4. Hung Window Installation
Step 1:
Insert the window slider assembly into the window opening.
Step 2:
Cut the non-adhesive foam seal C strip to match the width of the window. Insert the seal between the glass
and the window frame to prevent air and insects from getting into the room.
Step 3:
If desired, install the security bracket with 2 screws as shown.
NOTICE:
Once the Exhaust Hose assembly and Adjustable Window Slider are prepared,
choose from one of the following two installation methods.
5. Sliding Window Installation
Step 1:
Insert the window slider assembly into the window opening.
Step 2:
Cut the non-adhesive foam seal C strip to match the height of the window. Insert the seal between the
glass and the window frame to prevent air and insects from getting into the room.
Step 3:
If desired, install the security bracket with 2 screws as shown.
NOTICE:
Once the Exhaust Hose assembly and Adjustable Window Slider are prepared,
choose from one of the following two installation methods.
19
