Summary of Contents for Extron electronics DTP HDMI 4K 230
- Page 1 DTP HDMI 4K 230 HDMI Twisted Pair Extender User Guide HDMI & DVI Extenders 68-2244-01, Rev. C 02 24...
- Page 2 Safety Instructions Safety Instructions • English Instructions de sécurité • Français AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le produit, WARNING: This symbol, , when used on the product, is intended to signale à l’utilisateur la présence à l’intérieur du boîtier du produit d’une alert the user of the presence of uninsulated dangerous voltage within the tension électrique dangereuse susceptible de provoquer un choc électrique.
- Page 3 安全说明 • 简体中文 警告： 产品上的这个标志意在警告用户, 该产品机壳内有暴露的危险电 压， 有触电危险。 注意： 产品上的这个标志意在提示用户, 设备随附的用户手册中有重 要的操作和维护(维修)说明。 关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍使 用的特性等相关内容，敬请访问 Extron 网站 , www.extron.com，参见 Extron 安全 规范指南，产品编号 68-290-01 。 安全記事 • 繁體中文 안전 지침 • 한국어 警告: 若產品上使用此符號， 是為了提醒使用者， 產品機殼內存在未隔離的危險 경고: 이 기호 가 제품에 사용될 경우, 제품의 인클로저 내에 있는 접지되지 電壓，...
- Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 5: Table Of Contents
Operation .............. 10 Reference Information ........11 Mounting the Transmitter or Receiver ....11 Tabletop Use ............11 Mounting kits ............11 UL Guidelines for Rack Mounting...... 12 Disconnecting the Ground ........13 DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Table of Contents... - Page 6 DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Table of Contents...
-
Page 7: Introduction
This guide describes the Extron DTP HDMI 4K 230 Long Distance High Definition Multimedia Interface (HDMI) Twisted Pair Extender, which consists of a DTP HDMI 4K 230 Tx transmitter and a DTP HDMI 4K 230 Rx receiver. This guide describes how to install, operate, and configure the transmitter and receiver. -
Page 8: Tp Cable Advantages
• UL 2043 plenum rated — The DTP HDMI 4K 230 Rx meets UL 2043 for smoke and heat release installation within a plenum airspace above a drop ceiling - power supply excluded. Above-the-ceiling placement conceals the receiver to prevent theft, and is convenient for installing equipment when space inside the room is limited. - Page 9 Optional, external Extron Everlast power supply available, part #70-1174-01 — Provides worldwide power compatibility with high demonstrated reliability and low power consumption. • Extron Everlast Power Supply is covered by a 7-year parts and labor warranty. DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Introduction...
-
Page 10: Installation And Operation
Installation and Operation _____________________________________________________________________ This section describes the installation and the operation of the DTP HDMI 4K 230 Tx/Rx Extender, including: • Mounting the Units • Connections • Operation Mounting the Units Mounting the Transmitter or Receiver Mounting instructions can be found in on page 11. - Page 11 Disconnecting the Ground on page 13) because of ground potential differences, one DTP HDMI 4K 230 unit cannot remotely power the other unit. Each unit requires a local power supply. DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Installation and Operation...
-
Page 12: Receiver Connections
Pour l’audio asymétrique, connectez les manchons au contact au sol. Ne PAS connecter les manchons aux contacts négatifs (–). • Do NOT connect the sleeves to the negative (-) contacts. • Ne PAS connecter les manchons aux contacts négatifs (–). DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Installation and Operation... -
Page 13: Connector And Cable Details
Disconnecting the Ground If you have removed the ground jumpers (see on page 13) because of ground potential differences, one DTP HDMI 4K 230 unit cannot remotely power the other unit. Each unit requires a local power supply. Connector and Cable Details TP cable termination and recommendations Figure 5 details the TIA/EIA T 568B wiring standard. - Page 14 Disconnecting the Ground on page 13) because of ground potential differences, one DTP HDMI 4K 230 unit cannot remotely power the other unit. Each unit requires a local power supply. Figure 6 shows how to wire the connector. Use the supplied tie-wrap to strap the power cord to the extended tail of the connector.
- Page 15 The length and preparation of exposed wires is important (see the second and third audio RS-232 Device NOTES connector on page 7 for details). Figure 7. RS-232 Connector Wiring DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Installation and Operation...
-
Page 16: Operation
If the other devices are not turned on before the video source, the image may not appear. DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Installation and Operation... -
Page 17: Reference Information
(voir Déconnecter la mise à la terre). The 1-inch high, quarter rack width DTP HDMI 4K 230 transmitter or receiver can be placed on a table, mounted in a rack, or mounted under a desk or table. The receiver can also be mounted on a projector bracket. -
Page 18: Ul Guidelines For Rack Mounting
UL Guidelines for Rack Mounting The following Underwriters Laboratories (UL) guidelines pertain to the installation of the DTP HDMI 4K 230 enclosure into a rack: CAUTION: Risk of minor personal injury: • Elevated operating ambient temperature — If the equipment is installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. -
Page 19: Disconnecting The Ground
NOTE: Once you have removed the ground jumpers, the DTP HDMI 4K 230 cannot extend analog audio and one unit cannot remotely power the other. No analog audio is output and each unit requires a local power supply. - Page 20 7. Obtain a second 12 V power supply (one supply is provided with the transmitter and normally powers both units), and locally power both units (see Power supply wiring on page 8). DTP HDMI 4K 230 Tx/Rx Transmitter and Receiver • Reference Information...
- Page 21 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
