:: Differential Build
::
Differential Build (Front and Rear)
Racer's Tip:
Fill diff above the cross
pins, below the planet
gears as shown.
:: Differential Build
::
Differential Build (Center)
81379
Diff
Case
81381
Diff Shim
6x8x0.20mm
::
:: Differential Build
Differential Build (Center)
81380
x2
x2
Diff
Crosspin
(Front and Rear) - Bag
(Center) - Bag
- Bag 1.1, 1.2
1.1, 1.2 - Step 5
81385
Outdrive
O-Ring
5.8x1.9mm
91564
8x16x5
Bearing
81012
17mm
Outdrive,
Center Diff
(Center) - Bag
- Bag 1.1, 1.2
1.1, 1.2 - Step 6
x4
x4
81380
Diff Planet
Gear, 10T,
HTC
- Bag 1.1, 1.2
1.1, 1.2 - Step 4
- Step 4
- Step 5
81380
Pin
2.5x12mm
!
Align pin with
groove in sun gear
- Step 6
25202
x4
x4
M3x10mm
FHCS
Front Diff Fluid:
15,000cst #5447
Rear Diff Fluid:
10,000cst #5455
!
Use HTC
Gearset for
center
differential!
81389
Spur Gear,
Plastic, 46T
81381
Diff Shim
6x8x0.20mm
81380
Diff Sun
Gear, 20T,
HTC
81385
Outdrive
O-Ring
5.8x1.9mm
91564
8x16x5
Bearing
81012
17mm
Outdrive,
Center Diff
