PART LIST:
A:Rail Left Section
2PCS
E:Rail Side Connector
Bar
2PCS
I: Slat Connector
20PCS
HARDWARE LIST:
1: Bolt
1/4*35mm
X 20pcs
5: Nut 1/4
X 2psc
ASSEMBLY INSTRUCTION
ITEM NO: 197MMF-850CK
CK METAL BED FRAME
B:Rail Right Section
2PCS
F:Rail End Connector
Bar
2PCS
J:Slat Connector -
Middle
10PCS
2: Bolt
1/4*50mm
X 2pcs
6: Wrench
X 1pc
C:Rail Down Section
4PCS
G:Center Support Rail
2PCS
K:Coverlet
1PC
3: Bolt
1/4*16mm
X 16pcs
7: Ratchet Tool
X 1PC
D:Rail Support Bar
8PCS
H: Slat
24PCS
4: Bolt
3/16*16mm
X 6pcs
Page:1/5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BED BATH & Beyond 197MMF-850CK
Summary of Contents for BED BATH & Beyond 197MMF-850CK
- Page 1 ASSEMBLY INSTRUCTION ITEM NO: 197MMF-850CK CK METAL BED FRAME PART LIST: B:Rail Right Section D:Rail Support Bar C:Rail Down Section A:Rail Left Section 2PCS 8PCS 4PCS 2PCS F:Rail End Connector H: Slat G:Center Support Rail E:Rail Side Connector 24PCS 2PCS...
- Page 2 How to Use the Ratchet Tool (7) 1. Before assembling the furniture, please adjust the lock as needed. Lock on the left Lock on the right to tighten bolts! to loosen bolts! 2. Tighten or loosen bolts. Tighten bolts: Locate the turncap and rotate it clockwise to screw the bolt quickly until it cannot be rotated any more.
- Page 3 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 1 STEP 2 Hardware 1: 16 pcs Hardware 3: 8 pcs STEP 3 Hardware 7: 4 pcs STEP 4 Hardware 4: 6 pcs Page:3/5...
- Page 4 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 5 Hardware 2: 2 pcs Hardware 3: 8 pcs Hardware 5: 2 pcs STEP 6 STEP 7 COMPLETED Page:4/5...
- Page 5 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 8 COMPLETED Page:5/5...
