Figure 10.
3V3
R1
1K
SB1 SB2 SB3
Open Open Open
NM NM NM
R5 R6 R7
22K 22K 22K
NM NM NM
FIDUCIAL1 FIDUCIAL2
Mouting hole_3.2mm drill 1
Fiducial Fiducial
FIDUCIAL3
Mouting hole_3.2mm drill 1
Fiducial
X-STM32MP-NFC08 circuit schematics (2 of 6)
3V3
C1
R2 R3
100nF
U1
1 8 1K 3.9K
E0 VCC
2 7
E1 WC
3 6
E2 SCL
4 5
VSS SDA
M24C32-RMN6TP
J1
1
2
3
3-pin Male Header
Jum per
1- 2
2- 3 ( DEFAULT)
J2
J3
Mouting hole_3.2mm drill
1
1
Mouting hole_3.2mm drill
J4
J5
R4
3.9K
EEPROM_ID_SC
EEPROM_ID_SD
2m m
EEPROM (WC)
WRITE_ENABLE
WRITE_DIS ABLE
Cam er a Sl ot
17m m
