Summary of Contents for Keysight Technologies P5552A
- Page 2 Software. With respect to any technical data as defined by FAR 2.101, pursuant to FAR 12.211 and 27.404.2 and DFARS 227.7102, the U.S. government acquires no Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 3 Keysight Technologies assumes no liability for the customer's failure to comply with these requirements. Product manuals may be available on the Web. Go to www.keysight.com...
- Page 4 Standby (mains supply). The instrument is not completely disconnected from the mains supply when the power switch is in the standby position In position of a bi-stable push switch Out position of a bi-stable push switch Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 5 Indicates hot surface. Please do not touch. Indicates ionizing radiation. Indicates that antistatic precautions should be taken CAT I IEC Measurement Category I CAT II Measurement Category II CAT III Measurement Category III CAT IV Measurement Category IV Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 6 (WEEE) is required, as obligated by the EU DIRECTIVE and other National legislation. Please refer to keysight.com/go/takeback to understand your Trade in options with Keysight in addition to product takeback instructions. Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 7 1 MW of isolation from ground. These techniques for a static-safe work station should not be used when WARNING working on circuitry with a voltage potential greater than 500 volts. Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 8 Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 9 ESD Protection 1 Specifications and Characteristics Features Components Attaching the Auxiliary Bracket to the P5552A PCIe Protocol Analyzer Module Usage Scenarios for PCIe Gen5 Protocol Analyzer Using P5552A Analyzer Module In Conjunction with the P5551A Exerciser Module Specifications Keysight Protocol Analyzer for PCI Express Hardware Guide...
- Page 10 Contents Keysight Protocol Analyzer for PCI Express Hardware Guide...
- Page 11 LTSSM information using the P5500 Protocol Testing application. This chapter provides information on the features, components, and usage scenarios of the P5552A PCIe Gen5 Protocol Analyzer module. Also listed are some of the chief specifications of the Protocol Analyzer module.
- Page 12 Specifications and Characteristics Features This topic describes the features of the Keysight P5552A analyzer card. • It is a standard height, half-length card as described in the PCI Express specification, and fits into every system including blade servers. • It supports Gen1 (2.5 GT/s), Gen2 (5.0 GT/s), Gen3 (8.0 GT/s), Gen4 (16.0 GT/s), and Gen5 (32.0 GT/s) speeds as per PCIe specifications.
- Page 13 Components This topic describes the hardware components of the P5552A Analyzer card. The following images display the front and side views of the Keysight P5552A PCIe Gen5 Analyzer. The hardware components have been labeled in the following images. Figure 1...
- Page 14 Specifications and Characteristics Figure 2 P5552A PCIe Protocol Analyzer - Side View Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 15 If the link is up, then the LEDs are on for only those lanes that are participating in the link. • USB Connector: This component is used to connect P5552A with the controller PC using the USB cable. •...
- Page 16 Attaching the Auxiliary Bracket to the P5552A PCIe Protocol Analyzer Module The Auxiliary Bracket for the Add-In Card (as shown in the photographs above) comes as a separate item in the kit that you receive. Screws are provided to attach this auxiliary bracket to the P5552A PCIe Analyzer module.
- Page 17 Specifications and Characteristics Align the auxiliary bracket in an orientation as shown below. Use the PH1 screw to assemble the bracket with the Analyzer module. The module will look like the following image after assembly. Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 18 Notice the hole alignment of the area highlighted in red in the above image. Rotate the unit to the top side. Locate the three holes as highlighted above and tighten with the provided screws using T10 torx screwdriver. Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 19 Using P5552A Analyzer Module In Conjunction with the P5551A Exerciser Module The P5552A PCIe Gen5 Protocol Analyzer's main task is to capture and analyze the traffic from one or more PCIe devices. In cases where you need to test a single PCIe device, you can use the Analyzer in conjunction with the P5551A PCIe Gen5 Exerciser module, which provides the traffic from the other side.
- Page 20 Specifications and Characteristics For detailed information on how to set up the P5552A analyzer card, refer NOTE to the Installation Guide. Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 21 82 gold-plated pins on the bottom to support 164 pins, a requirement for PCIe x16 slot. Trigger Specifications Trigger output Output impedance 50 ohms Threshold voltage VOH - 2.4V VOL - 0.55V Trigger input Vin Low Min Vin Low Max 0.9V Vin High Min 2.0V Keysight P5552A PCIe Gen5 Analyzer Hardware Guide...
- Page 22 IEC 61010-1 / EN 61010-1 Canada: CSA C22.2 No. 61010-1 USA: UL 61010-1 The P5552A Protocol Analyzer is intended to be used in an R&D WARNING environment and therefore mainly operated as an open instrument. For safe usage, do not operate the Analyzer unattended.
