The board includes M24C32-RMN6TP, ST25R3916B, LEDs, and switch:
M24C32-RMN6TP: The M24C32 is a 32-Kbit I2C-compatible EEPROM (electrically erasable programmable
memory) organized as 4 K × 8 bits. The M24C32-W can operate with a supply voltage from 2.5 to 5.5 V.
The M24C32-R can operate with a supply voltage from 1.8 to 5.5 V, over an ambient temperature range of -40 to
+85 °C.
Order code
Package
Operating voltage
ST25R3916B: The ST25R3916B is a high-performance NFC universal device supporting NFC initiator, NFC
target, NFC reader and NFC card emulation modes when applicable.
UM3260 - Rev 1
Figure 3. X-STM32MP-NFC08 component placement details
Table 1.
Features
EEPROM details
Description
M24C32-RMN6TP
SO-8
1.8 to 5.5 V
UM3260
Overview
page 4/27
