2.2 Overview of Product
333
Figure 2.2
Dimensions of M2 microinverter
2.3 Terminals Description
D
E
B
Figure 2.3
M2 microinverter interface
(rear view)
7
A
C
Code
A
B
C
Table 2.1
M2 microinverter D
Interface description
E
2.4 Datasheet
Model M2-1.8K-S4
Input Data (DC)
Recommended PV Module Power (STC) Range [Wp]
Peak Power Tracking Voltage [V]
Operating Voltage Range [V]
Maximum Input Voltage [V]
Maximum Input Current [A]
Back-Feed Current [A]
Overvoltage Category
Output Data (AC)
Maximum Output Power [VA]
Nominal Output Current [A]
Rated AC Voltage/Range [V]
Rated Output Frequency/Range [Hz]
Power Factor [cos φ]
M2 Series Micro-inverter
Name
Mounting Hole
DC Cables
Antenna
AC Cables
LED Indicators
M2-2K-S4 M2-2.2K-S4
400~700+
35~50
16~55
60
20 x 4
0
Ⅱ
1800 2000 2200
7.82 8.7 9.56
L+N+PE, 220, 230, 240/180～280
50, 60/45～55, 55～65
> 0.99 default 0.8 leading～0.8 lagging
M2-2.25K-S4
2250
9.78
8
