Egholm City Ranger 2250 Operator's Manual

Hide thumbs Also See for City Ranger 2250:
Table of Contents

Advertisement

Quick Links

Download this manual
O
´
peratOr
s manual
SNOW BLOWER
City Ranger 2250

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the City Ranger 2250 and is the answer not in the manual?

Questions and answers

Related Manuals for Egholm City Ranger 2250

Summary of Contents for Egholm City Ranger 2250

  • Page 1 ´ peratOr s manual SNOW BLOWER City Ranger 2250...
  • Page 2 (Title and/or number and date of issue of standards and/or specifications)) Entwicklungsleiter / Chef du service techn. / Dokumentationsbevollmächtigter Direttore tecnico / Director técnico / R & D Manager Dietikon, den 17.12.2009 K. Iten A. Nussbaumer Operator´s manual City Ranger 2250 Snow blower...

  • Page 3: Table Of Contents

    9.1 Wearing parts -City Ranger 2250 Snow blower ....... . .

  • Page 4: First Things First

    He shall inform Rapid/Egholm immediately of asafety defects becoming apparent on the machine or its mounted devices. Service centers Complex work on the machine must only be carried out by an authorized Rapid/Egholm service center. User The machine must only be used, serviced and repaired by persons familiar with such work who have been informed of the potential dangers involved.

  • Page 5: Safe Operation

    The accident prevention regulations and the generally approved safety-related rules regulations must be observed. Stopping the In case of unexpected situations, immediately switch off the blower drive and apply the blower drive parking brake. Operator´s manual City Ranger 2250 Snow blower...

  • Page 6: Workstation

    The operator bears the full responsibility that there are no persons within the danger zone. • Do not touch machine parts until they have come to a complete standstill (moving parts continue to run). Operator´s manual City Ranger 2250 Snow blower...

  • Page 7: Working On The Slope Or In Uneven Terrain

    Use the largest possible track width and axle width. • Adapt your speed. • Keep people away from the danger zone. NOTICE Simple checking of the slope inclination in % with a spirit level, see illustration below. Operator´s manual City Ranger 2250 Snow blower...

  • Page 8: Working

    2.6 Noise and vibration CAUTION Noise and vibration Health hazard due to noise and vibration. Long-term exposure to noise and vibrations may damage your health. • Wear ear protectors. • Adjust your working hours accordingly. Operator´s manual City Ranger 2250 Snow blower...

  • Page 9: Safety Stickers And Their Position

    Shut off engine and remove key before performing maintenance or repair work. Identification / Labeling Manufacturer’s nameplate When ordering spare parts or in case of inquiries with regard to the machine, please indi- cate the device type and vehicle number always.. Operator´s manual City Ranger 2250 Snow blower...

  • Page 10: Identification / Labeling

    Identification / Labeling 3.1 Manufacturer´s nameplate When ordering spare parts or in case of inquiries with regard to the machine, please indi- cate the device type and vehicle number always. 3.2 Markings CE symbol Operator´s manual City Ranger 2250 Snow blower...

  • Page 11: Maschine Parts

    Scraper bar Gears Protective cloth Electric cylinder ”Ejection door adjustment” Ejection door Discharge chute Plug connection Coupling triangle 10. Cover ”tooth belt” 11. Sliding block 12. Protection fence 13. Rod 14. Drift cutter Operator´s manual City Ranger 2250 Snow blower...

  • Page 12: Attaching On Basic Machine

    The machine can suddenly trap the user or third persons, cause them to fall over, run them over, crush or lacerate them. • Coupling and uncoupling the snow blower may only be done when the engine is turned off. Operator´s manual City Ranger 2250 Snow blower...

  • Page 13: Drive

    WARNING Projected parts Projected parts may hit persons, animals and objects. • Do not point the discharge chute in direction of people, animals and objects. • Keep people away from the danger zone. Operator´s manual City Ranger 2250 Snow blower...

  • Page 14: Ejection Door Adjustment

    WARNING Projected parts Projected parts may hit persons, animals and objects. • Do not point the discharge chute in direction of people, animals and objects. • Keep people away from the danger zone. Operator´s manual City Ranger 2250 Snow blower...

  • Page 15: Adjusting The Skid Shoes

    The higher the engine speed, the higher the throwing distance. 6.9 Moving, maneuvering the snow blower When maneuvering or moving the snow blower, the blower drive must be switched off. NOTICE For transport protection see operating instructions of the basic machine. Operator´s manual City Ranger 2250 Snow blower...

  • Page 16: Transporting Without Basic Machine

    The machine can suddenly trap the user or third persons, cause them to fall over or run them over. • Never leave the machine while the engine is running. • Secure the machine against rolling away and unauthorized use. Operator´s manual City Ranger 2250 Snow blower...

  • Page 17: Maintenance

    • Discharge chute clogged. NOTICE If you are unable to remedy the malfunction yourself, consult an authorized Egholm dealer. 7.2 Eliminating the plugging inside the discharge chute Remove the plugged snow by using the rod fastened on the blower housing. Do not use metal objects.

  • Page 18: Overload Protection Of The Blower Drive

    Refit the protective cover. Belt tension: • New toothed belt 116 - 125.4 Hz • Toothed belt in use 90.8 - 107.4 Hz or • pressure of 10 kg = deformation of 6 mm Operator´s manual City Ranger 2250 Snow blower...

  • Page 19: Maintenance Plan

    Fill in the prescribed oil quantity. • Check the oil level. • Screw in the charging screw (2). NOTICE Check the oil level When refilling oil or checking the oil level, the machine must be positioned horizontally. Operator´s manual City Ranger 2250 Snow blower...

  • Page 20: Lubrication Layout

    Maintenance 7.9 Lubrication layout Lubrication points 1) Toothed wheels Lubricating grease Lithium soap base NLGI 2 (multi-purpose grease) Operator´s manual City Ranger 2250 Snow blower...
  • Page 21 Snow blower for smooth snow Type 1562 (SF105) Clearance width 105 cm Diameter of the cutter 46 cm Diameter of the impeller 35 cm Max. shaft speed 1000 RPM Weight 170 kg Dimensions Operator´s manual City Ranger 2250 Snow blower...

  • Page 22: Conditions

    In case of errors or defects on the machine within the warranty period, Egholm will carry out the necessary repairs at no charge to the customer, including materials and working hours, in accordance with the terms and conditions listed below.

  • Page 23: Complaint

    1. Used hydraulic oil is to be disposed of at an approved waste disposal facility or site. 2. Remove all plastic and rubber parts and dispose of. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an approved scrap merchant. Operator´s manual City Ranger 2250 Snow blower...

  • Page 24: Wearing Parts

    Wearing parts 9.1 Wearing parts -City Ranger 2250 Snow blower 01604240 Toothed belt 01905070 Tightening pin 90605070 Slide shoe 90605090 Scraper bar 90605100 Protective cloth Operator´s manual City Ranger 2250 Snow blower...

  • Page 25: Notes

    Notes Operator´s manual City Ranger 2250 Snow blower...
  • Page 26 Notes Operator´s manual City Ranger 2250 Snow blower...
  • Page 27 Notes Operator´s manual City Ranger 2250 Snow blower...
  • Page 28 Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.egholm.eu info@egholm.dk 70101171-01 EN...
