Testing Procedure - TMQ C-Drive 5 Installation And Service Manual

Initial Inspection and Testing
Confirm power to be connected is the required DC voltage.
Power Supply 12V DC
Power Supply 24V DC
Ensure polarity of the voltage supply is correct.
All electrical connections are correct.
Loose cables are clipped or tied up.
Dockside Tests
Turn steering wheel fully clockwise and visually check that moving and
mechanical parts do not foul; visually check that RFU has moved in
correct direction as indicated on the RFU label on top.
Repeat step 1 for anti-clockwise.
Return steering to centre and ensure RFU is at centre.
Centre electric steering wheel or lever
If drive goes hard over to mechanical stop change motor connection
wiring. (See Trouble Shooting Section)
Check rudder direction follows Wheel or Lever
Check Wheel or Lever provides sufficient rudder movement
Adjust Rudder Limits using a display or computer if required
IMPORTANT: Always initially test system at low speeds first in open water
during calm conditions.
