Preparing the assembly

1� Gather all parts for the desk including the tabletop�
2� Turn the tabletop upside down�

Assembling the top frame

1� Adjust the beam length�
Be careful when adjusting the beams� Fingers may get squeezed�
1�1� Extend the beam to the required length (1150 mm to 1750 mm (45" to 69")), adjustable in
50 mm (2") steps)�
The beam must not be pulled completely apart in order not to pull the drive shaft apart�
Minimum adjustment in the connection end is 100 mm (4") (to keep the power and RJ45 sockets
accessible), otherwise adjustable in 50 mm (2") steps�
