- Page 1 User Guide HDMI Extenders DTP HDMI 4K D Series HDMI Twisted Pair Extender Transmitters and Receivers 68-2366-01 Rev. F 01 19...
- Page 2 Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano WARNING: This symbol, , when used on the product, is intended to AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad alert the user of the presence of uninsulated dangerous voltage within avvertire l’utente della presenza di tensione non isolata pericolosa the product’s enclosure that may present a risk of electric shock.
- Page 3 安全記事 • 繁體中文 안전 지침 • 한국어 警 告 경고: 이 기호 가 제품에 사용될 경우, 제품의 인클로저 내에 있는 若產品 上使 用此 符 號 ， 是 為了提 醒 使 用者，產品 機 殼內 存 在 著 접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을 可能會導致觸電之風險的未絕緣危險電壓。...
- Page 4 • Risque de dommages matériels. NOTE: A note draws attention to important information. Copyright © 2017-2019 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks( ®...
-
Page 6: Table Of Contents
Power Supply Wiring ........11 RS-232 and IR Connector Wiring ..... 13 Operation ............14 Transmitter Power Indicator ......14 Receiver Power Indicator ......14 System Operation ......... 14 Ground Loops ..........15 DTP HDMI 4K D Series Transmitter and Receiver • Contents... -
Page 8: Introduction
Figure 1. Typical Transmitter and Receiver Application A DTP HDMI 4K D Series system consists of a transmitter (Tx) and a receiver (Rx). The pair can handle a single HDMI digital video signal and a bidirectional RS-232 or IR link. -
Page 9: Twisted Pair Cable Advantages
10 for more information). NOTE: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201 cable to link the transmitter and receiver. The DTP HDMI 4K D Series Tx/Rx do not work properly with these cables. Control communications The RS-232 or infrared (IR) communications are pass-through only. -
Page 10: Installation And Operation
Installation and Operation This section describes the installation and the operation of the DTP HDMI 4K D Series, including: • Mounting the Transmitter or Receiver • Transmitter Connections • Receiver Connections • Twisted Pair Recommendations for DTP Communication • Power Supply Wiring •... -
Page 11: Site Preparation And Wall Box Installation
flush with edge of box. Cable Clamp -2 3 D IO Signal Output Extron Cable DTP HDMI 4K D Decorator-Style Faceplate Figure 2. Installing the Wall Box and Mounting the Unit DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 12: Mud Ring Installation
3. Follow steps 6 through 9 of above, and Final Installation on the next page. Wall Mud Ring Figure 3. Installing the Mud Ring DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 13: Final Installation
Audio input — Connect an unbalanced stereo audio source to this 3.5 mm mini stereo jack. Figure 5 shows how to wire the audio plug. Left (+) Ring Right (-) Sleeve ( ) Figure 5. Audio Input Connector Wiring DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 14: Transmitter Rear Panel
Do not connect these outputs to a telecommunications or computer data network. • Ne connectez pas ces appareils à des données informatiques ou à un réseau de télécommunications. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 15: Receiver Connections
2-pole connector (see Power Supply Wiring on page 11 to wire the power connector) or the power input connector on the transmitter (see Figure 6, on the previous page). DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 16: Receiver Front Panel
3.5 mm, 5-pole captive screw connector for bidirectional RS-232 communication (see RS-232 and IR Connector Wiring on page 13 to wire the connector). NOTE: The RS-232 connector can also transmit one-way modulated IR signals. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 17: Twisted Pair Recommendations For Dtp Communication
• Loosely place cables and limit the use of tie wraps or hook-and-loop fasteners. • Separate twisted pair cables from AC power cables. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 18: Power Supply Wiring
Remove power before wiring. ATTENTION : Les deux cordons d’alimentation doivent être tenus à l’écart l’un de l’autre quand l’alimentation est branchée. Couper l’alimentation avant de faire l’installation électrique. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... - Page 19 Si ce produit ne dispose pas de sa propre source d’alimentation électrique, il doit être alimenté par une source d’alimentation de classe 2 ou LPS et paramétré à 12 V et 1.0 A minimum. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation...
-
Page 20: Rs-232 And Ir Connector Wiring
NOTE: Do not tin the power supply leads before installing them in the direct insertion connector. Tinned wires are not as secure in the connectors and could be pulled out. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 21: Operation
If all other devices are not turned on before the video source, the image may not appear. DTP HDMI 4K D Series Transmitter and Receiver • Installation and Operation... -
Page 22: Ground Loops
Ground Loops When installing the DTP HDMI 4K D series of products, be sure to avoid scenarios where the ground potential differs greatly between the locations where the DTP transmitter and DTP receiver are installed. Such situations can cause ground loops, which can result in image drops, no image, or damage to the units. -
