Configuration Registers - HMS Networks Intesis INMBSDAI001I000 User Manual

INMBSDAI001I000 Modbus RTU Gateway
Register Address Register Address
(protocol address)
26
28
97
1
Available values will depend on the AC unit mode. Check the AC unit model functions in its user manual to find out the possible values for
this register.
2
The order of magnitude and the scale for this register can be adjusted to Celsius x 1°C (default), Celsius x 10°C, or Fahrenheit. See
Considerations on Temperature Registers (page 17)
3
Fahrenheit x 10 is not available.
4
This value is stored in non-volatile memory.
5
This register blocks the remote controller's communication installed in the MD-RC bus (if the remote is installed).
6
For more information, refer to Considerations on Temperature Registers (page
7
If the register is configured as "0: Non-blocked", all commands received from Modbus will be sent to the AC system. If "1: Blocked",
commands from Modbus will only be sent to the AC system if they differ from the previous value (values sent on change).
8
The register applies to firmware version 1.5 onwards.

5.2.2. Configuration Registers

Table 7. Configuration Registers
Register Address
(protocol address)
13
14
15
21
49
50
1
Once the window contact is open, a countdown to switch off the AC Unit will start from this configured value.
Page 16 of 23
(PLC address)
AC unit Left/Right Vane Position
27 0: Auto (default value)
10: Swing
AC Humidification Value
0: Off
1: Low Humidification
29
2: Medium Humidification
3: High Humidification
4: Continuous
Block Periodic Sendings
98
0: Non-blocked (default value)
1: Blocked
for more information.
Register Address
(PLC address)
"Open Window" switch-off timeout
14
0 .. 30 min
Factory setting: 30 min
Modbus RTU Baud rate
2400bps
4800 bps
9600 bps (default)
15
19200 bps
38400 bps
57600 bps
76800 bps
115200 bps
Device Modbus server address
16
1 .. 63
Maximum number of fan speeds
22
Value is always 5
50 Device ID: 0x0701
51 Software version
Description
1
1
4,7,8
17).
Description
1
Modbus Registers
R/W
R, W
R, W
R, W
R/W
R,W
R
R
R
R
R
USER MANUAL Version 1.0.0
