Thank you for using our S100 PROFInet option module
 Always follow safety instructions to prevent accidents and potential hazards from occurring.
 Safety precautions are classified into "WARNING" and "CAUTION" and their meanings are as
follows:
WARNING Improper operation may result in serious personal injury or death.
CAUTION Improper operation may result in slight to medium personal injury
or property damage
 The indicated illustrations on the product and in the manual have the following meanings.
Danger may be present. Read the message and follow the instructions carefully.
Particular attention should be paid because danger of an electric shock may be present.
 Keep operating instructions handy for quick reference.
 Read the operating instructions carefully to fully understand the functions of the S100 series
and to use it properly.
 Be cautious, when handling the CMOS components of the communication module.
Static may lead to malfunctioning of the product.
 Turn off the inverter power, when changing the communication cable.
Otherwise, you may damage the module or a communication error may occur.
 Make sure to insert the Communication module connector to the inverter precisely.
Otherwise, you may damage the module or a communication error may occur.
 Check the parameter unit before setting up the parameter.
Otherwise, a communication error may occur.
Safety PRECAUTIONS
CAUTION
S100 PROFInet Option Manual
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LS ELECTRIC S100

  • Page 1 Particular attention should be paid because danger of an electric shock may be present.  Keep operating instructions handy for quick reference.  Read the operating instructions carefully to fully understand the functions of the S100 series and to use it properly.
  • Page 2: Table Of Contents

    Fault Message Counter (PNU[944]) and Fault Number (PNU[947]) .... 24 10 Accessing the S100 Common Parameters using the PROFIdrive Parameters ..................... 28 11 Accessing S100 Inverter Parameters using the PROFInet Record Data Object ......................30 12 Processing the Alarms .................. 31...
  • Page 3: About The Product

    Using a PROFInet connection, the S100 inverter can be controlled and monitored via a PLC sequence program or any master PLC module. In addition, PROFInet is easy to connect, enabling faster installation and easier maintenance.
  • Page 4: Part Names And Installation

    Warning) Connect a communication network after the power supply is off. If PROFInet communication module is removed or installed, the power supply should be switched off. Otherwise, the S100 inverter will be damaged entirely. Take off PROFInet communication module from the product after the power supply is totally discharged.
  • Page 5 S100 PROFInet Option Manual ■ Remove the keypad (3). ■ Unfasten a screw from I/O board and fasten the prepared brass bar(4). ■ Mount PROFInet communication Module and fasten the removed screw(6) and the included screw(7).
  • Page 6 S100 PROFInet Option Manual ■ Install the keypad (8) at first and the communication module cover(9) in order. ■ Install the front cover(10) again And installation is completed. (10) (10)
  • Page 7: Profinet Communication Module Front Panel

    S100 PROFInet Option Manual 2.3 PROFInet Communication Module Front Panel ERROR LINK1 LINK2 Indicator Color Description Status Remarks Abnormal The CPU is not operation operating. Green The communication Flashing Normal module is installed (1 second operation correctly in the intervals) inverter.
  • Page 8 S100 PROFInet Option Manual Indicator Color Description Status Remarks inverter. The communication module failed to boot LINK1 is connected to a network. Normal Green LINK1 is not operation connected to a network Network LINK1 is not transmitting/receiving LINK1/ACT1 data Data transmission...
  • Page 9: Network Connections

    S100 PROFInet Option Manual Network Connections 3.1 Network Cable Contacts Pin No. Signal Description Cable Color Data Transmission (+) White/Yellow Data Transmission (-) Yellow Data Reception (+) White/Green NONE Not Used Blue NONE Not Used White/Blue Data Reception (-) Green...
  • Page 10: Profinet Communication Related Keypad Parameters

    S100 PROFInet Option Manual PROFInet Communication Related Keypad Parameters To operate an S100 inverter using the PROFInet communication module, set DRV-06 (Cmd Source) to [4 Fieldbus]. Set DRV-07 (Freq Ref Src) to [8 Fieldbus] to provide a frequency reference to the inverter using the PROFInet communication module.
  • Page 11 S100 PROFInet Option Manual IP – 3 12 opt para-3 13 opt para-4 IP - 4 14 opt para-5 Subnet Mask - 1 15 opt para-6 Subnet Mask - 2 Subnet Mask – 3 16 opt para-7 17 opt para-8...
  • Page 12: Keypad Parameters Related To Profinet Communication Module

    5.2 DRV Group 5.2.1 [DRV-06] Cmd Source: Command Source Selection Selects the command source for the S100 inverter. Set the parameter to [4 FieldBus] to set PROFInet communication as the command source. 5.2.2 [DRV-07] Freq Ref Src: Frequency Reference Source Selection Selects the frequency reference source for the S100 inverter.
  • Page 13: Com Group

    S100 PROFInet Option Manual 5.3 COM Group 5.3.1 [COM-06] FBus S/W Ver: Communication Module Software Version Automatically detects and displays the software version of the currently installed communication module. 5.3.2 [COM-09] FBus LED: Communication Module Status Indicator (LED) Information Displays the communication module’s status indicator (LED) information on the inverter’s keypad.
  • Page 14 PROFInet network communication, instead of resetting the IP. 5.3.4 [COM-22] Telegram Mode Settings The S100 PROFInet Communication module supports two different types of telegrams. Refer to <7 Supported PROFIdrive Cyclic Telegram> for the supported telegram types and the details.
  • Page 15: Prt Group

    S100 PROFInet Option Manual 5.4 PRT Group 5.4.1 [PRT-12] Lost Cmd Mode: Lost Command Mode Options Select the inverter’s operation mode for a “Lost Command” condition caused by a communication error. The following table lists available operation modes. Settings Description...
  • Page 16: Profidrive Status Diagram

    S100 PROFInet Option Manual PROFIdrive Status Diagram The following diagram shows the operation status that the PROFInet communication module uses. Status Description The communication module cannot be switched ON at S1: Switching On Inhibited the moment. The communication module can be switched ON at any S2: Ready For Switching On moment.
  • Page 17 "SwitchOFF" None (Motor is stopped.) Operation” Switching On” “Ready For “Operation” "OperationEnable" Motor is run. Operation” Motor is stopped (the S100 “Ready For inverter stops the motor “Operation” "OperationDisable" Operation” according to the ADV-8 “Stop Mode” settings). “Switch On Motor is stopped (Free Run “Operation”...
  • Page 18: Supported Profidrive Cyclic Telegram

    S100 PROFInet Option Manual Supported PROFIdrive Cyclic Telegram The S100 communication module supports “Standard” and “Vendor Specific” telegrams. On a PROFInet network, it can exchange cyclic telegrams with a PLC, at a minimum cycle time of 8 ms. Each telegram is expressed as a submodule in PROFInet network communication, and can be assigned to either Slot1 or Subslot 2 at the communication module.
  • Page 19 The motor is operated based on the speed Enable Setpoint reference from the PLC. Forces the motor operation frequency to “0.” Disable Setpoint (0 -> Set to 1 to release fault conditions at the S100 Fault Acknowledge inverter. Jog1 ON/OFF Not supported Jog2 ON/OFF Not supported The S100 inverter is controlled by the PLC’s...
  • Page 20 S100 PROFInet Option Manual The status transition explained in <10. PROFIdrive Operation Diagram> can be performed by setting the four control word bits, from bit 0 to bit 3. For example, setting the four bits to 1 (XXXX XXXX XXXX 1111) changes the status to “Operation.”...
  • Page 21 S100 PROFInet Option Manual 7.2.2 Status Word (ZSW1) Name Value Description Ready for Switch ON (Operation is available.) RDY_ON Not Ready for Switch OFF (Operation is not available.) Bit 0 value of the control word (STW1) RDY_OPERATION that has been input.
  • Page 22 S100 PROFInet Option Manual “bits 0 to 2” and “bit 6” indicate the following communication module status, as explained in <10. PROFIdrive Status Diagram>. Status Word Status “Switching On Inhibited” xxxx xxxx x1xx x000 “Ready For Switching On” xxxx xxxx x0xx x001 “Ready For Operation”...
  • Page 23 S100 PROFInet Option Manual Name Description compatible parameter communication addresses. This bit is set to 1 when more than one bit in the “level type trip information” parameter bit field is set to 1. Bit for displaying “level type trip Otherwise, it is set to 0.
  • Page 24: Supported Profidrive Parameters

    0: Manufacturer (the PROFInet vendor ID “849” for LS ELECTRIC, as defined by the Profibus.org, is displayed (referenced from communication address 0h351). 1. Device Type: “1” is displayed for S100 PROFInet communication module. 2. Version: Displays the software version. E.g.,) “102” for Version 1.2 3.
  • Page 25 Displays the status word (ZSW1) value that is currently input via the PROFInet communication network. The S100 communication module is reset when the parameter value is changed to “1” from “0.” Displays the device name of the S100 PROFInet 61000 communication module.
  • Page 26: Fault Message Counter (Pnu[944]) And Fault Number (Pnu[947])

    S100 PROFInet Option Manual Fault Message Counter (PNU[944]) and Fault Number (PNU[947]) The Fault Message Counter (PNU[944]) parameter value increases by 1 each time an inverter fault occurs, and the fault is saved at the Fault Number (PNU[947]) parameter. The Fault Number (PNU[947]) parameter can save 8 Fault Situations, and each Fault Situation contains 8 Fault Messages.
  • Page 27 S100 PROFInet Option Manual following table. Trip Names Fault Message Overload Trip Underload Trip Inverter Overload Trip E-Thermal Trip Ground Fault Trip Missing Output Phase Trip Missing Input Phase Trip Reserved Reserved NTC Trip Overcurrent Trip Overvoltage Trip External Trip...
  • Page 28 S100 PROFInet Option Manual Trip Names Fault Message Safety B Trip Reserved Reserved Lost Command Keypad Lost Command Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved ADC Error EEPROM Error Watchdog-1 Error Watchdog-2 Error Reserved QueueFull...
  • Page 29 S100 PROFInet Option Manual Trip Names Fault Message Reserved Reserved Reserved Reserved Internal Communication Error between the Inverter and the Option Card...
  • Page 30: Accessing The S100 Common Parameters Using The Profidrive Parameters

    Inverter setting data is assigned to PNU [1001]. PNU [1003] is set to 0. When PNU [1002] is set to 1, the S100 PROFInet communication module references the values assigned at PNU [1000] and PNU [1001] and writes the values to the inverter’s internal parameters.
  • Page 31 Inverter communication address is assigned to PNU [1000]. PNU [1003] is set to 0. When PNU [1002] is set to 2, the S100 PROFInet communication module references PNU [1000] and reads the data saved in the inverter’s internal address pointed by it.
  • Page 32: Accessing S100 Inverter Parameters Using The Profinet Record Data Object

    S100 PROFInet Option Manual Accessing S100 Inverter Parameters using the PROFInet Record Data Object Using the PROFInet Record Data object, you can access the S100 inverter parameters for data reading and writing, without the PROFIdrive communication protocol. The inverter’s parameter data is assigned to the PROFInet Record Data from the index address 0h5000.
  • Page 33: Processing The Alarms

    S100 PROFInet Option Manual Processing the Alarms The S100 communication module sends a PROFInet alarm notification to the PLC when a fault trip occurs, or when it is released. Fault Alarm Packet Details User Channel Slot Subslot Alarm Channel Type...
  • Page 34: Trouble Shooting

    ELECTRIC customer support. ERROR indicator is The hardware is malfunctioning. Contact a service agent turned on, and CPU near you or LS ELECTRIC customer support. indicator is turned off. • Check the connector pins on the communication module ERROR indicator and for bends or other defects.
  • Page 35 S100 PROFInet Option Manual...
  • Page 36 S100 PROFInet Option Manual Installation Maker LS ELECTRIC Co., Ltd. (Start-up) Date LV-S100 PROFInet Option Model No. Warranty Period Board Name Customer Address Information Tel. Name Sales Office Address (Distributor) Tel. Warranty period is 12 months after installation or 18 months after manufactured when the installation date is unidentified.
