Evaluation Board User Guide
46 1
47 1
48 2
49 2
50 1
51 1
52 2
53 2
54 3
55 2
56 1
57 1
58 1
analog.com
Arrow.com.
Downloaded from
VCC_5V
VREF_5V
C14, C19
C18, C48
C8
GND_7
R11, R15
R14, R82
R33, R35, R87
R42, R51
R59
R61
R62
EEPROM, 1.8 V to 5.5
V
Connector-PCB test Components Corporation, TP-104-01-09
point white
Connector-PCB test Components Corporation, TP104-01-08
point grey
Capacitor, ceramic, 2 MURATA, GQM1875C2E2R0BB12
pF 250 V, 0.1 pF, C0G
0603
Capacitor, ceramic, 100 KEMET, C0603C101K5RAC
pF, 50 V, 10%, X7R
0603
Non-preferable, do not N/A
install (DNI), use
SYM_3 and/or SYM_4
Connector-PCB test Components Corporation, TP-104-01-00
point, black
Do not install (DNI) TBD0603
(TBD_R0603), use
SYM_3 and/or SYM_4
Resistor, surface-mount Vishay, FC0402E50R0FST1
device (SMD), 50 Ω,
1%, 1/20 W, 0402, high
frequency
Resistor, surface-mount Panasonic, ERJ-2GE0R00X
device (SMD), 0 Ω,
jumper 1/10 W, 0402,
AEC-Q200
Resistor, surface-mount Panasonic, ERJ-3EKF4992V
device (SMD), 49.9 kΩ,
1% 1/10 W, 0603, AEC-
Q200
Resistor, surface-mount Vishay, CRCW251249R9FKEG
device (SMD), 49.9 Ω,
1%, 1 W, 2512, AEC-
Q200
Resistor, through hole, Vishay, Y00622K00000V9L
2 kΩ, 0.005% 0.6 W,
7.62 mm x 2.67 mm x
8.53 mm x 3.81 mm,
high precision
Resistor, surface-mount Vishay, PAT0603E2001BST1
device (SMD) 2 kΩ
0.1% 0.15 W, 0603,
AEC-Q200, sulfur
resistant
AD8460
Rev.0 23 of 31
