Before using the product
Thank you for using the G100 PROFIBUS-DP communication module.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPDP-G100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LS ELECTRIC CPDP-G100

Summary of Contents for LS ELECTRIC CPDP-G100

  • Page 1 Before using the product Thank you for using the G100 PROFIBUS-DP communication module.
  • Page 2 SAFETY PRECAUTIONS SAFETY PRECAUTIONS • Always follow safety instructions to prevent accidents and potentially hazardous situations. • Safety precautions are classified into "WARNING" and "CAUTION," and their meanings are as follows: Improper operation may result in serious personal injury or death. Improper operation may result in minor personal injury or property damage.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 Overview ....................... 1 What is the PROFIBUS-DP Communication Module? ..........1 Package Content ....................... 1 2 LSLV-G100 PROFIBUS-DP Communication Module.......... 2 Technical Specifications .................... 2 PROFIBUS-DP Communication Module Layout ............3 PROFIBUS-DP Connector Specifications ..............4 Installation ........................
  • Page 4 Table of Contents 4.2.6 Number of Para Control settings ............... 16 4.2.7 Para Control 1–8 ..................17 4.2.8 Comm Update .................... 18 4.2.9 Setting PROFIBUS Bit Swap ..............18 5 GSD File (Electronic Data Sheets) ..............19...

  • Page 5: Overview

    PLC and by utilizing other control systems, such as a PC, for controlling the inverter. 1.2 Package Content The product package includes the following components. • PROFIBUS-DP communication module (CPDP-G100): 1 ea • User manual: 1 ea • PROFIBUS connector: 1 ea...

  • Page 6: Lslv-G100 Profibus-Dp Communication Module

    LSLV-G100 PROFIBUS-DP Communication Module 2 LSLV-G100 PROFIBUS-DP Communication Module 2.1 Technical Specifications Type Description Device Type PROFIBUS-DP slave Auto Baud Rate Supported Detect Sync Mode Supported Freeze Mode Supported Max Input Length 8 words Max Output Length 8 words Baud Rate Support 9.6K, 19.2K, 93.75K, 187.5K, 500K, 1.5M, 3M, 6M, 12M Modular Station Supported...

  • Page 7: Profibus-Dp Communication Module Layout

    LSLV-G100 PROFIBUS-DP Communication Module 2.2 PROFIBUS-DP Communication Module Layout Figure 1 PROFIBUS-DP Communication Module...

  • Page 8: Profibus-Dp Connector Specifications

    LSLV-G100 PROFIBUS-DP Communication Module 2.3 PROFIBUS-DP Connector Specifications Figure 2 PROFIBUS Connector PROFIBUS Signal Description Connector None None 24 V Output GND RxD/TxD-P Received/Transmitted Data - Plus CTRL-P Control signal for a repeater DGND Signal GND 5 V for termination resistance 24 V Output - Positive Received/Transmitted Data - RxD/TxD-N...

  • Page 9: Installation

    LSLV-G100 PROFIBUS-DP Communication Module 2.4 Installation Turn off the inverter before configuring the communication network. Both the inverter and the communication module will be damaged if the communication module is installed or removed while the inverter is turned on. Install or remove the communication module after the capacitor inside the inverter is completely discharged.
  • Page 10 LSLV-G100 PROFIBUS-DP Communication Module • Do not install or remove the communication module to or from the G100 inverter while the inverter is turned on. • Install or remove the communication module to or from the G100 inverter only after the electric charge of the capacitor inside the inverter has been completely discharged.

  • Page 11: Network Cable Specifications

    LSLV-G100 PROFIBUS-DP Communication Module 2.5 Network Cable Specifications Item Description Cable Type BC-Bare Copper Insulation PE-Polyethylene Insulation Thickness 0.035 inch Aluminum Foil-Polyester, Shield Tape/Braid Shield Electrostatic Capacity 8,500 pF/ft 150Ω Characteristic Impedance Number of Conductors 2 Cores Table 3 Network Cable Specifications 2.6 Network Cable Length by Baud Rate The total length of a network cable configuration varies depending on the baud rate.

  • Page 12: Operation Status And Led Indicators

    Operation Status and LED Indicators 3 Operation Status and LED Indicators 3.1 LED Indicators The PROFIBUS DP communication module has 3 LED indicators. Figure 3 LED Indicators Color Description Flashes when the communication module is installed to the Green inverter and the power is supplied. ERROR Flashes when a communication module error is detected.

  • Page 13: Device Status By Indicator Signal

    Operation Status and LED Indicators 3.2 Device Status by Indicator Signal Operation Possible Status Resolution Status Cause Check the power supply to the inverter. Power has not been Check if the inverter provided to the inverter has tripped. Power supply or the PROFIBUS-DP Check the failure...
  • Page 14 Operation Status and LED Indicators Operation Possible Status Resolution Status Cause the cable connection and check the termination resistor configuration. A master device has not been assigned, A master device does or the master not exist in the network. device's station ID has been set incorrectly.

  • Page 15: Inverter Parameters

    Inverter Parameters 4 Inverter Parameters 4.1 PROFIBUS-DP Communication Parameter List Code Parameter Setting Default Description Number Name Range Indicates the version of the communication CM-06 FBus S/W Ver module installed to the inverter. Sets up the station ID for the PROFIBUS- CM-07 FBus ID 1–125...

  • Page 16: Profibus-Dp Communication Parameters

    Inverter Parameters 4.2 PROFIBUS-DP Communication Parameters 4.2.1 Communication module Version CM-06 is used to display the version of PROFIBUS-DP communication module installed on the inverter. 4.2.2 Station ID Setting The following parameters are used to set the Station ID for the PROFIBUS-DP communication module.

  • Page 17: Led Indication For Communication Status

    Inverter Parameters 4.2.3 LED Indication for Communication Status CM-09 is used to indicate the operation status of the three LED indicators (NODE, ERROR, CPU) on the PROFIBUS-DP communication module. On the keypad display, the status of the 3 LED indicators are displayed, in an order of blank (reserved), NODE, ERROR, and CPU, from left to right.

  • Page 18: Number Of Para Status Settings

    Inverter Parameters 4.2.4 Number of Para Status settings CM-30 Number of Para Status settings CM-31 Para Status1–8 settings CM-38 CM-94 Comm Update The parameters above are used to determine how much "Para Status" data will be sent to the master device by the inverter through PROFIBUS-DP network communication.

  • Page 19: Para Status 1-8

    Inverter Parameters 4.2.5 Para Status 1–8 The following parameters are used to set the Station ID for the PROFIBUS-DP communication module. CM-30 Number of Para Status settings CM-31 Para Status1–8 settings CM-38 The "Para Status" setting defines which status information will be sent to the master device through PROFIBUS-DP network communication.

  • Page 20: Number Of Para Control Settings

    Inverter Parameters 4.2.6 Number of Para Control settings CM-50 Number of Para Control settings CM-51 Para Control 1–Control 8 settings CM-58 CM-94 Comm Update The parameters above are used to determine how much "Para Control" data will be sent to the master device by the inverter through PROFIBUS-DP network communication.

  • Page 21: Para Control 1-8

    Inverter Parameters 4.2.7 Para Control 1–8 CM-50 Number of Para Control settings CM-51 Para Control 1–Control 8 settings CM-58 The "Para Control" setting defines which control information will be sent to the master device through PROFIBUS-DP network communication. Para Control 1–8 are set in the form of an inverter address. The inverter's common area and keypad parameter addresses are used as the setting values.

  • Page 22: Comm Update

    Inverter Parameters 4.2.8 Comm Update CM-07 Station ID setting CM-30 Number of Para Status settings CM-50 Number of Para Control settings CM-94 Comm Update After changing the Station ID, and the number of Para Status and Para Control, set the "CM-94 (Comm Update)" to "1" to apply the changes to the PROFIBUS-DP communication module.

  • Page 23: Gsd File (Electronic Data Sheets)

    5 GSD File (Electronic Data Sheets) A GSD file includes information about the PROFIBUS-DP communication module. The GSD file is required to utilize the PROFIBUS Configuration Software. You can download the GSD file from the technical support page of LS ELECTRIC website (https://www.lselectric.co.kr).
  • Page 24 After purchasing and installing the product, fill out the following information in detail. This information can be used to get the benefits of a warranty when the product becomes faulty during the warranty period. Date of Maker LS ELECTRIC Co., Ltd. Installation Warranty Model No. CPDP-G100...
  • Page 25 OUT-OF WARRANTY service information The guarantee will not apply in the following cases, even if the guarantee term has not expired. • Damage was caused by misuse, negligence or accident. • Damage was caused by abnormal voltage and peripheral devices’ malfunction (failure).
