Summary of Contents for Briteq BTI-BLIZZARD BSW2
-
Page 3: Before Use
FEATURES • BTI-BLIZZARD BSW2 is a powerful HYBRID moving head, based on a 450W white LED module. • IP65 protection and low noise operation: perfect for both outdoor and indoor use! •... -
Page 4: Safety Instructions
• Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ 2/17 BTI-BLIZZARD BSW2 ®... -
Page 5: Overhead Rigging
• Fasten the omega brackets on the bottom of the base by inserting quick-lock fasteners into the holes of the base and tighten fully clockwise. (you should hear or feel a ‘click’) BRITEQ 3/17 BTI-BLIZZARD BSW2 ®... -
Page 6: Electrical Installation
Pin layout XLR-3pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) Pin layout XLR-5pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) ~ Pins4+5 not used. BRITEQ 4/17 BTI-BLIZZARD BSW2 ®... - Page 7 Runmode sACN Auto Custom1 Custom 2 Off* Pan invert Off* Tilt invert Studio Perform Power Live* Off* Blackout Dim4 Option Dim3 Dimmer Dim2 Dim1 Off* 1200Hz* 2400Hz Led PWM 4000Hz 6000Hz 25000Hz DMX Error Save* BRITEQ 5/17 BTI-BLIZZARD BSW2 ®...
- Page 8 Manual All Reset PT Reset Reset Color system Gobo system Other Fixture hours LED use hours Temperature Version Info Network Label System Error … Service … Note: menu items with * are the default values. BRITEQ 6/17 BTI-BLIZZARD BSW2 ®...
- Page 9 • Press the up/down buttons to select the PERFORM option and hit the right button to select. • Use the up/down buttons to select the correct mode STUDIO: Silent mode POWER: Full power mode LIVE: Temperature controlled mode • Press the Right button to confirm. BRITEQ 7/17 BTI-BLIZZARD BSW2 ®...
- Page 10 • Press the right button to open the menu. (Enter the password if prompted) • Press the up/down buttons to select OPTION and hit the right button to select • Press the up/down buttons to select the LOAD PARA option and hit the right button to select. BRITEQ 8/17 BTI-BLIZZARD BSW2 ®...
- Page 11 • Press the Right button to set the values for step 1 Tilt …: Set the desired value for the channel Time: duration of the step between 0-25s Use: Activate/Disable step • Press the right button to confirm. BRITEQ 9/17 BTI-BLIZZARD BSW2 ®...
- Page 12 Displays the RDM information of the fixture RDM UID: 0x2122004C**** (**** = unique number) RDM Label: BTI-BLIZZARD BSW2 SYSTEM ERROR Displays possible system errors SERVICE Used to calibrate the base pan/tilt position • Press the right button to open the menu. (Enter the password if prompted) •...
- Page 13 2. When the bottom is removed you see the empty battery slot. 3. Insert the battery (model: 18650 * 3,7V Li-ion) in the battery slot. Pay attention to the correct direction and polarity. 4. Put the bottom plate back and fix screw the hex screws tightly. BRITEQ 11/17 BTI-BLIZZARD BSW2 ®...
-
Page 14: Dmx Channels
Color macro CMY speed Color wheel Colorwheel fine Rotating gobos Gobo rotation Gobo rotation fine Fixed gobo Animation wheel Animation Rotation Prism Frost Zoom Zoom fine Focus Focus fine Auto focus Dimmer Dimmer fine Strobe Control BRITEQ 12/17 BTI-BLIZZARD BSW2 ®... - Page 15 011-018 Gobo 1 019-026 Gobo 2 027-034 Gobo 3 035-042 Gobo 4 Rotating gobos 043-050 Gobo 5 051-058 Gobo 6 059-066 Gobo 7 067-074 Gobo 1 Shake 075-082 Gobo 2 Shake 083-090 Gobo 3 Shake BRITEQ 13/17 BTI-BLIZZARD BSW2 ®...
- Page 16 201-205 Stop 206-255 Spin CCW Slow-Fast 000-010 Open Frost 011-255 Frost Zoom 000-255 Zoom fine 000-255 Focus 000-255 Focus fine 000-255 000-012 No function 013-039 5 Meter Auto focus 040-066 7 Meter 067-093 9 Meter BRITEQ 14/17 BTI-BLIZZARD BSW2 ®...
-
Page 17: Maintenance
Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. • Clean with a soft cloth using normal glass cleaning products. BRITEQ 15/17 BTI-BLIZZARD BSW2 ®... -
Page 18: Specifications
3pin XLR IN/OUT, RDM compatible, (W-DMX optional) Movement: Pan: 540° Tilt: 210° Beam angle: 3°→ 30° DMX channels used: 22, 26 and 29 Channels Lamp: 450W LED Size: 416 x 358 x 670 mm Weight: 34 kg LUX CHART BRITEQ 16/17 BTI-BLIZZARD BSW2 ®... - Page 19 USER MANUAL V1.0 ENGLISH Color wheel Rotating gobo wheel Static gobo wheel All the information is subject to change without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ 17/17 BTI-BLIZZARD BSW2 ®...
-
