Optional Extras

There are a range of optional extras
that can be connected to the C-Drive
system as the circumstances require.
The C-Drive system can be adapted
to suit many applications.
For further information see the TMQ
website www.tmq.com.au
Rudder Angle
Indicator
The rudder angle
indicator is a flush
mounted instrument providing a clear
indication of rudder position, which is
critical when docking or manoeuvring
in close quarters.
(Note: Connect with the RFU to the
'Rudder' socket on C-Drive)
Electric Wheel
The TMQ Electric
steering wheel provides
precise, light steering
on any vessel with a power steering
system installed. It simplifies vessel fit
out by eliminating long hydraulic lines
to the helm position
(Note: Connect to the 'Remotes 1&2'
or 'Remote 3' sockets on C-Drive)
Fluxgate Compass
The TMQ Fluxgate
Compass provides the
necessary heading information when
the C-Drive is used as an autopilot.
Note: Connect to the 'Compass'
socket on C-Drive.
28 of 36
remotes provide the freedom to
maintain full control of the autopilot
and steering while moving around the
vessel.
course or heading along with rudder
angle and mode. Note: Connect to
DISPLAY socket on C-Drive.
enabling autopilot control from a
standard PC with serial comm. ports.
(Cable required)
(Note: Connect to DISPLAY
socket on C-Drive)
Steering Lever
Levers allow single handed control
of any size vessel with power
steering. Movement to port or
starboard causes the rudder to follow
proportionally.
or 24 volts DC with 1, 2 or 3 litre
capacity to suit recreational, work
boat or fishing applications.
TMQ C-Drive 5 Manual
Hand Remote or
Active Remote
Hand remotes and Active
AP56 Display
The AP56 head provides
full control of the C-Drive
indicating current
AP1000 Computer
Software
This is a computer
software program
Reversible pumps
Hydraulic pumps
available in either 12
