20V BATTERY INSTALLATION TOOL
GAGE BILT
MADE in USA
ORIGINAL INSTRUCTIONS
GB107 SERIES
GB107 SERIES
GB107
GB107/2
GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE
E-MAIL US FOR A DISTRIBUTOR NEAR YOU.
Includes (1) VP1086
(2Ah Battery)
Includes (2) VP1086
(2Ah Batteries)
44766 Centre Court, Clinton Twp., MI. 48038 USA
Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505
solutions1@gagebilt.com / www.gagebilt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GB107 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gage Bilt GB107 Series

Summary of Contents for Gage Bilt GB107 Series

  • Page 1 Includes (1) VP1086 (2Ah Battery) GB107/2 Includes (2) VP1086 (2Ah Batteries) GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE E-MAIL US FOR A DISTRIBUTOR NEAR YOU. GAGE BILT 44766 Centre Court, Clinton Twp., MI. 48038 USA Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505 MADE in USA solutions1@gagebilt.com / www.gagebilt.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Warranty ..................................... 3 Description and Technical Specifications ..........................4 Description of Functions ................................5 Warnings ..................................... 6 Principle of Operation ................................7 How to set-up the GB107 ..............................8-10 How to use the GB107 ................................11 Maintenance .....................................

  • Page 3: Warranty

    WARRANTY Seller warrants that all goods covered by this catalog will conform to applicable specifications and will replace or repair, EXW our plant, any goods providing defective from faulty workmanship, or material, for 1 year from date of shipment Said warranty to remain in effect if, and only if, such goods are used in accordance with all instructions as to maintenance, operation and use, set forth in manuals and instruction sheets furnished by seller.

  • Page 4: Description And Technical Specifications

    DESCRIPTION WARNING: Any other use is forbidden. The GB107 is a battery operated 20V installation tool designed specifically for the efficient installation of 3/32” (2.4 mm) thru 3/16” (5.0 mm) blind rivets. It weighs just 3.5 lbs. (1.6 kg) and can be operated in any position. It has a .984” (25 mm) fastener setting stroke and a rated pull load of 2,248 lbs.

  • Page 5: Description Of Functions

    DESCRIPTION OF FUNCTIONS Fault Indicator Hanger Hole Mandrel Collection Bottle Nose Assy Nose Tip Actuator Assy Riveting Point Light (white LED) Battery with charging Battery Lock / Release Latch status indication Universal Quick Charger Images may not reflect actual tool GB107 20V BATTERY INSTALLATION TOOL 2/23 REV 8/23...

  • Page 6: Warnings

    SAFETY WARNINGS OPERATING HAZARDS: TERMS AND SYMBOLS 1. Use of tool can expose the operator’s hands to hazards, including crushing, impacts, cuts, abrasions and heat. Wear suitable gloves to protect hands. 2. Operators and maintenance personnel shall be physically able to handle the bulk, - Product complies with requirements weight and power of the tool.

  • Page 7: Principle Of Operation

    PRINCIPLE OF OPERATION When the battery is connected to the tool, operation is controlled by a actuator to the motor. The GB107 incorporates an electronic actuator assembly to send a signal to the motor. When the actuator assembly is depressed, the gear on the motor spins the gear on the gear box assy retracting the nose assembly collet.

  • Page 8: How To Set-Up The Gb107

    HOW TO SET-UP THE GB107 WARNING: Only qualified and trained operators should install, adjust or use the installation power tool for all fasteners. WARNING: Operator MUST read and understand all warnings and cautions. WARNING: It is required that eye protection, hearing protection and safety boots be worn at all times while handling this equipment. WARNING: The users or the user’s employer should assess specific risks that could be present before each use based on their application.
  • Page 9 HOW TO SET-UP THE GB107 Cont. Battery (VP1086): Always make removing the battery (VP1086) from the installation tool your first step before making adjustments, changing parts or overhauling and installing the battery (VP1086) into the tool your last step before using to prevent accidental starting of the tool. The battery (VP1086) has a latch on the front side.
  • Page 10 HOW TO SET-UP THE GB107 Cont. Additional Actuator Assy (VP1572) functions: Auto and Manual mode: a. In Manual mode, hold the actuator assy (VP1572), depressing during setting of the fastener until the mandrel is sheared off. b. In Auto mode, you only have to press the actuator assy (VP1572) briefly and the installation tool controls the fastening process automatically.

  • Page 11: How To Use The Gb107

    HOW TO USE THE GB107 WARNING: Only qualified and trained operators should install, adjust or use the installation power tool for all fasteners. WARNING: Operator MUST read and understand all warnings and cautions. WARNING: It is required that eye protection, hearing protection and safety boots be worn at all times while handling this equipment. WARNING: The users or the user’s employer should assess specific risks that could be present before each use based on their application.

  • Page 12: Maintenance

    * Changing the anvil insert should be done by the maintenance personnel every 25,000 to 50,000 fasteners. * Full inspection should be done every 300,000 fasteners or once a year by qualified trained maintenance personnel or by Gage Bilt. Battery Disposal: Do not throw the battery (VP1086) into the domestic waste, fire or water.

  • Page 13: Troubleshooting

    LED’S turn off and you can continue working. THE INSTALLATION TOOL DOESN’T WORK AND THE GREEN, YELLOW AND RED LED’S COME ON. a) Installation tool is in need of service. Please contact Gage Bilt. Fault Indicator (Red / Yellow/Green LED)

  • Page 14: Parts Lists

    SCREWS FOR MOTOR HOLDER (1 SET=10 PCS) VP1578 VP1087 UNIVERSAL QUICK CHARGER 110V MOTOR 740 COMPLETE VP1579 SCREW FOR MOTOR * Sold Separately GB107 SHOWN ABOVE GB107 SERIES 19a. Mandrel 19b. Mandrel Container-Short S Container L GB107 Includes (1) VP1086 (2Ah Battery) (VP1324)
  • Page 15 This page intentionally left blank GB107 20V BATTERY INSTALLATION TOOL 2/23 REV 8/23...

  • Page 16: Alternate Tools / Accessories

    Pulls a variety of small diameter 3/16” (4.8 mm) diameter. 5/32” (4.0 mm) diameter. 5/32” (4.0 mm) diameter. aerospace fasteners. Process Monitoring. Contact Gage Bilt for nose assembly & fastener options. GB108A GB107A GB108 GB110A Blind rivets 3/32” (2.4 mm) thru Blind rivets 3/32”...

This manual is also suitable for:

Gb107Gb107/2

Table of Contents
