  • Page 1 Operator´s manual Snow V-plough City Ranger 3070...
  • Page 2 Reservations As it is the Egholm policy to make continuous improvements, we reserve the right to alter the specifications and equipment at any time without notice. Egholm accepts no liability for errors or omissions in the operator’s manual.

  • Page 3: Table Of Contents

    Daily cleaning and maintenance will extend machine. the lifetime of both the machine and the attachment. The V-plough support has sideways suspension, so that the Snow V-plough always adjusts to ground conditions. Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 4: General Information

    General information...

  • Page 5: Safety

    Avoid roll-overs Do not drive the machine in a place where it can slide, tip or roll. Do not drive on slopes with an incline of more than 5°. (Picture 3) Right Joystick Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 6 Avoid eye injuries Wear eye protection. Destruction of the hydraulic hoses by pinching or rubbing against the structural parts When connecting the hydraulic hoses, make sure their installation is kink and abrasion free. Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 7 Regularly check the hydraulic hoses for leaks. They must be replaced at regular intervals, even if no defects are present (See the Section 3.1 Service and Maintenance chart in the Operator´s manual for the City Ranger 3070 Basic machine). Operator’s Manual City Ranger 3070 Snow...

  • Page 8: Eu Declaration Of Conformity

    Unless otherwise agreed in writing between the operator, customer and Egholm, Egholm is the data originator (data originator) of all data generated by the machine and attachments during use.

  • Page 9: Technical Data

    1,380 - 1,600 mm Ground clearance below scraping edge, lifted V-plough in straigt position 350 mm Ground clearance below skids, lifted V-plough in straight position 280 mm Attention Specifications may be changed without prior notice Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 10: Operator's Manual

    Operator´s manual...

  • Page 11: Assembly/Disassembly

    Remove the plastic from the V-plough and pallet. Lift the V-plough off the pallet - use a crane and the V-plough lifting point. (Picture 2) Delivered on a pallet Lifting point Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 12 (Picture 3+4) The locking handle may only be engaged when the machine has been stopped and engine switched off. Locking the attachment Handle in locked position. Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 13: Important Before Start-Up

    Always make sure the right tool is selected on the selection screen. If a wrong tool is chosen the tool may work in a wrong way. The Snow V-plough and machine are now on the screen Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 14 V-plough. This damage may cause bolts to snap or parts of the Snow V-plough to bend. Turning the Snow V-plough Damage of this type is not covered by Lifting/lowering the Snow V-plough the warranty. Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 15: Adjustment

    The Snow V-plough is raised using the 3. Stop the machine. joystick 4. Remove the locking ring on the skid. (Picture 2) Adjust the skid height by moving washers up or down. Skid Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 16: Service And Maintenance

    Service and maintenance...
  • Page 17 (Picture 2) There are four lubrication nipples on the two cylinders. (Picture 3) 1 on each skid bracket. (Picture 4) Location of lubrication nipples 1 on each skid bracket. Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 18 Same procedure when replacing both loose paint and to repaint any damaged areas. steel scraper or rubber scraper. it is recommended to preserve grease and spray the attachment with a protective lubricants Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 19: Conditions

    Conditions...

  • Page 20: Warranty

    The warranty period for the materials and manufacture of this Snow V-plough is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs at no charge to the customer, including materials and working hours, in accordance with the terms and conditions listed below.

  • Page 21: Complaints

    2. Remove the plastic and rubber parts and dispose of them in accordance with the applicable environmental legislation. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an approved scrap merchant. Operator’s Manual City Ranger 3070 Snow V-plough...

  • Page 22: Notes

    Notes Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 23 Notes Operator’s Manual City Ranger 3070 Snow V-plough...
  • Page 24 Egholm A/S Egholm A/S Transportvej 27 Transportvej 27 7620 Lemvig, Denmark 7620 Lemvig, Denmark T.: +45 97 81 12 05 T.: +45 97 81 12 05 www.egholm.eu - info@egholm.dk www.egholm.eu - info@egholm.dk...
