Summary of Contents for HIKVISION DS-7600NI-I2 Series

  • Page 1 Network Video Recorder User Manual...
  • Page 2 ● Products described in this Document, which may include licenses obtained from third parties. Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part ● of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission.
  • Page 3 LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY ●...
  • Page 4 Network Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for pursuant to part 15 of the FCC Rules.
  • Page 5 Network Video Recorder User Manual purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: http://www.recyclethis.info . 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information.
  • Page 6 Network Video Recorder User Manual Applicable Model This manual is applicable to the following models. But not all the functions in this manual are supported for each model. Table 1-1 Applicable Model Series Model DS-7600NI-I2 DS-7608NI-I2 DS-7616NI-I2 DS-7632NI-I2 DS-7600NI-I2/P DS-7608NI-I2/8P DS-7616NI-I2/16P DS-7632NI-I2/16P DS-7700NI-I4...
  • Page 7 Network Video Recorder User Manual Series Model DS-7732NI-M4/16P DS-7732NI-M4/24P DS-9600NI-M8 DS-9616NI-M8 DS-9632NI-M8 DS-9664NI-M8 DS-96128NI-M8 DS-9600NI-M8/R DS-9616NI-M8/R DS-9632NI-M8/R DS-9664NI-M8/R DS-96128NI-M8/R DS-9600NI-M16 DS-9616NI-M16 DS-9632NI-M16 DS-9664NI-M16 DS-96128NI-M16 DS-9600NI-M16/R DS-9616NI-M16/R DS-9632NI-M16/R DS-9664NI-M16/R DS-96128NI-M16/R DS-7600NXI-I2/S DS-7608NXI-I2/S DS-7616NXI-I2/S DS-7632NXI-I2/S DS-7600NXI-I2/P/S DS-7608NXI-I2/8P/S DS-7616NXI-I2/16P/S DS-7632NXI-I2/16P/S DS-7700NXI-I4/S DS-7716NXI-I4/S DS-7732NXI-I4/S DS-7700NXI-I4/P/S DS-7716NXI-I4/16P/S DS-7732NXI-I4/16P/S...
  • Page 8 Network Video Recorder User Manual Series Model DS-8632NXI-I8/S DS-8664NXI-I8/S DS-8600NXI-I8/24P/S DS-8632NXI-I8/24P/S DS-9600NXI-I8/S DS-9616NXI-I8/S DS-9632NXI-I8/S DS-9664NXI-I8/S iDS-7600NXI-M1/X iDS-7608NXI-M1/X iDS-7616NXI-M1/X iDS-7600NXI-M2/X iDS-7608NXI-M2/X iDS-7616NXI-M2/X iDS-7632NXI-M2/X iDS-7600NXI-M2/P/X iDS-7608NXI-M2/8P/X iDS-7616NXI-M2/16P/X iDS-7700NXI-M4/X iDS-7716NXI-M4/X iDS-7732NXI-M4/X iDS-7700NXI-M4/16P/X iDS-7716NXI-M4/16P/X iDS-7732NXI-M4/16P/X iDS-9632NXI-M8/X iDS-9632NXI-M8/X iDS-9664NXI-M8/X iDS-96128NXI-M8/X iDS-9600NXI-M8R/X iDS-9632NXI-M8R/X iDS-9664NXI-M8R/X iDS-96128NXI-M8R/X iDS-9600NXI-M16/X iDS-9632NXI-M16/X iDS-9664NXI-M16/X iDS-9600NXI-M16R/X...
  • Page 9 Network Video Recorder User Manual Safety Instruction Proper configuration of all passwords and other security settings is the responsibility of the ● installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations ●...
  • Page 10 Network Video Recorder User Manual Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: The device is designed for indoor use only. Install it in a well-ventilated, dust-free environment ● without liquids. Ensure recorder is properly secured to a rack or shelf.
  • Page 11 Network Video Recorder User Manual For the device with sticker , pay attention to the following cautions: CAUTION: Hot ● parts! Do not touch. Burned fingers when handling the parts. Wait one-half hour after switching off before handling the parts. If the device needs to be installed on the wall or ceiling, ●...
  • Page 12 Network Video Recorder User Manual Content Convention In order to simplify description, please read the following conventions. Recorder or device mainly refers to video recorder. ● IP device mainly refers to network camera (IP camera), IP dome (speed dome), DVS (Digital ●...
  • Page 13 Network Video Recorder User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
  • Page 14 Network Video Recorder User Manual HDD Installation If your device does not support HDD hot swapping, disconnect the power from the device before installing a hard disk drive (HDD). A factory recommended HDD should be used for this installation. Scan the QR code below to view HDD installation videos. Figure 1-1 HDD Installation Bracket Installation Bracket installation is applicable when it requires to remove the device cover, and install HDD on...
  • Page 15 Network Video Recorder User Manual Note Please uninstall the upper layer bracket first before installing HDD on the lower layer bracket. Figure 1-3 Fix HDD 3. Connect the data cable and power cable. Figure 1-4 Connect Cable Note You can repeat the steps above to install other HDDs. 4.
  • Page 16 Network Video Recorder User Manual Figure 1-5 Fix Mounting Ears to HDD 2. Unlock the front panel with the attached key, and press the buttons on both sides of the front panel to open it. Figure 1-6 Open Front Panel 3.
  • Page 17 Network Video Recorder User Manual HDD Case Installation HDD case installation refers to the method that you install the HDD in the case, and then plug the HDD case into the slot. Steps 1. Unlock the front panel with panel key. 2.
  • Page 18 Network Video Recorder User Manual 6. Press the handle until you hear a click. Thus to fix the HDD case. Repeat above steps to install the rest hard disk boxes. 7. Close the front panel, and lock it with the panel key. Fix-on-Bottom Installation Fix-on-bottom installation is applicable when you need to install and fix the HDD on the device bottom.
  • Page 19 Network Video Recorder User Manual Figure 1-12 Fix HDD to Device Bottom 4. Optional: Repeat the steps above to install other HDDs. 5. Reinstall the device cover and fasten screws. xviii...
  • Page 20 Network Video Recorder User Manual Coin/Button Cell Battery Replacement The coin/button cell battery should be replaced when the device has been powered off or placed for a long time, and the system time is incorrect. Before You Start Power off your device. Steps 1.
  • Page 21 Network Video Recorder User Manual What to do next If the system time is incorrect, please go to configure the time.

  • Page 22: Table Of Contents

    Network Video Recorder User Manual Contents Chapter 1 Activate via Local Menu ....................1 Chapter 2 Log In to Your Device ....................3 Chapter 3 User Interface Introduce ..................... 4 Chapter 4 Network Settings ......................6 4.1 Network Parameter Settings ....................6 4.1.1 Configure TCP/IP ......................
  • Page 23 Network Video Recorder User Manual 6.1.2 Add Network Camera Manually .................. 19 6.1.3 Add Network Camera via Custom Protocol ..............20 6.1.4 Add Network Camera through Camera Configuration File ......... 22 6.2 Add Access Control Device ....................22 6.3 Add Audio Device ......................... 22 6.4 Add POS Device ........................
  • Page 24 Network Video Recorder User Manual 11.1 Configure Live View Layout ....................41 11.2 GUI Introduction ........................ 41 11.3 PTZ Control ........................42 Chapter 12 Playback ......................... 44 12.1 GUI Introduction ........................ 44 12.2 Normal Playback ........................ 45 12.3 Event Playback ........................46 12.4 Slice Playback ........................
  • Page 25 Network Video Recorder User Manual 16.3.2 Upload Face Pictures to the Library ................78 Chapter 17 Application Center ....................79 17.1 Human and Vehicle Detection ................... 79 17.2 Person Check-In ......................... 79 17.2.1 Add Check-In Task ..................... 79 17.2.2 Search Check-In Records ................... 80 17.3 Statistic Report ........................
  • Page 26 Network Video Recorder User Manual 24.3.1 Why is there a part of channels displaying “No Resource” or turning black screen in multi-screen live view? ......................94 24.3.2 Why is the video recorder notifying risky password after a network camera is added? ..............................

  • Page 27: Chapter 1 Activate Via Local Menu

    Network Video Recorder User Manual Chapter 1 Activate via Local Menu For the first-time access, you have to set an admin password to activate your device. No operation is allowed before activation. You can also activate the device via web browser, SADP or client software.
  • Page 28 Network Video Recorder User Manual Note After the device is activated, you should properly keep the password. 6. Optional: Draw an unlock pattern. 7. Configure at least one password recovery method. What to do next Follow the wizard to set basic parameters.

  • Page 29: Chapter 2 Log In To Your Device

    Network Video Recorder User Manual Chapter 2 Log In to Your Device You have to log in to your device before operating the menu and other functions. Before You Start Ensure your device is activated. Steps 1. Power on your device. 2.

  • Page 30: Chapter 3 User Interface Introduce

    Network Video Recorder User Manual Chapter 3 User Interface Introduce The device will enter the live view interface after it is powered on. Right click your mouse and select Exit Full Screen through the shortcut menu. Figure 3-1 Main Function Page Figure 3-2 Menu Bar Example Figure 3-3 Human and Vehicle Detection Example of Application Center...
  • Page 31 Network Video Recorder User Manual Table 3-1 Interface Introduction Interface Name Introduction Task Bar The opened applications are listed in the task bar. You can move and close each application tab. Icon introduction： : Main menu. ● : Event center. Event alarms can be searched and viewed. ●...

  • Page 32: Chapter 4 Network Settings

    Network Video Recorder User Manual Chapter 4 Network Settings Network parameters, platform access settings, and network services are configurable. 4.1 Network Parameter Settings You shall configure network parameters before using functions that require network access. 4.1.1 Configure TCP/IP TCP/IP must be properly configured before you operate video recorder over network or access network devices.

  • Page 33: Configure Ddns

    Network Video Recorder User Manual Note Working mode is only available for certain models. 3. Configure network parameters. - IPv4 DHCP If the DHCP server is available, you can enable DHCP to automatically obtain an IP address and other network settings from that server. The maximum transmission unit (MTU) is the size of the largest network layer protocol data unit that can be communicated in a single network transaction.

  • Page 34: Configure Pppoe

    Network Video Recorder User Manual Figure 4-2 DDNS 2. Turn on Enable. 3. Select a DDNS type. 4. Set parameters, including service address, domain name, etc. 5. Click Save. 4.1.3 Configure PPPoE If the device is connected to Internet through PPPoE, you need to configure user name and password accordingly.

  • Page 35: Platform Access Settings

    Network Video Recorder User Manual Steps 1. Go to System → System Settings → Network → Network → Other . 2. Set Multicast parameters. Note When adding device through network video security client, multicast group IP address should ● be the same as the device multicast IP address. For IPv4, it covers Class-D IP ranging from 224.0.0.0 to 239.255.255.255 and it is ●...

  • Page 36: Configure Otap

    4.2.2 Configure OTAP OTAP (Open Thing Access Protocol) is an unified integrated standard and push-pull mode of HikVision protocol in the public network and private network. After OTAP is enabled, other applications may be able to remotely view videos through this protocol.

  • Page 37: Configure Isup

    Network Video Recorder User Manual Steps 1. Go to System → System Settings → Network → Platform Access → OTAP . Figure 4-6 OTAP 2. Turn on OTAP. 3. Set the parameters. 4. Click Save. 4.2.3 Configure ISUP ISUP (Intelligent Security Uplink Protocol) provides APIs, library files, and commands for the third- party platform to access devices such as NVRs, speed domes, DVRs, network cameras, mobile NVRs, mobile devices, decoding devices, etc.

  • Page 38: Configure Sdk Service

    Network Video Recorder User Manual The platform server IP address. Access Server Port The platform server port, ranges from 1024 to 65535. The actual port shall be provided by the platform. Device ID Device ID shall be provided by the platform. Protocol Version ISUP protocol version, only ISUP 5.0 is available.

  • Page 39: Enable Isapi

    Network Video Recorder User Manual 4. Click Save. 4.2.5 Enable ISAPI ISAPI (Internet Server Application Programming Interface) is an open protocol based on HTTP, which can realize the communication between the system devices (e.g., network camera, NVR, etc.). Go to System → System Settings → Network → Platform Access → ISAPI to enable the function. 4.2.6 Configure ONVIF ONVIF protocol allows the connection with third-party cameras.

  • Page 40: Configure Log Server

    Network Video Recorder User Manual we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product 6. Click Save. 4.2.7 Configure Log Server Logs can be uploaded to the log server for backup. Steps 1.

  • Page 41: Configure Rtsp

    Network Video Recorder User Manual Figure 4-11 HTTP(S) 2. Optional: Turn on HTTP or HTTPS. 3. View or edit Port of HTTP or HTTPS. 4. Set HTTP/HTTPS Authentication. Authentication Type Two authentication types are selectable, for security reasons, it is recommended to select Digest as the authentication type.

  • Page 42: Configure Websocket(S)

    Network Video Recorder User Manual Figure 4-12 RTSP 2. Set parameters. Port The port is 554 by default. Authentication Type Two authentication types are selectable, if you select Digest, only the request with digest authentication can access the video stream by RTSP via the IP address. For security reasons, it is recommended to select Digest as the authentication type.
  • Page 43 Network Video Recorder User Manual as multi-address, the Default Route of the device should be in the same network segment as that of the LAN IP address of the router. Steps 1. Go to System → System Settings → Network → Network Service → NAT . Figure 4-13 Port Mapping (NAT) 2.

  • Page 44: Chapter 5 User Management

    Network Video Recorder User Manual Chapter 5 User Management There is a default account for administrator. The administrator user name is admin. Administrator has the permission to add, delete, and edit user. Guest and operator users only have limited permissions. Go to System →...

  • Page 45: Chapter 6 Device Access

    Network Video Recorder User Manual Chapter 6 Device Access The video recorder may be able to access multiple device types, such as network camera, access control device, and alarm device. Please refer to the actual device for the access capability of your video recorder.

  • Page 46: Add Network Camera Via Custom Protocol

    Network Video Recorder User Manual Before You Start Ensure your network camera is on the same network segment with that of your video recorder. ● Ensure the network connection is valid and correct. ● Ensure the network camera is activated. ●...
  • Page 47 Network Video Recorder User Manual Before You Start Ensure the network camera supports RTSP streaming. ● Prepare the URL (Uniform Resource Locator) for getting the main stream or sub-stream of ● network cameras. Steps 1. Go to System → Device Access → Device → Video Device . 2.

  • Page 48: Add Network Camera Through Camera Configuration File

    Network Video Recorder User Manual Note Protocol Name and Path can be automatically generated if you click a brand name below ● Protocol Name. You can disable sub-stream if the camera does not support sub-stream or does not have to ●...
  • Page 49 Network Video Recorder User Manual Steps 1. Go to System → Device Access → Device → POS . 2. Click Add to add a POS device. Figure 6-4 Add POS Device 3. Set the POS device parameters. POS Protocol Universal Protocol You can set the start line identifier, line break tag, and end line tag for the POS overlay characters, and the case-sensitive property of the characters.
  • Page 50 Network Video Recorder User Manual When using UDP connection, the port must be set from 1 to 65535, and the port for each POS machine must be unique. USB-to-RS-232 Connection Configure the USB-to-RS-232 convertor port parameters, including the port serial number, baud rate, data bit, stop bit, and parity.

  • Page 51: Chapter 7 Camera Settings

    Network Video Recorder User Manual Chapter 7 Camera Settings You can configure the added camera, such as privacy mask, image parameters, etc. 7.1 Enable H.265 Stream Access The device can automatically switch to the H.265 stream of IP camera (which supports H.265 video format) for the initial access.

  • Page 52: Configure Video Parameters

    Network Video Recorder User Manual Image Settings Customize the image parameters including the brightness, contrast, and saturation for the live view and recording effect. Exposure Set the camera exposure time (1/10000 to 1 sec). A larger exposure value results in a brighter image.

  • Page 53: Configure Privacy Mask

    Network Video Recorder User Manual Frame Rate It refers to the number of frames captured each second. A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout. I-Frame Interval I-Frame also referred as intra picture, I-Frame is the first frame of every GOP (a video compression technology of MPEG).

  • Page 54: Chapter 8 Device Grouping

    Network Video Recorder User Manual Chapter 8 Device Grouping The added devices can be classified into different customized groups. Steps 1. Go to System → Device Access → Device Grouping . Figure 8-1 Device Grouping 2. Click to add a group. Note After a group is added, you can click to edit/delete it.

  • Page 55: Chapter 9 Storage Management

    Network Video Recorder User Manual Chapter 9 Storage Management 9.1 Manage HDD A newly installed hard disk drive (HDD) must be initialized before using. You can format HDD, repair database, and view HDD status through HDD management interface. Before You Start Ensure the HDD is properly installed to your device.

  • Page 56: Create Disk Array

    Network Video Recorder User Manual across the drives in one of several ways called "RAID levels", based the redundancy and performance required. Caution RAID requires enterprise-level HDDs. The functions in this section are only available for certain models. It is recommended to use the same model and capacity HDDs.

  • Page 57: Rebuild Array

    Network Video Recorder User Manual Figure 9-2 Enable RAID 3. Wait for the device to restart. 4. Go to System → Storage Management → Storage HDD → Array Management again. Figure 9-3 Array Management 5. Create an array. Creation Method Description One-touch Array Click One-touch Array Configuration.

  • Page 58: Delete Array

    Network Video Recorder User Manual Steps 1. Go to System → Storage Management → Storage HDD → Array Management . 2. Rebuild an array. Table 9-2 Rebuilding Method Rebuilding Method Description Auto Rebuild There should be a hot spare disk in the array, and the hot spare disk capacity is not less than the disk with the minimum capacity in the array.

  • Page 59: Configure Storage Mode

    Network Video Recorder User Manual 9.3 Configure Storage Mode Steps 1. Go to System → Storage Management → Storage Mode . Figure 9-4 Storage Mode 2. Select Quota or Group. Quota Each camera or audio device can be configured with an allocated quota for storing videos, pictures, or audios.
  • Page 60 Network Video Recorder User Manual Parameter Name Description Usage Set the usage for eSATA. Tag Video Post-Record After adding a tag to a video, it is the time you set to record after the scheduled time. Note You can click during live view or playback to add a tag.

  • Page 61: Chapter 10 Schedule Configuration

    Network Video Recorder User Manual Chapter 10 Schedule Configuration The device will follow the schedule to store files to the disk. 10.1 Configure Schedule Template After a schedule template is configured, you can use the template as the recording schedule. Steps 1.

  • Page 62: Configure Recording Schedule

    Network Video Recorder User Manual Figure 10-2 Edit Template 3) Select a recording type. For example, Event. 4) Drag the cursor on time bar to draw the schedule. Note After moving the cursor on time bar, you can also click to set specified time ●...
  • Page 63 Network Video Recorder User Manual Figure 10-3 Video Recording Configuration 2. Turn on Enable for a camera. 3. Select a schedule type. Note If you set Record Schedule as Custom, you can drag the cursor on time bar to set customized record schedule, or move the cursor on time bar and click to set specified time schedule.

  • Page 64: Configure Picture Capture Schedule

    Network Video Recorder User Manual Parameter Description Note The channel shall have audio function, or have connected an audio device. ANR (Automatic Network Replenishment) can automatically enable SD card of network camera to save the video in the condition of network disconnection, and can synchronize data after the network is recovered.
  • Page 65 Network Video Recorder User Manual Note If you set Record Schedule as Custom, you can drag the cursor on time bar to set customized record schedule, or move the cursor on time bar and click to set specified time schedule. 4.

  • Page 66: Configure Audio Recording

    Network Video Recorder User Manual 10.4 Configure Audio Recording The device would automatically record audios according to the configured recording schedule. Steps 1. Go to System → Storage Management → Storage Schedule → Audio Recording . 2. Turn on Enable for a channel. 3.

  • Page 67: Chapter 11 Live View

    Network Video Recorder User Manual Chapter 11 Live View 11.1 Configure Live View Layout Live view displays the video image of each camera in real time. Steps 1. Go to Live View. 2. Click at the lower-right corner. 3. Select a window division type, or click Custom to customize a new type as your desire. 4.

  • Page 68: Ptz Control

    Network Video Recorder User Manual Description Channel tool bar. Click to add a tag go the channel. After adding, you ● can go to → Backup → By Tag to search videos by tag. You can select → Show VCA Info to display rule ●...
  • Page 69 Network Video Recorder User Manual Note If the PTZ panel cannot be used, please click to check the settings.

  • Page 70: Chapter 12 Playback

    Network Video Recorder User Manual Chapter 12 Playback 12.1 GUI Introduction You can play back video or audio files. Figure 12-1 Playback Table 12-1 Interface Description Description Area for selecting playback type. Channel list. Calendar for time selection. Channel tool bar. Click to add a tag go the channel.

  • Page 71: Normal Playback

    Network Video Recorder User Manual Description Note In order to use this function, go to Configuration → Device Access → Device Configuration → Device Parameter → Display Info. on Scream to turn on Enable Dual-VCA via web browser, and go to System → Storage Management →...

  • Page 72: Event Playback

    Network Video Recorder User Manual Note Group playback: Select a group in the list, and channels in the group can be played back. 3. Select a date in the calendar. Note The blue triangle at the calendar date corner indicates there are available videos. 4.

  • Page 73: Sub-Period Playback

    Network Video Recorder User Manual Steps 1. Go to Playback → 2. Select a camera from the camera list. 3. Select a date on the calendar. 4. Click Search. The retrieved video will be divided into one-hour slices for playback. 5.

  • Page 74: Chapter 13 Event Center

    Network Video Recorder User Manual Chapter 13 Event Center 13.1 Event Settings 13.1.1 Basic/Generic Event Steps 1. Go to Event Center → → Event Configuration → Basic Event / Generic Event . 2. Select a channel. 3. Select an event type. 4.
  • Page 75 Network Video Recorder User Manual Event Name Event Description Rule Configuration from false alarms, only the selected target(s) can triggered alarms. Video Video tampering Use the tool bar at the Tampering detection triggered an top of image to draw the Detection alarm when the camera detection area.

  • Page 76: Perimeter Protection

    Network Video Recorder User Manual Table 13-2 Linkage Method Description Linkage Method Description Notify Surveillance The device can send an exception or alarm signal to the remote Center alarm host when an event occurs. The alarm host refers to the PC installed with client software (e.g., iVMS-4200, iVMS-5200).
  • Page 77 Network Video Recorder User Manual Steps Note A part of the following steps are only available for certain NVR or camera models. 1. Go to Event Center → → Event Configuration → Perimeter Protection. 2. Select a camera. 3. Optional: Turn on Enable AI by NVR. The device will analyze the video, and cameras only transmit video stream.
  • Page 78 Network Video Recorder User Manual Only the object crossing the configured line from the B side to the A side can be detected. Sensitivity The higher the value is, the more easily the detection alarm can be triggered. Detection Target Select Detection Target as Human or Vehicle to discard alarms which are not triggered by human or vehicle.
  • Page 79 Network Video Recorder User Manual 9. Optional: Set Shield Area when AI by NVR is enabled. After a shield area is set, the device will not analyze target behavior in the area, so that the perimeter protection events will not be triggered within the area.
  • Page 80 Network Video Recorder User Manual Figure 13-2 Intrusion Detection 6. Click Rule Settings to detection rules. 1) Select a rule number. For example, select 1. 2) Click , and click on the image 4 times respectively to draw each point of a quadrilateral area.
  • Page 81 Network Video Recorder User Manual Note If you set Arming Schedule as Custom, you can drag the cursor on time bar to set customized arming schedule, or move the cursor on time bar and click to set specified time schedule. 8.
  • Page 82 Network Video Recorder User Manual Before You Start If your device supports AI by NVR function, and its corresponding functions are required, please go to System → Smart Settings → Algorithm Configuration → Algorithm Management to enable Perimeter Protection algorithm. Steps Note A part of the following steps are only available for certain NVR or camera models.
  • Page 83 Network Video Recorder User Manual Detection Target Select Detection Target as Human or Vehicle to discard alarms which are not triggered by human or vehicle. Detection Target is only available for certain models. 4) Optional: Repeat above steps to draw more rules. Up to 4 rules are supports. 7.
  • Page 84 Network Video Recorder User Manual Configure Region Exiting Detection Region exiting detection detects objects that exit from a predefined virtual region. Before You Start If your device supports AI by NVR function, and its corresponding functions are required, please go to System →...
  • Page 85 Network Video Recorder User Manual 2) Click , and click on the image 4 times respectively to draw each point of a quadrilateral area. 3) Set Sensitivity and Detection Target. Sensitivity The higher the value is, the more easily the detection alarm can be triggered. Detection Target Select Detection Target as Human or Vehicle to discard alarms which are not triggered by human or vehicle.

  • Page 86: Abnormal Behavior Event

    Network Video Recorder User Manual 9. Optional: Set Shield Area when AI by NVR is enabled. After a shield area is set, the device will not analyze target behavior in the area, so that the perimeter protection events will not be triggered within the area.
  • Page 87 Network Video Recorder User Manual Event Name Event Description Rule Configuration region, such as the exhibits on display, and a series of actions can be taken when the alarm is triggered. Fast Moving Fast moving detection is used Detection to detect suspicious running and chasing, over-speed, and fast moving.

  • Page 88: Target Event

    Network Video Recorder User Manual Linkage Method Description Send Email The system can send an email with alarm information to a user or users when an alarm is detected. Alarm Output The alarm output can be triggered by the alarm input, motion detection, video tampering detection, face detection, line crossing detection, and any all other events.
  • Page 89 Network Video Recorder User Manual Event Name Event Description Rule Configuration be triggered when a human face is detected. Face Picture The function compares Comparison detected face pictures with specified list library. Trigger alarm when comparison succeeded. Figure 13-5 Flow Diagram of Face Picture Comparison Target Grading Face grading is used for face picture...
  • Page 90 Network Video Recorder User Manual Event Name Event Description Rule Configuration enough, Non-Real-Time Mode will save the real-time pictures as cache, and process them later when engine has free resource. After enabling this function, all channels will be able to support face picture comparison.

  • Page 91: Thermal Camera Detection

    Network Video Recorder User Manual Linkage Method Description Alarm Output The alarm output can be triggered by the alarm input, motion detection, video tampering detection, face detection, line crossing detection, and any all other events. Record When an alarm is detected, the selected channel would record videos.

  • Page 92: Alarm Input Event

    Network Video Recorder User Manual 7. Click Linkage Method to set linkage methods. Table 13-11 Linkage Method Description Linkage Method Description Notify Surveillance The device can send an exception or alarm signal to the remote Center alarm host when an event occurs. The alarm host refers to the PC installed with client software (e.g., iVMS-4200, iVMS-5200).
  • Page 93 Network Video Recorder User Manual Figure 13-6 Configure Alarm Input Note For example, Local<-1 represents the alarm input number at the device rear panel is 1. 3. Edit Alarm Name. 4. Turn on Enable. 5. Set Quick Disarming. Quick disarming can disable the selected alarm linkage methods in a batch. 6.

  • Page 94: Audio Analysis Event

    Network Video Recorder User Manual 8. Click Linkage Method to set linkage methods. Table 13-12 Linkage Method Description Linkage Method Description Notify Surveillance The device can send an exception or alarm signal to the remote Center alarm host when an event occurs. The alarm host refers to the PC installed with client software (e.g., iVMS-4200, iVMS-5200).
  • Page 95 Network Video Recorder User Manual Event Name Event Description Rule Configuration the scene, such as a Detects a steep sound drop in the scene. sudden increase/ Sensitivity decrease in sound The higher the value is, the easier the detection intensity. alarm can be triggered.

  • Page 96: Linkage Configuration

    Network Video Recorder User Manual 8. Click Save. 13.2 Linkage Configuration Configure parameters for event linkages. Steps 1. Go to Event Center → → Linkage Configuration . 2. Click Email to configure email parameters. Table 13-15 Email Linkage Item Description Server Authentication Enable it if the SMTP server requires user authentication and enter the user name and password accordingly.

  • Page 97: Event Search

    Network Video Recorder User Manual Delay The alarm signal duration. Alarm Status Click Trigger to switch the status. 5. Click Alarm Host to set security control panel parameters. 6. Click Flashing Light Alarm Output to set the camera flashing light. 7.
  • Page 98 Network Video Recorder User Manual Steps 1. Go to Event Center → 2. Click Real-Time Alarm. 3. Select the alarm from the list. If there are too many alarms, click Filter to search and find the alarm. 4. Click Playback, and the alarm recording video would be played back. 5.

  • Page 99: Chapter 14 Search And Backup

    Network Video Recorder User Manual Chapter 14 Search and Backup You can search files according to different searching conditions, including file type, event type, time, tag, etc. The searching results can be exported to another device, such as a USB flash drive. Before You Start Ensure HDD is correctly installed and recording parameters are properly configured.
  • Page 100 Network Video Recorder User Manual Figure 14-2 Searching Result 5. Optional: Perform the following operations. 1 Click to select a file. 2 Click to lock a file. After a file is locked, it will not be overwritten. 3 Click to export a file. 4 Use the tool bar at the top to filter results by channel.

  • Page 101: Chapter 15 Acusearch

    Network Video Recorder User Manual Chapter 15 AcuSearch AcuSearch function firstly extracts pictures of human face or body from a video scene during live view or playback, then compares the extracted picture with recorded videos, and eventually finds out videos that contains the target. Before You Start Ensure your device or camera supports this function.
  • Page 102 Network Video Recorder User Manual Figure 15-2 AcuSearch Result 5. Optional: If the results are not desired, you can adjust parameters like Time Range, Channel, or Similarity to search again. 6. Optional: Select an item from the result list, and its corresponding video would be played back at the right side and be marked with red color.

  • Page 103: Chapter 16 Smart Settings

    Network Video Recorder User Manual Chapter 16 Smart Settings 16.1 Algorithm Management Algorithms are used for device engines to analyze different smart functions. Smart function would be usable after allocating the corresponding algorithm to an engine. Go to System → Smart Settings → Algorithm Configuration → Algorithm Management . The available algorithms would be listed, and you can click the required algorithm to link engine(s).

  • Page 104: Upload Face Pictures To The Library

    Network Video Recorder User Manual Note After a list library, you can move the cursor on the library to edit or delete it. ● You can click Delete in Batch to delete selected libraries, or clear all pictures in the selected ●...

  • Page 105: Chapter 17 Application Center

    Network Video Recorder User Manual Chapter 17 Application Center 17.1 Human and Vehicle Detection The human and vehicle information will be displayed for the selected channel at real-time. Human and vehicle detection should be configured in advance. Go to Event Center → configure.

  • Page 106: Search Check-In Records

    Network Video Recorder User Manual Before You Start A camera for person check-in is properly connected. ● Go to System → Smart Settings → Algorithm Configuration → Algorithm Management . ● Allocate Target Recognition to at least one engine. The list library for check-in comparison is properly configured. Refer to Add a List Library for ●...

  • Page 107: Statistic Report

    Network Video Recorder User Manual 3. Click Figure 17-3 Search Check-In Records 4. Set time. 5. Click Search. 17.3 Statistic Report You can view reports of people counting and heat map. Table 17-2 Statistic Report Introduction Function Icon Condition Description Name People The function must be supported...

  • Page 108: Chapter 18 System Parameter Settings

    Network Video Recorder User Manual Chapter 18 System Parameter Settings System parameters include device name, time, lock screen time, language, etc. Go to System → System Settings → System Configuration to configure parameter. Table 18-1 Parameter Description Type Parameter Name Description Basic Info Lock Screen Time...

  • Page 109: Chapter 19 Hot Spare Device Backup

    Network Video Recorder User Manual Chapter 19 Hot Spare Device Backup Video recorders can form an N+M hot spare system. The system consists of several working video recorders and at least one hot spare video recorder. When a working video recorder fails, the hot spare video recorder would switch into operation, which increases the reliability of the system.
  • Page 110 Network Video Recorder User Manual 4. Go to System → System Management → N+M Hot Spare again. 5. Add working devices to the hot spare system. 6. Add hot spare devices to the hot spare system. 7. Click Save.

  • Page 111: Chapter 20 Configure Exception Event

    Network Video Recorder User Manual Chapter 20 Configure Exception Event Exception events can be configured to take the event hint in the live view interface and trigger alarm output and linkage actions. Steps 1. Go to System → System Settings → Exception . Figure 20-1 Exception Event Configuration 2.
  • Page 112 Network Video Recorder User Manual Linkage Method Description Send Email The system can send an email with alarm information to a user or users when an alarm is detected. Alarm Output The alarm output can be triggered by the alarm input, motion detection, video tampering detection, face detection, line crossing detection, and any all other events.

  • Page 113: Chapter 21 View System Info

    Network Video Recorder User Manual Chapter 21 View System Info Go to System → System Maintenance → System Info → System Info to view the system information.

  • Page 114: Chapter 22 System Maintenance

    Network Video Recorder User Manual Chapter 22 System Maintenance System maintenance functions include log search, schedule reboot, upgrade, etc. 22.1 Schedule Reboot The device will automatically restart according to the schedule. Go to System → System Maintenance → Maintenance → Schedule Reboot to enable the function, and set the reboot schedule.

  • Page 115: Log Info

    Network Video Recorder User Manual 22.4 Log Info Go to System → System Maintenance → Maintenance → Log to search and export log information. Expired Time Settings When the log disk is full, logs that exceed the period will be overwritten. 22.5 Configure Log Server You can upload system logs to the server for backup.
  • Page 116 Network Video Recorder User Manual Tool Name Description After the recorder accessing network, you can use USB flash drive to capture and export network packet. HDD Status Detection You can view the health status of a 4 TB to 8 TB Seagate HDD that generated after October 1, 2017.

  • Page 117: Chapter 23 Security Management

    Network Video Recorder User Manual Chapter 23 Security Management 23.1 Address Filter The address filter decides whether to allow or forbid specific IP/MAC address to get access to your device. Before You Start Log in with the admin account. Steps 1.

  • Page 118: Chapter 24 Appendix

    Network Video Recorder User Manual Chapter 24 Appendix 24.1 List of Applicable Power Adapter Only use power adapters listed below. Power Adapter Model Specifications Manufacturer ADS-26FSG-12 12024EPG 12 V, 2 A Shenzhen Honor Electronic Co., Ltd. MSA-Z3330IC12.0-48W-Q 12 V, 3.33 A Moso Power Supply Technology Co., Ltd.

  • Page 119: Glossary

    Network Video Recorder User Manual 24.2 Glossary Dual-Stream Dual-stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 1080P and the sub-stream having a maximum resolution of CIF.

  • Page 120: Frequently Asked Questions

    Network Video Recorder User Manual Acronym for National Television System Committee. NTSC is an analog television standard used in such countries as the United States and Japan. Each frame of an NTSC signal contains 525 scan lines at 60Hz. Acronym for Network Video Recorder. An NVR can be a PC-based or embedded system used for centralized management and storage for IP cameras, IP Domes and other DVRs.

  • Page 121: Why Is The Video Recorder Notifying Risky Password After A Network Camera Is Added

    Network Video Recorder User Manual 24.3.2 Why is the video recorder notifying risky password after a network camera is added? Reason The camera password is too weak. Solution Change the camera password. Warning We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product.

  • Page 122: Why Is Image Getting Stuck When Playing Back By Single Or Multi-Channel Cameras

    Network Video Recorder User Manual 24.3.6 Why is image getting stuck when playing back by single or multi-channel cameras? Reason HDD read/write exception. Solution Export the video, and play it with other devices. If it plays normally on other device, change your HDD, and try again.

  • Page 123: Notification For Corrosive Gas

    Network Video Recorder User Manual Reason 1. The audio input device does not have a good effect in sound collection. 2. Interference in transmission. 3. The audio parameter is not properly set. Solution 1. Check if the audio input device is working properly. You can change another audio input device, and try again.
  • Page 124 Network Video Recorder User Manual Table 24-2 Common Categories and Sources of Corrosive Gases Category Primary Sources S (Hydrogen Sulfide) Geothermal emissions, microbial activity, oil manufacturing, wood corrosion, wastewater treatment, etc. (Sulfur Dioxide), SO (Sulfur Coal combustion, petroleum products, automobile exhaust, Trioxide) smelting ore, sulfuric acid manufacturing, tobacco combustion, etc.
  • Page 125 UD36044B...

This manual is also suitable for:

Ds-7600ni-i2/p seriesDs-7700ni-i4 seriesDs-7700ni-i4/p seriesDs-7600ni-m1/p seriesDs-7600ni-m2/p seriesDs-7700ni-m4 series ... Show all

Table of Contents
