Version 1.0
Revision Date: 03.21.2022
THOR100-X4
MIL-STD-810 Military Computer
1U 1/2 Size Intel Xeon E-2276ML
processor, MIL-STD-461 EMI 18-
36V DC-In
Quick Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THOR100-X4 and is the answer not in the manual?

Questions and answers

Related Manuals for Star Lake THOR100-X4

Summary of Contents for Star Lake THOR100-X4

  • Page 1 Version 1.0 Quick Installation Guide Revision Date: 03.21.2022 THOR100-X4 MIL-STD-810 Military Computer 1U 1/2 Size Intel Xeon E-2276ML processor, MIL-STD-461 EMI 18- 36V DC-In...

  • Page 2: Safety Information

    Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 3: Revision History

    Revision Date (yyyy/mm/dd) Changes Version 1.0 2022/03/21 Initial release Packing list THOR100-X4 1U 1/2 Rugged Military System CD (Driver + Quick Installation Guide) Ordering information De Scription] Model Number THOR100X4-D10 MIL-STD Fanless Rugged Computer with Intel® 9th Gen Xeon® E- 2276ML, IP65, with 10 MIL-DTL-D38999 Connectors, Operating Temp.

  • Page 4: Table Of Contents

    Table Contents SAFETY INFORMATION ................................2 LECTRICAL SAFETY ............................................PERATION SAFETY ............................................STATEMENT ....................................2 REVISION HISTORY ..................................3 PACKING LIST ....................................3 ORDERING INFORMATION ............................. 3 TABLE CONTENTS ....................................4 CHAPTER 1: PRODUCT INTRODUCTION ..........................5 • K EATURES ..........................................•...

  • Page 5: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Key Features System Intel® 9 Gen. XEON E-2276ML Processor (12M Cache, Base Frequency 20GHz; Max Turbo Frequency 4.2GHz) Memory Type 4 x DDR4 2666MHz up to 128GB Processor Graphics Intel® UHD Graphics P630 BIOS AMI® BIOS Storage Device 1x M.2 2280 NVMe up to 2TB Digital Input/Output...

  • Page 6: Dimensions

    • Dimensions...
  • Page 7 • Panel Component DC In label (X1) DIO, label (X2) LAN, label (X3) LAN, label (X4) LAN, label (X5) DVI, label (X6) DVI, label (X7) USB 3.0, label (X8) USB 3.0, label (X9) USB 3.0, label (X10)

  • Page 8: Chapter 2: Jumpers And Connectors Locations

    Chapter 2: Jumpers and Connectors Locations D38999 Connector Pin Definitions X1:DC-In X2: DIO...
  • Page 9 X3, X4, X5: LAN X6, X7 DVI...
  • Page 10 X8, X9, X10 USB 3.0...

  • Page 11: Chapter 3: Bios Setup

    3: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 3.1 Starting To enter the setup screens, perform the following steps: • Turn on the computer and press the <Del> key immediately. •...
  • Page 12 The Main BIOS setup screen has two main frames. The left frame displays all the options that can be configured. Grayed-out options cannot be configured; options in blue can. The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is selected in the left frame, it is highlighted in white.
  • Page 13 3.4.1 CPU Configuration Field Name Intel (VMX) Virtualization Technology Default Value [Enabled] Possible Value Disabled Enabled Field Name Active Processor Cores Default Value [A11] Possible Value A11...
  • Page 14 Field Name Hyper-Threading Default Value [Enabled] Possible Value Disabled Enabled 3.4.2 Power & Performance Field Name Intel (R) SpeedStep(tm) Default Value [Enabled] Possible Value Disabled Enabled Field Name Turbo Mode Default Value [Enabled] Possible Value Disabled Enabled Field Name C states Default Value [Disabled] Possible Value Disabled...
  • Page 15 Field Name ME State Default Value [Enabled] Possible Value Disabled Enabled Field Name Manageability Features State Default Value [Enabled] Possible Value Disabled Enabled Field Name AMT BIOS Features Default Value [Enabled] Possible Value Disabled Enabled 3.4.4 AMT Configuration...
  • Page 16 Field Name ASF support Default Value [Enabled] Possible Value Disabled Enabled Field Name USB Provisioning of AMT Default Value [Disabled] Possible Value Disabled Enabled 3.4.4.1 CIRA Configuration Field Name Activate Remote Assistance Process Default Value [Disabled] Possible Value Disabled Enabled 3.4.4.2 ASF Configuration...
  • Page 17 Field Name PET Progress Default Value [Enabled] Possible Value Disabled Enabled Field Name WatchDog Default Value [Disabled] Possible Value Disabled Enabled Field Name ASF Sensors Table Default Value [Disabled] Possible Value Disabled Enabled 3.4.4.3 Secure Erase Configuration...
  • Page 18 Field Name Secure Erase mode Default Value [Simulated] Possible Value Simulated Real Field Name Force Secure Erase Default Value [Disabled] Possible Value Disabled Enabled 3.4.4.4 OEM Flags Settings Field Name MEBx hotkey Pressed Default Value [Disabled] Possible Value Disabled Enabled Field Name MEBx Selection Screen Default Value...
  • Page 19 Field Name Unconfigure ME Default Value [Disabled] Possible Value Disabled Enabled 3.4.4.5 MEBx Resolution Settings Field Name Non-UI Mode Resoultion Default Value [Auto] Possible Value Auto 80x25 100x31 Field Name UI Mode Resolution Default Value [Auto] Possible Value Auto 80x25 100x31 Field Name Graphics Mode Resoultion...
  • Page 20 Field Name Pending operation Default Value [None] Possible Value None TPM Clear 3.4.5 Trusted Computing Field Name Security Device Support Default Value [Enabled] Possible Value Disabled Enabled Field Name SHA-1 PCR Bank Default Value [Enabled] Possible Value Disabled Enabled...
  • Page 21 Field Name SHA256 PCR Bank Default Value [Enabled] Possible Value Disabled Enabled Field Name Pending operation Default Value [None] Possible Value None TPM Clear Field Name Platform Hierarchy Default Value [Enabled] Possible Value Disabled Enabled Field Name Storage Hierarchy Default Value [Enabled] Possible Value Disabled Enabled...
  • Page 22 Field Name Enable ACPI Auto Configuration Default Value [Disabled] Possible Value Disabled Enabled Field Name Enable Hibernation Default Value [Enabled] Possible Value Disabled Enabled Field Name ACPI Sleep State Default Value [S3 (Suspend to RAM)] Possible Value Suspend Disabled S3 (Suspend to RAM) Field Name Lock Legacy Resources Default Value...
  • Page 23 3.4.7 IT8786 Super IO Configuration 3.4.7.1 Secial Port 1 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Field Name COM1 Control Default Value [RS-232] Possible Value Loopback RS-232 RS-485 Half Duplex RS-485/422 Full Duplex...
  • Page 24 3.4.7.2 Secial Port 2 Configuration Field Name Serial Port Default Value [Enabled] Possible Value Disabled Enabled Field Name COM2 Control Default Value [RS-232] Possible Value Loopback RS-232 RS-485 Half Duplex RS-485/422 Full Duplex 3.4.8 Hardware Monitor 3.4.8.1 Smart Fan Function...
  • Page 25 Field Name FAN_CTL Polarity Default Value [Active high] Possible Value Active low Active high Field Name Smoothing control Default Value [4Hz] Possible Value 1Hz 16Hz 3.4.8.2 System Fan Setting...
  • Page 26 Field Name Smart Fan Mode Default Value [Automatic Mode] Possible Value Software Mode Automatic Mode Field Name Smart Fan Mode Default Value [Automatic Mode] Possible Value Software Mode Automatic Mode Field Name System Fan Type Default Value [PWM] Possible Value PWM Field Name Temperature select Default Value...
  • Page 27 Field Name Legacy USB Support Default Value [Enabled] Possible Value Enabled Disabled Auto Field Name XHCI Hand-off Default Value [Enabled] Possible Value Enabled Disabled Field Name USB Mass Storage Driver Support Default Value [Enabled] Possible Value Disabled Enabled Field Name USB transfer time-out Default Value [20 sec]...
  • Page 28 Field Name CSM Support Default Value [Disabled] Possible Value Disabled Enabled 3.4.12 NVMe Configuration...
  • Page 29 3.4.13 Network Stack Configuration Field Name Network Stack Default Value [Disabled] Possible Value Disabled Enabled...
  • Page 30 3.5 Chipset 3.5.1 System Agent (SA) Configuration Field Name Primary Display Default Value [Auto] Possible Value Auto IGFX...
  • Page 31 Field Name Internal Graphics Default Value [Auto] Possible Value Auto Disabled Enabled Field Name GTT Size Default Value [8MB] Possible Value 2MB Field Name Aperture Size Default Value [256MB] Possible Value 128MB 256MB 512MB 1024MB 2048MB Field Name DVMT Pre-Allocated Default Value [32M] Possible Value 0M...
  • Page 32 3.5.2 PCH-IO Configuration 3.5.2.1 PCI Express Configuration Field Name PCIe function swap Default Value [Disabled] Possible Value Disabled Enabled...
  • Page 33 Field Name PCI Express Root Port 1 Default Value [Enabled] Field Name PCI Express Root Port 5 Default Value [Enabled] Field Name PCI Express Root Port 10 Default Value [Enabled] Field Name PCI Express Root Port 11 Default Value [Enabled] Field Name PCI Express Root Port 12 Default Value...
  • Page 34 3.5.2.2 SATA And RST Configuration Field Name SATA Controller(s) Default Value [Enabled] Possible Value Enabled Disabled Field Name SATA Mode Selection Default Value [AHCI] Possible Value AHCI Intel RST Premium With Intel Optane System Acceleration Field Name M.2 Port Default Value [Disabled] Possible Value Disabled Enabled...
  • Page 35 3.5.2.3 Security Configuration Field Name RTC Memory Lock Default Value [Enabled] Possible Value Disabled Enabled Field Name BIOS Lock Default Value [Enabled] Possible Value Disabled Enabled Field Name Force unlock on all GPIO pads Default Value [Disabled] Possible Value Disabled Enabled Field Name PCH LAN Controller...
  • Page 36 3.6 Security 3.6.1 Administrator Password...
  • Page 37 3.6.2 User Password 3.6.3 Secure Boot Field Name Secure Boot Default Value [Disabled] Possible Value Disabled Enabled Field Name Secure Boot Mode Default Value [Custom] Possible Value Standard Custom...
  • Page 38 3.6.3.1 Restore Factory Keys 3.6.3.2 Key Management Field Name Factory Key Provision Default Value [Disabled] Possible Value Disabled Enabled 3.6.3.3 Install factory defaults...
  • Page 39 3.6.3.4 File System...
  • Page 40 3.6.3.5 File System 3.6.3.6 Restore DB defaults 3.6.3.7 Platform Key(PK)
  • Page 41 3.6.3.8 Key Exchange Kesys...
  • Page 42 3.6.3.9 Authorized Signatures 3.6.3.10 Forbidden Signatures...
  • Page 43 3.6.3.11 Authorized TimeStamps 3.6.3.12 OsRecovery Signatures...
  • Page 44 3.7 Boot Field Name Bootup NumLock State Default Value [Off] Possible Value On Field Name Quiet Boot Default Value [Enabled] Possible Value Disabled Enabled Field Name Fast Boot Default Value [Disable Link] Possible Value Disable Link Enabled...
  • Page 45 3.8 Save & Exit 3.8.1 Save Changes and Exit 3.8.1.1 Save & Exit Setup...
  • Page 46 3.8.2 Exit Without Saving 3.8.3 Save & reset...
  • Page 47 3.8.4 Reset Without Saving 3.8.5 Save Setup Values...
  • Page 48 3.8.6 Load Previous Values 3.8.7 Load Optimized Defaults...
  • Page 49 3.8.8 Save Values as User Defaults 3.8.9 Restore User Defaults This page intentionally left blank...
