4. st. 20% LEL 1. st. 5% LEL, 2. st.10% LEL Acetylene 20 % DEGA NBY-SL III Acetylene (C 0–100% LEL...

  • Page 12: Signalization Transmitted By The Current Loop 4-20Ma

    • DEGA products that have been used in association with other than original DEGA products, including consumables and accessories • transmitter calibrations, setting the detection limits •...
  • Page 13 For the complete version of the general business conditions and of the claims procedure go to www.dega.cz Manufacturer: DEGA CZ s.r.o., Malešická 2850/22c, 130 00 Praha 3, Czech republic Tax ID: CZ 279 029 43, IČO: 279 02 943; Telephone +420 774 447 660 E-mail: info@dega.cz , Web: www.dega.cz © 2016 DEGA CZ s.r.o.
