  • Page 1 INSTRUCTIONS FOR USE CW4938GGC Cooker hood CI41038GGC...

  • Page 2: Table Of Contents

    Contents Pictograms used ........Maintenance ..........Safety ............Cleaning ..........................Replacing the odour/particulate matters Your cooker hood ........(PM2.5) filter ..........Dear customer! ..........Lighting ............Description user interface ......Technical data ..........Cooker hood functions ......... EU Product Sheet ........Operation ............

  • Page 3: Pictograms Used

    Pictograms used The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip, or recommendation WARNING! Warning general danger ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire...

  • Page 4: Safety

    Safety WARNING! READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! Safe use This appliance is only designed for household use. CAUTION: Accessible parts may become hot when used with cooking appliances. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the...
  • Page 5 Safety Do not use the cooker hood if the grease filter has not been fitted properly! Do not lean against the cooker hood. Never use the cooker hood as a working surface unless this is indicated explicitly. Grease and oil are inflammable when overheated. Remain in the cooking area when preparing meals.
  • Page 6 Safety The light emitted by LED lights is very dazzling and can damage the eyes. Do not look directly into the switched on LED lights for longer than 100 seconds. When washing grease filters in the dishwasher it is recommended to use a short, non-intensive programme.

  • Page 7: Your Cooker Hood

    Your cooker hood Dear customer! Welcome to our growing ASKO family! We are proud of our appliances. We hope that this appliance will be an appreciated and dependable aid for many years to come. Please read the operating instructions before use. They include general tips, information about the settings and adjustments you can make, and the best way to take care of your appliance.

  • Page 8: Description User Interface

    Your cooker hood Description user interface 1. Switching on/off and dimming the lighting 2. Reducing air extraction capacity and switching off 3. Grease filter and combi filter cleaning indicator 4. Proximity sensor 5. Display status 6. Proximity sensor 7. Wi-Fi 8.

  • Page 9: Operation

    Operation Switching extraction on and off 1. Touch the + (plus) key. The cooker hood will switch on at the lowest setting. 2. Touch the + (plus) key for a higher fan setting. Touch the + (plus) key for 2 seconds to select the highest setting (boost) (see 'Switch on the boost setting').

  • Page 10: Switching The Light On And Off

    Operation Switching the light on and off 1. Short touch the lighting key. The lighting changes from maximum to minimum strength and vice versa. 2. Long touch the lighting key to set the lighting strength. 3. Short touch the lighting key to turn off the light. Changing the colour temperature You can adjust the lighting temperature.

  • Page 11: Clean Air Function

    Operation Clean Air function The Clean Air function allows you to freshen the air in your kitchen for a maximum of 24 hours at level 1. 1. Switch off the cooker hood. 2. Touch the timer key for approximately 3 seconds. The cooker hood will switch on automatically for 10 minutes every hour at the lowest speed setting.

  • Page 12: Making The Connection Between Cooker Hood And Hob

    Operation Making the connection between cooker hood and hob To operate the cooker hood with the hob, you must make a connection between the hob and the hood. To make the connection, the Connection setup mode of the cooker hood and the hob must be activated.

  • Page 13: Wi-Fi-Connectivity

    Wi-Fi-connectivity Wi-Fi/ConnectLife-app The appliance is fitted with a Wi-Fi module that allows the appliance to connect to a mobile device such as a smartphone or tablet. It offers to monitor the appliance status via the mobile device. NOTE! The monitoring function via mobile device shall not be used to replace the personal supervision of the cooking process directly on the appliance.
  • Page 14 Wi-Fi-connectivity First steps to set up the Wi-Fi connectivity: Within the following steps, the “Connection setup” is performed: 1. Check the “Requirements” as described above. 2. The hood and lights must be switched off. 3. Touch and hold simultaneously the – (minus) and timer key for 3 seconds to enter the Wi-Fi menu.
  • Page 15 Wi-Fi-connectivity ‘P’ is shown on the display. Touch the timer key to enable 'Pairing mode'. The Wi-Fi symbol will flash. This mode will be disabled automatically after 3 minutes. On the ConnectLife-app, use the 'Pairing' or 'Discovery' option of the ConnectLife app to pair another user.
  • Page 16 Wi-Fi-connectivity Wi-Fi troubleshooting Symptom Possible cause Solution Wi-Fi icon not shown. Wi-Fi turned off. Switch on Wi-Fi (see 'Switching on Wi-Fi'). Wi-Fi setup failed. Home network issues. Check that your home network signal is strong and internet connection is working. Home network is not The home network is not on Please check the network settings.

  • Page 17: Maintenance

    Maintenance Cleaning WARNING! Important! For all maintenance, first, switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home's master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least as often as the grease filter). Do not use abrasive cleaning products.

  • Page 18: Replacing The Odour/Particulate Matters (Pm2.5) Filter

    Maintenance Removing cassette filter 1. Switch off the motor and lighting. 2. Push in the latches and open the panel. 3. Open the filter’s access latch. Support the filter with your hand. 4. Remove the filter from the hood. Inserting cassette filter The filter should be placed with the locking mechanism on the front.

  • Page 19: Lighting

    Maintenance 6. Re-tighten the filter holder. 7. Reset the memory by long touching the – (minus) key until the filter indicator goes off. NOTE! More noise is produced when odour filters are used than when the cooker hood is used with an exhaust vent.

  • Page 20: Technical Data

    Technical data EU Product Sheet Data determined according to: Standard EN61591 and Commission Regulations (EU) no. 65/2014 and (EU) no. 66/2014. Type of model CW4938GGC CI41038GGC Trademark ASKO ASKO Annual Energy Consumption (AEC ) [kWh/a] 23.8 25.3 hood Energy efficiency class...

  • Page 21: Compliance Information

    Wi-Fi module Operating frequency range 2412 - 2472 MHz (16 channels) Maximum output power 17.7 dBm EIRP average (calculated) Maximum antenna gain 2.7 dBi Hereby, ASKO declares that the radio equipment type Cooker hood is in compliance with Directive 2014/53/EU.

  • Page 22: Installation

    Installation Safety regulations WARNING! This appliance should only be connected by a registered installer. Always follow the installation instructions in the installation manual provided. Check the appliance for transport damage. Do not connect a damaged appliance. Faulty parts may only be replaced by original parts. The manufacturer can only guarantee that original parts meet safety requirements.
  • Page 23 Installation WARNING! Never open the casing of the appliance. Disconnect the appliance from the mains supply before starting any repair work. We advise you to wear protective gloves when assembling the cooker hood because of the possible sharp edges. The distance between the lowest point of the cooker hood and the supporting surface for the cooking vessels gas hob should be at least 65 cm.

  • Page 24: Preparations For Installation

    Installation Preparations for installation...

  • Page 25: Electrical Connection

    Installation Electrical connection This appliance is manufactured in class I; it must therefore be connected to the earth system. Make sure the supply voltage ratings correspond with those stated on the appliance data plate. The connection to the mains is carried out as follows: BROWN = L phase BLUE = N zero YELLOW/GREEN = Earth...

  • Page 26: Built-In

    Installation Built-in Wall hoods...
  • Page 27 Installation...
  • Page 28 Installation...
  • Page 29 Installation...
  • Page 30 Installation...
  • Page 31 Installation Island hoods...
  • Page 32 Installation...
  • Page 33 Installation...
  • Page 34 Installation...
  • Page 35 Installation...
  • Page 36 Installation...

  • Page 37: Environmental Aspects

    Environmental aspects Tips for energy-efficient cooking with hoods Use a low extractor setting and use the highest setting (boost) if necessary. A well-ventilated kitchen makes the range hood more efficient. Clean filters regularly and replace filters when needed to keep the filter efficiency high, as a saturated filter cannot perform and leads to longer usage times.

  • Page 38: Your Notes

    Your notes...
  • Page 39 Your notes...
  • Page 40 880680 We reserve the right to make changes.
