- Page 1 FMG-25 ∙ FMG-60 ∙ FMG-80 ∙ FMG-120 Manual Cartridge Dispensers info@fisnar.com www.fisnar.com...
- Page 2 FMG-25, FMG-60, FMG-80, FMG-120 Manual Cartidge Dispensers OVERVIEW Tough, durable, and lightweight these 2.5, 6, 8 and 12oz manual cartridge dispensers are designed for dispensing adhesives and sealants commonly used in industrial assembly, aerospace, and automotive applications. Compatible for use with Techcon, Semco and EFD style cartridge systems.
- Page 3 Do not use incompatible material cartridges. Do not make any modifications to the dispenser. All repairs are to be done using Fisnar specified spare parts. Do not operate the applicator in excess of its maximum ratings / settings. Maintenance The dispensers are generally maintenance free.
- Page 4 FMG-25, FMG-60, FMG-80, FMG-120 Manual Cartidge Dispensers REPLACEMENT PARTS LIST Ref. Item Number Description 5801379 2.5oz Nylon Retainer Body 5801380 6oz Nylon Retainer Body 5801381 8oz Nylon Retainer Body 5801382 12oz Nylon Retainer Body 5801376-SEAL 2.5, 6, 8 and 12oz Nylon Retainer Cap Seal Item 2 not shown in graphic displayed above ©...
- Page 5 FMG-25, FMG-60, FMG-80, FMG-120 Manual Cartidge Dispensers OPTIONAL LUER LOCK ADAPTERS AND ACCESSORIES Tip Adapter ¼” NPT Male x Male Luer Lock 5801420 Metal Tip Adapter ¼” NPT Male x Male Luer Lock 5801449 Black Polypropylene Tip Adapter ¼” NPT Male x Male Luer Lock...
- Page 6 FMG-25, FMG-60, FMG-80, FMG-120 Manual Cartidge Dispensers STANDARD COMPATIBLE 1/4” NPT NOZZLES Item Number Length (inch) Dimension (inch) Material 1/16 EA2160-HD HDPE EA2180-LD LDPE EA2180-HD HDPE 1/16 EA4160-HD HDPE 1/16 EA4160-LD LDPE EA4180-LD LDPE 1/32 EA4320-HD HDPE 1/32 EA4320-LD LDPE...
- Page 7 FMG-25, FMG-60, FMG-80, FMG-120 Manual Cartidge Dispensers SPECIALTY COMPATIBLE 1/4” NPT NOZZLES Item Number Length (inch) Dimension (inch) Material Nozzle Style EA1050 1/2 x 1/16 HDPE Spreader EA1050-45 1/2 x 1/16 HDPE 45° Spreader EA1075 3/4 x 1/8 HDPE Spreader...
