Summary of Contents for Briteq BT-NONAMOVE
-
Page 3: Before Use
• It turns the static BT-NONABEAM into an extremely powerful moving show projector, ready for the biggest shows on the planet! • It takes less than a minute and no tools to install and configure the projector on the BT-NONAMOVE. • No configurations needed: intelligent communication between both units ensures a seamless transformation into a completely new product. -
Page 4: Safety Instructions
• Please use the original packing when the device is to be transported. • Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ BT-NONAMOVE ®... -
Page 5: Overhead Rigging
5. [MENU / ESC] button: Press to enter the setup menu or jump to the higher menu level. 6. ROTARY ENCODER: turn the wheel in both directions to browse the menu items. Press the wheel to select an item. BRITEQ BT-NONAMOVE ®... -
Page 6: Installing The Projector
Installation is VERY easy and fast: • Tilt the installation frame of BT-NONAMOVE over 45° to the back to be sure that all four quick locks (1) are easily accessible and lock it in that position with the TILT lock (3). -
Page 7: Setup Menu
USER MANUAL SETUP MENU The setup menu of the BT-NONAMOVE is deliberately kept very small to allow quick installation with less risk of incorrect settings. The display of the installed BT-NONABEAM is not used: internal communication with the BT-NONAMOVE assures that all settings and information are handled by the BT-NONAMOVE. -
Page 8: Information Menu
Shows actual firmware version information. • Turn and press the encoder wheel to show the information: • 1U + 2U firmware versions of BT-NONAMOVE • Firmware version of the connected BT-NONABEAM • Press the encoder wheel or [MENU/ESC] button to return. -
Page 9: Calibration Menu
Never use Y-splitter cables, this simply won’t work! • Make sure that all units are connected to the mains. • Each unit in the chain has its proper starting address so it knows which commands from the controller it has to decode. BRITEQ BT-NONAMOVE ®... -
Page 10: Maintenance
• The DMX-controller sends out a “discovery command”, all RDM devices respond and send their unique device ID. • The DMX-controller asks each RDM device for some basic data so it knows which devices are connected. The projector will respond: • Device name: BT-NONAMOVE • Manufacturer: Briteq ® • Category: fixture moving yoke •... -
Page 11: Specifications
IP-Rating: IP20 Operating temperature (T 0°C to 45°C Size: see drawing Weight: 13,5 kg Every information is subject to change without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ BT-NONAMOVE ®...
