ORIGINAL INSTRUCTIONS
S/N: 1135 AND ABOVE
PLEASE CONTACT GAGE BILT FOR
ALL OTHER SERIAL NUMBERS.
GB713SH
INSTALLATION TOOL
GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE
E-MAIL US FOR A DISTRIBUTOR NEAR YOU.
GAGE BILT
44766 Centre Court, Clinton Twp., MI. 48038 USA
Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505
MADE in USA
solutions@gagebilt.com / www.gagebilt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GB713SH and is the answer not in the manual?

Questions and answers

Summary of Contents for Gage Bilt GB713SH

  • Page 1 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS. GB713SH INSTALLATION TOOL GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE E-MAIL US FOR A DISTRIBUTOR NEAR YOU. GAGE BILT 44766 Centre Court, Clinton Twp., MI. 48038 USA Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505 MADE in USA solutions@gagebilt.com / www.gagebilt.com...
  • Page 2: Table Of Contents

    Description and Technical Specifications ..........................4 Description of Functions ................................5 Safety Warnings ..................................6 Principle of Operation ................................7 How to set up the GB713SH ..............................8 How to use the GB713SH ................................9 Maintenance ..................................... 10 Filling ......................................11 Bleeding ....................................
  • Page 3: Eu Conformity & Warranty

    GAGE BILT DECLARATION OF CONFORMITY MANUFACTURER: Gage Bilt Inc. 44766 Centre Ct. Clinton Twp. Michigan U.S.A. +1(586-226-1500) WE DECLARE THAT THE EQUIPMENT SPECIFIED HEREIN CONFORMS TO THE FOLLOWING DIRECTIVES AND STANDARDS Machinery Directive 2006/42/EC EN ISO 12100:2010 EN ISO 13849-2:2012 EU REPRESENTATIVE Edgar Hausmann GmbH Förster-Busch-Str.
  • Page 4: Description And Technical Specifications

    2.50 lbs. (1.1 kg). The entire split handle installation tool weighs 7.50 lbs. (3.4 kg). It has a .760” (19.3 mm) fastener setting stroke. The GB713SH split handle installation tool operates on 90 to 100 psi. (6.2-6.9 bar) Max. of air pressure, with 90 psi. (6.2 bar) providing maximum efficiency.
  • Page 5: Description Of Functions

    Lever Handle Assembly Hydraulic Hose “Pull” Air Line “RETURN” Manifold-Handle Bleed Screw Handle Assembly Air Inlet Image may not reflect actual tool GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 6: Safety Warnings

    4. Support the weight of the tool in a stand, tensioner or balancer, because a lighter grip can then be used to support the tool. GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 7: Principle Of Operation

    Air Piston moves down Air exhaust Air exhaust Pressurized Oil Pressurized Air Unpressurized Oil Unpressurized Air Images may not reflect actual tool GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 8: How To Set Up The Gb713Sh

    HEAD CYLINDER DEFLECTOR WORK FASTENER LEVER RED SHIPPING PLUG USER QUICK DISCONNECT FITTING AIR INLET AIR HOSE Image may not reflect actual tool GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 9: How To Use The Gb713Sh

    Press lever to start cycle. Release lever as soon as fastener breaks. Repeat steps 1-4. Images may not reflect actual tool or fastener GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 10: Maintenance

    WARNING: Tool must be maintained in a safe working condition at all times and examined on a daily basis for damage or wear. Any repair must be done by qualified personnel trained on Gage Bilt procedures. WARNING: Excessive contact with hydraulic oil and lubricants must be avoided.
  • Page 11: Filling

    (713123) Power Cylinder hole Oil Passage hole O’ring (S832) ***Keep air hole free from oil*** Images may not reflect actual tool. GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 12: Bleeding

    Subtract dimension (A) from dimension (B). If stroke is not consistent within 1/64" (.396 mm) repeat bleeding procedure until stroke met. Gage Bilt offers a depth gage (Pt.# A-1935) to help simplify and more accurately check your tool stroke. Please contact Gage Bilt for more information.
  • Page 13: Troubleshooting

    Selection Chart pg. 20 to select Stroke Limiter) Tighten End Cap onto tool. (See pg. 10 for torque setting) Images may not reflect actual tool GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 14: Overhaul

    Perform overhaul in a clean, well lit area using care not to scratch or nick any smooth surface that comes in contact with an o'ring. Use of Lubriplate® (Gage Bilt part no. 402723) or other lubricant is recommended during reassembly to prevent tearing or distorting of o'rings.
  • Page 15 Reinsert pin (703543) into hole on handle assembly (700343). Re-attach the lever (704345) and tighten set screw (401771). Note: View above shows proper orientation of lever. GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 16 Valve spring installation tool (744251) will facilitate the proper installation of the spring (744144). Valve sleeve (743144) can be pulled out using valve sleeve removal tool (744152). GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 17: Disassembly And Parts Lists

    PARTS LIST GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 18 PARTS LIST GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 19: Dexron® Iii Oil Safety Data (Sds)

    Use material for its intended purpose or recycle if possible. Oil collection services are available for used oil recycling or disposal. Place contaminated materials in containers and dispose of in a manner consistent with applicable regulations. GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 20: Nose Assemblies And Accessories

    GB713SH ACCESSORIES Approved for use on Gage Bilt CE installation tools and/or other manufacturer’s CE approved tools of similar design. (Sold Separately) Grip Gage #269G3 NOSE ASSEMBLY SELECTION CHART For CHERRYMAX® and STRAIGHT CHERRYLOCK® rivets RIGHT ANGLE OFFSET (Sold Separately)
  • Page 21 Accessories Cont. Approved for use on Gage Bilt CE installation tools and/or other manufacturer’s CE approved tools of similar design. (Sold Separately) Catcher Bag-Stem Air Bleeder Assembly #704214 #704153 (Sold Separately) (Sold Separately) Tool Stroke Depth Gage #A-1935 (Sold Separately) Image may not reflect actual gage.
  • Page 22 Hand held weight - 2.00 lbs. (0.9 kg) Entire tool weight - 7.00 lbs. (3.2 kg) Pull load - 4,500 (20.0 kN) GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 23 This page intentionally left blank GB713SH INSTALLATION TOOL S/N: 1135 AND ABOVE Rev. 3/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 24 Riveter Kits Available (Sold Separately) Contact Gage Bilt to customize your riveter kit today. Approved Approved DEXRON® IS A REGISTERED TRADEMARK OF GENERAL MOTORS CORPORATION. LOCTITE® IS A REGISTERED TRADEMARK OF HENKEL CORPORATION. TEFLON® IS A REGISTERED TRADEMARK OF E.I. DUPONT DE NEMOURS & CO. LUBRIPLATE® IS A REGISTERED TRADEMARK OF FISKE BROTHERS REFINING CO. CHERRYMAX® CHERRYLOCK® ARE REGISTERED TRADEMARKS OF CHERRY AEROSPACE.
