- Page 1 IN231000683V01_UK 823-048V70 A020G Local air conditioners IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Instruction Manuel...
-
Page 2: Table Of Contents
Content I. Attention Matters………………………………………………………….…...………….…..3 II. Features and Components…………………………………………………………….…..4 III. Control Setting……………………………………………………..….……………….…..6 IV. Installation and adjustment…………………………………………………………….…..9 V. Drainage Instructions…………………………………………………………………….….11 VI. Maintenance………………………………………………………………………….…..12 VII. Unit Storage ……………………………………………………………….…....12 VIII. Troubleshooting…………………………………………………………………….…..13 IX. Addendum………………………………………………………………………….…...…...19 The refrigerant used in mobile air conditioners is the environmentally friendly hydrocarbon R290.This refrigerant is odorless, and compared to the alternative refrigerant, the R290 is an ozone-free refrigerant, and its effect is very low. -
Page 3: Attention Matters
I. Attention Matters Warning matters: 1. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. 2. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.) 3. -
Page 4: Features And Components
* The machine should stay away from gasoline, flammable gas, stoves and other heat sources. * Don't disassemble, overhaul and modify the machine arbitrarily, otherwise it will cause a machine malfunction or even bring harm to persons and properties. To avoid danger, if a machine failure occurs, ask the manufacturer or professionals to repair it. - Page 5 The Max operation temperature for the air conditioner Cooling: 35/24℃; heating:20/12 ℃; Temperature operation range: 7-35℃. 2. Components:...
-
Page 6: Control Setting
III. Control Setting I. Operation interface: 1: Power Key 2: Mode Key 3:Fan Key 4:Down Key 5: Display Window 6: Up Key 7: Timer Key 8: Sleep Mode Key 9: Swing Key 10: WIFI Indicator 1. Power Key: Press this key to turn on and turn off the unit. 2. - Page 7 10.WiFi indicator light 11. Information on the WIFI App “Smart Life - Smart Living” The Smart Life - Smart Living app is available for android and iOS. Scan the corresponding QR code to get directly to the download. NOTE: Depending on the provider, there may be costs involved in downloading the app.
- Page 8 Instructions of key operation of the high-quality remote control are as follows: 1. Power: Press the key to turn on or turn off the machine. 2. Mode: press the key to switch between cooling, fan, and dehumidification mode. 3. Up: press the key to increase temperature and timing set value.
-
Page 9: Installation And Adjustment
3.3 Automatic Defrosting (heating models have this function): The machine has automatic defrosting function. Defrosting can be achieved through four - way valve reversing. 3.4 Protection Function of the Compressor ： To increase the service life of the compressor, it has a 3-minute delay booting protection function after the compressor is turned off. - Page 10 Figure 2 Figure 3 1.3 Install the body 1) Move the machine with installed heat pipe and fittings before the window, and the distance between the body and walls or other objects shall be least 50 cm (as shown in Fig.4).
-
Page 11: Drainage Instructions
Important Notice The length of the exhaust hose shall be 280~1,500mm, and this length is based on the specifications of the air conditioning. Do not use extension tubes or replace it with other different hoses, or this may cause a malfunction. Exhaust must be unobstructed; otherwise it may cause overheating. -
Page 12: Maintenance
VI. Maintenance Cleaning: before cleaning and maintenance, turn off the machine and unplug the plug. 1. Clean the surface Clean with surface of machine with a wet soft cloth. Don't use chemicals, such as benzene, alcohol, gasoline, etc.; otherwise, the surface of the air conditioning will be damaged or even the whole machine will be damaged. -
Page 13: Troubleshooting
VIII .Troubleshooting 1. Information on servicing 1) Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system. - Page 14 – Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded. 9) Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures.
- Page 15 5. Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. 6. Leak detection methods The following leak detection methods are deemed acceptable for systems containing flammable refrigerants.
- Page 16 equipment. Hoses or lines shall be as short as possible to minimize the amount of refrigerant contained in them. – Cylinders shall be kept upright. – Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. –...
- Page 17 holding the total system charge is available. All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure relief valve and associated shut-off...
- Page 18 VIII. Troubleshooting Do not repair or disassemble the air conditioning by yourself. Unqualified repair will lead to failure of the warranty card, and may cause damage to users or their properties. Reasons Solutions Problems Turn it on after connecting it to a There is no electricity.
-
Page 19: Addendum
IX. Addendum Schematic diagram for air conditioning (The specific technical parameters of the machine shall be subject to the nameplate on the product) Capillary Condenser Evaporator Compressor Treatment: Don't put the abandoned machine with other unsorted waste together. Such waste shall be placed separately for other special use. If you have any questions, please contact our customer care centre.
