Installing/removing the battery
(Fig. 8)
Installation:
– Lock the power button.
– Align the slots on the battery with the
slots on the body of the power tool.
– Push the battery with a little force in the
direction (B) until you hear a character-
istic locking sound.
– Do not apply excessive force when in-
stalling the battery. The need for effort
during connection means that the ac-
tions are performed incorrectly. Also,
the cause may be a foreign object in
the grooves of the battery case.
Removal:
– Turn off the power tool and lock the
power button.
– Press the battery latch (1) and do not
release. Pull the battery with a little
force in the direction (A).
Battery charging procedure (Fig. 9)
WARNING!
Charge the battery at an ambient
temperature of +5 °C to +45 °C. If
the temperature range is not ob-
served, the protection system will
activate the battery
charging.
Fully charge the new battery before
connecting it to the power tool for
the first time.
– Disconnect the battery from the pow-
er tool.
– Connect the charger to an AC outlet.
When you connect the charger to the
network, the green indicator will light
up.
– Install the battery (1) on the charger (2).
– The indicator on the charger (Fig. 10)
will light up in red during the charging
of the battery.
– The indicator will change from red to
green when the battery is fully charged.
– When the battery is fully charged, re-
move it from the charger. Be sure to
disconnect the charger cord from the
network.
EU-CD1023001-1023001
Battery charge indicator (Fig. 11)
– The battery is 75-100% charged if all in-
– The battery is 25-75% charged if two in-
– The battery is 10-25% charged if only
8. WORKING WITH ELECTRIC
TOOLS
On/off (Fig. 1)
To turn the power tool on/off, press/
release the power button (10). Adjust-
ing the rotation speed (Fig. 1). The rota-
tion speed can be adjusted. Press harder/
lighter on the power button (10).
Switching speed modes (Fig. 12)
Set one of the two speed modes using
the switch (1). To do this, move the switch
(1) to position "1" (low speed (3)) or to po-
sition "2"(high speed (2)).
Use low speed in screwdriver mode or
and block
when drilling holes in hard materials (met-
al, etc.). Use high speed when screwing/
unscrewing fasteners or drilling holes in
wood, etc.
The switch for the direction of
rotation/ locking the power button
(Fig. 1)
The switch allows you to change the di-
rection of rotation (twisting or unwind-
ing).
Locking prevents the power tool from be-
ing switched on accidentally. If you set
the switch (9) to the middle position, the
power button (10) is blocked. Lock the
power button when the power tool is not
dicators (red, orange, and green) are lit.
dicators (red and orange) are lit.
one indicator (red) is lit. Charge the
battery.
WA R NI NG!
It is recommended to work with the
power tool at ambient tempera-
tures from -10 °C to +50 °C.
WA R NI NG!
Switch the speed and change the
direction of rotation only after the
motor of the power tool has come
to a complete stop!
