- Page 1 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
- Page 2 SCH-X403 User’s Manual Revision Date: Jan.16.2024 Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
- Page 3 SCH-X403 User’s Manual Revision Date: Jan.16.2024 Revision History Revision Date (yyyy/mm/dd) Changes V1.0 2024/01/16 First release Packing List Item Description Q’ty SCH-X403 Driver CD SSD Tray Key Rackmount Bracket + Screw 1 set Ordering information SCH-X403 Micro-Grid 10th CPU Fanless Computer with Intel. 10th Gen. Core i3/i5/i7/i9 up to 65W Processor, up to 64G SO-DIMM DDR4, 2 ×...
- Page 4 SCH-X403 User’s Manual Revision Date: Jan.16.2024 RoHS Compliance Perfectron RoHS Environmental Policy and Status Update Perfectron is a global citizen for building the digital infrastructure. We are committed to providing green products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU, to be your trusted green partner and to protect our environment.
-
Page 5: Table Of Contents
SCH-X403 User’s Manual Revision Date: Jan.16.2024 Chapter 1 : Production Introduction ....................... 5 1.1 Specifications ........................... 5 1.2 Front Panel I/O Placement ....................... 6 1.3 Rear Panel I/O Placement ......................7 1.4 Mechanical Dimensions ......................8 Chapter 2 : Rear I/O Ports ........................9 2.1 LAN port LED Indications ...................... -
Page 6: Chapter 1 : Production Introduction
SCH-X403 User’s Manual Revision Date: Jan.16.2024 Chapter 1 : Production Introduction 1.1 Specifications System Intel® 10 Core™ i3/i5/i7/i9 up to 65W processor Memory type DDR4 SO-DIMM up to 64GB Expansion Slot 1 PCI-E 3.0 x16 (Gen3, Support riser card x8 / x8, x8 / x4 / x4) 1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 and CNVi for Wireless... -
Page 7: Front Panel I/O Placement
SCH-X403 User’s Manual Revision Date: Jan.16.2024 Mechanical and Environmental Dimension 362 x 250 x 70 mm ( W x D x H ) Operating Temp. -20 to 60°C Storage Temp. -40°C to 85°C Relative Humidity 5% to 95%, non-condensing Certification... -
Page 8: Rear Panel I/O Placement
SCH-X403 User’s Manual Revision Date: Jan.16.2024 1.3 Rear Panel I/O Placement... -
Page 9: Mechanical Dimensions
SCH-X403 User’s Manual Revision Date: Jan.16.2024 1.4 Mechanical Dimensions... -
Page 10: Chapter 2 : Rear I/O Ports
SCH-X403 series embedded system. 3.1 2.5” Easy swap SSD installation SCH-X403 series supports two 2.5” easy swap SSD • Use Tri-angle security key to open keylock and pull out 2.5” SSD tray. • Put 2.5”SSD on the tray and make sure SSD is fixed and push the tray back. -
Page 11: Chapter 4: Ami Bios Utility
SCH-X403 User’s Manual Revision Date: Jan.16.2024 Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: •... -
Page 12: Navigation Keys
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.2 Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process. Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys. -
Page 13: Main Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.3 Main Screen When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The... -
Page 14: Advanced Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, Super IO Configuration, AMT Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. -
Page 15: Cpu Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.1 CPU Configuration... - Page 16 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
-
Page 17: Chipset Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.2 Chipset Configuration... - Page 18 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
- Page 19 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
-
Page 20: Storage Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.3 Storage Configuration... -
Page 21: Super Io Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.4 Super IO Configuration... - Page 22 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
-
Page 23: Amt Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.5 AMT Configuration... - Page 24 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
- Page 25 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
-
Page 26: Acpi Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.6 ACPI Configuration... -
Page 27: Usb Configuration
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.7 USB Configuration... -
Page 28: Trusted Computing
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.4.8 Trusted Computing... -
Page 29: Hardware Health Event Monitoring Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.5 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed,... -
Page 30: Security Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.6 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. -
Page 31: Boot Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.7 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. - Page 32 SCH-X403 User’s Manual Revision Date: Jan.16.2024...
-
Page 33: Exit Screen
SCH-X403 User’s Manual Revision Date: Jan.16.2024 4.8 Exit Screen...
