CHAPTER 1 OVERVIEW

1. Introduction to the chapter

Thank you for choosing the STM32-E407 single board computer from Olimex! This document
provides a user's guide for the Olimex STM32-E407 board. As an overview, this chapter gives the
scope of this document and lists the board's features. The differences between the members of the
STM32-E407 and STM32-H407 boards are mentioned. The document's organization is then
detailed.
The STM32-E407 development board enables code development of applications running on the
microcontroller STM32F407ZGT6, manufactured by STMicrocontrollers.

1.1 Features

 STM32F407ZGT6 Cortex-M4 210DMIPS, 1MB Flash, 196KB RAM, 3×12-bit 2.4 MSPS
A/D, 2×12-bit D/A converters, USB OTG HS and USB OTG HS, Ethernet, 14 timers, 3 SPI,
3 I2C, Ethernet, 2 CANs, 3 12 bit ADCs, 2 12 bit DACs, 114 GPIOs, Camera interface
 JTAG connector with ARM 2x10 pin layout for programming/debugging
 UEXT connector
 2 x USB-OTG
 SD-card
 Input DCDC power supply which allows operation from 6-16VDC source
 Power and User LEDs
 Reset and User buttons
 Arduino shield platform with provided headers
 4 full 20-pin Ports with the external memory bus for add-on modules
 PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
 Dimensions: 10x76 mm (4''x3.40")

1.2 H407 or E407?

The major difference between STM32-E407 and STM32-E407 is that the latter has built-in Ethernet
(physical level transceiver Micrel -
OTG and a number of SMD jumpers on the bottom which help the user to control the multiplexing
on some pins easier. STM32-E407 has 2 x USB-OTG both with a miniUSB interface. STM32-
H407 has 1 x USB-OTG and 1 x USB-HOST with the On-The-Go interfaced by miniUSB and the
HOST by USB type A connector.
Micrel datasheet). STM32-E407 also features an extra USB-
