4.1 Safety Instruction

Electrical connection must only be carried out by professional technicians. Before connection, necessary
protective equipment must be employed by technicians including insulating gloves, insulating shoes and
safety helmet.
· Dangerous to life due to potential fire or electricity shock.
· The wiring and connection of the inverter should be carried out by qualified technicians in accordance
with local and national electrical standards and regulations.
· When the photovoltaic array is exposed to light, it supplies a DC voltage to the inverter.
· Ensure that all AC cables are correctly wired and that none of the wires are pinched or damaged.
· Electrical connection should in conformity with proper stipulations, such as stipulations for cross-sectional
area of conductors, fuses and ground protection.
· Use AWG 10 (4 mm²) cable for AC trunk cable.

4.2 Specifications for Electrical Interface

Note: Except for optional parts and parts provided by installers, all other accessories are included in the
product package.
