P/N 561864
AUTOMATIC LIQUID DISPENSERS
Standard Accessories
Qty Description
1
Power cord – 110V unit
1
Power cord – 220V unit
1
Power cord – 220V unit
1
Barrel stand
1
Air hose
1
Foot pedal & cord
1
30 cc barrel adapter
1
5 cc barrel adapter
3
30 cc barrel
3
5 cc barrel
3
30 cc barrel piston PE
3
5 cc barrel piston PE
2
Barrel tip cap
2
14 gage tapered tip
2
16 gage tapered tip
2
18 gage tapered tip
2
20 gage tapered tip
2
22 gage tapered tip
2
24 gage tapered tip
2
20 gage blunt end tip
2
21 gage blunt end tip
2
22 gage blunt end tip
2
23 gage blunt end tip
2
25 gage blunt end tip
2
30 gage blunt end tip
DSP501A-4 & DSPE501A-4
O P E R A T I N G M A N U A L
Re-order P/N
Re-order
Qty/Pkg
560033
1
560033E-CE
1
560033E-PLUG
1
560751
1
560752
1
560027CW
1
560004A
1
560003A
1
560002E
10
560001A
10
560552
20
560550
40
580142
10
560783K
25
560010K
25
560011K
25
560012K
25
560013K
25
561338K
25
560088
25
560089
25
560090
25
560014
25
560015
25
560016
25
The DSP501A-4 & DSPE501A-4 are ideal for dispensing
applications requiring simultaneous control of between one
and four barrels. A common internal manifold distributes
the air pressure to four outputs on the side of the unit. A
larger internal air solenoid assists in exhausting the greater
volume of air found in a multiple barrel configuration.
An internal vacuum prevents dripping of very low viscosity
liquids.
The
DSP501A-4
and
programming from 0.01 to 31 seconds. Foot pedal initiation
can be for either maintained or momentary operation.
Specifications
•
Size:
•
Weight:
•
Input Voltage:
•
Dispense Time:
•
Internal Voltage:
•
Cycle Initiation:
•
Cycle Speed:
•
Air Input:
•
Air Output:
•
Standards:
•
Barrel "Suck-Back" Feature
Ordering Guide
Part No
DSP501A-4
DSPE501A-4
REV. B
DSPE501A-4
provide
9 " x 8 " x 2 " (24 x 21.6 x 6.7cm)
4lbs 2oz (1.9kg)
110V – Model DSP501A-4
220V – Model DSPE501A-4
0.01 - 31 seconds
24V dc
Maintained or Momentary
600+ /Minute
80-100psi (5.5-7 bar)
4 outputs: 1-100psi (0.1-7 bar)
European CE approved unit
Description
Automatic Liquid Dispenser – 110V ac
Automatic Liquid Dispenser – 220V ac
AUG. 05
timer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FISNAR DSP501A-4
Summary of Contents for FISNAR DSP501A-4
- Page 1 AUTOMATIC LIQUID DISPENSERS O P E R A T I N G M A N U A L The DSP501A-4 & DSPE501A-4 are ideal for dispensing applications requiring simultaneous control of between one and four barrels. A common internal manifold distributes the air pressure to four outputs on the side of the unit.
- Page 2 5. Fill barrel (with barrel tip cap on the barrel) with material to be dispensed and lock barrel to adapter assembly as shown. AIR & ELECTRICAL SET UP DIAGRAM POWER CORD AIR HOSE COMPRESSED AIR FEMALE PLUG COUPLING MALE QUICK CONNECT FOOT SWITCH PLUG DSP501A-4 BARREL BARREL STAND - 2 -...
- Page 3 UNDERSTANDING THE FUNCTIONS OF YOUR DISPENSER DISPLAY D F A B G Turn unit on. Turn amber light on – this will provide continuous flow of material as long as the foot pedal is depressed. Turning the pressure adjust knob (D) allows for adjustments of air pressure.
- Page 4 In no event shall manufacturer be liable for consequential or incidental damages. A return authorization is required from I&J FISNAR INC. prior to shipping a defective unit to the factory.
