Midea MAP10S1XWBL User Manual page 16

Con rm your window type (window type
and opening size
Sliding Window Installation
For optimal performance in operation
INCORRECT
NOTICE:
To ensure proper function, DO NOT overextend or bend the hose. Make sure
that there is no obstacle around the air outlet of the exhaust hose (in the range
of 500mm) in order to the exhaust system works properly. All the illustrations
in this manual are for explanation purpose only. Your air conditioner may be
slightly different. The actual shape shall prevail.
CORRECT
16
Hung Window Installation
