Mounting the feet

On-top or recessed
In case of a C-desk design, ensure to turn the feet in the correct direction to avoid tilting of the desk�
1� Mount the feet on the columns using four M6 or two M8 mounting screws for each foot�
The columns have four M6 and two M8 threaded holes in the bottom plate� For mounting the feet, always
use four M6 or two M8 screws with the following specifications:
Quality:
Length:
2� Fasten the screws thoroughly (torque: max� 10 Nm)�
3� Mount the adjustment screws�
Min� grade 8�8
Min� 10 mm (plus foot thickness);
Max� 16 mm (plus foot thickness) for M6
Max� 14 mm (plus foot thickness) for M8
Figure 4 Column bottom mounted on desk foot (left: M6; right: M8)
DF2 | 25
