1.2 Install the window sealing plate assembly
1) Half open the window, and mount the window sealing plate assembly to the window
(as shown in Figure 2 and Figure 3); the assembly can be placed in horizontal and
vertical direction.
2） Pull various components of the window sealing plate assembly open, adjust their
opening distance to bring both ends of the assembly into contact with the window
frame, and fix various components of the assembly.
1.3 Install the body
1) Move the machine with installed heat pipe and fittings before the window, and the
distance between the body and walls or other objects shall be least 50 cm (as shown
in Figure 4).
2) Elongate the heat pipe and snap the flat end of the heat pipe joints into the elliptical
hole of the window sealing plate assembly (as shown in Figure 5 and Figure 6) .
Notes: 1. the flat end of the heat pipe joints must be snapped into place.
2. The pipe cannot be distorted nor has substantial turning (greater than 45 °).
Keep the ventilation of the heat pipe unobstructed.
