DIP Switch Configuration
Table 5. DIP switch SW3: Modbus server address setting
Address
0
1
2
3
[...]
61
62
63
NOTE
DIP switch configuration will only take effect after a device reboot.
USER MANUAL Version 1.0.0
Binary
0 0 0 0 0 0 X X
1 0 0 0 0 0 X X
0 1 0 0 0 0 X X
1 1 0 0 0 0 X X
[...]
1 0 1 1 1 1 X X
0 1 1 1 1 1 X X
1 1 1 1 1 1 X X
INMBSDAI001I000 Modbus RTU Gateway
SW3
↓ ↓ ↓ ↓ ↓ ↓ X X
↑ ↓ ↓ ↓ ↓ ↓ X X
↓ ↑ ↓ ↓ ↓ ↓ X X
↑ ↑ ↓ ↓ ↓ ↓ X X
[...]
↑ ↓ ↑ ↑ ↑ ↑ X X
↓ ↑ ↑ ↑ ↑ ↑ X X
↑ ↑ ↑ ↑ ↑ ↑ X X
