Dimensions - Tbw Magnet Plate - Tecnotion TM3 Manual

Parameter Dimension
Magnet plate length
Magnet plate width
Magnet plate height
Magnet plate mass
Magnet plate edge to center line
Magnet plate edge to dowel pin
Dowel pin to slotted dowel pin P
Dowel pin to dowel pin M
Dowel pin to mounting hole
Mounting hole to mounting hole
Number n
Mounting hole to center line
Dowel pin dimensions
Slotted dowel pin dimensions
Mounting hole dimensions
Mechanical Interface Mechanical Interface Mechanical Interface
Iron Core TB Series Iron Core TB Series Iron Core TB Series
APPENDIX A
Unit TB192 TB288
Magnet Plates Magnet Plates Magnet Plates
mm 192 288
mm 130
mm 12.2
kg/m 10.5
mm 65
mm 14.2
mm 168 264
mm 192 288
mm 12
mm 48
3 5
mm 60
mm Ø5 F10 (3 deep)
mm 5F10 x 0.5 (3 deep)
mm Ø6 (8x) Ø6 (12x)

Dimensions - TBW magnet plate

+0.05 +0.05 +0.05
M M M
0 0 0
‹ 5F10 x 0,5 ‹ 5F10 x 0,5 ‹ 5F10 x 0,5 P u 0,1 P u 0,1 P u 0,1
(3 deep) (3 deep) (3 deep)
O 6 O 6 O 6
n x 48 n x 48 n x 48
APPENDIX A
Tecnotion | www.tecnotion.com | sales@tecnotion.com
O 5F10 O 5F10 O 5F10
14,2 14,2 14,2
(3 deep) (3 deep) (3 deep)
12 12 12
48 48 48
21,7 21,7 21,7
* All sizes are in mm
46
