Keysight Technologies P50 A Series Quick Start Manual

Usb-vector network analyzer

P5000A Series USB-

Vector Network Analyzer

Please use ESD Precautions when handling and operating

System Requirements

Refer

https://www.keysight.com/find/pxiusbvna-firmware

1. Download and install the Keysight IO Libraries Suite

at www.keysight.com/find/iosuite. Follow the installer

prompts.

2. Download the network analyzer software from

https://www.keysight.com/find/pxiusbvna-firmware

webpage.

3. Execute and install the network analyzer software

according to the installer prompts.

4. Shutdown PC once the installation is done.

5. Connect the included USB 3.0 Type C cable to the

P50xxA and the other end of the cable directly to a

USB 3.0 port on a PC (USB 2.0 is not supported).

6. Plug in the AC adapter to the back of the instrument

and then plug it into the AC power.

Quick Start Guide

for the system requirements.

For 4-port P502xA above 20GHz, connect

the control cable and tighten it with the nuts

as shown in the image above.

Table of Contents

Do you have a question about the P50 A Series and is the answer not in the manual?

Page 1 Quick Start Guide P5000A Series USB- Vector Network Analyzer Please use ESD Precautions when handling and operating System Requirements Refer https://www.keysight.com/find/pxiusbvna-firmware for the system requirements. Installation Procedure 1. Download and install the Keysight IO Libraries Suite at www.keysight.com/find/iosuite. Follow the installer prompts.
Page 2 Manuals http://www.keysight.com/manuals/P5000A http://www.keysight.com/support/P5000A Technical support Multiple modules setup Help: Quick Start > Multiport and Multisite Configuration Connector Care http://na.support.keysight.com/pna/connectorcare/Connector_Care.htm Contacting Keysight http://www.keysight.com/find/assist This information is subject to change without notice. © Keysight Technologies 2019-2022 Edition 4, September 2022 www.keysight.com...
