Associated Electrics RC8B4.1e Team Kit Manual page 4

4
:: Table of Contents :: Table of Contents
1................... Cover
2................... Introduction
3................... 1:1 Hardware "Fold Out"
4................... Table of Contents
5 - 7 ..............Differentials Build
(Bags 1. 1 , 1.2)
7 - 8..............Shocks Build
(Bag 2. 1 )
9....................Turnbuckles Build
(Bags 3. 1 )
10 - 11.........Steering / Chassis Build
(Bag 4. 1 )
11 - 14........Front Gearbox Build
(Bags 5. 1 , 5.2, 5.3)
14 - 15........Steering Blocks Build
(Bags 6. 1 )
:: Notes :: Notes
This symbol indicates a special
!
note or instruction in the manual.
This symbol indicates a specific
1
build order in the manual.
This symbol indicates a Racers Tip.
Associated Electrics, Inc.
21062 Bake Parkway
Lake Forest, CA 92630
http://www.RC10.com · http://twitter.com/Team_Associated · http://www.instagram.com/teamassociatedrc/ · http://www.facebook.com/TeamAssociated/
16 - 18.........Rear End Build
(Bags 7 . 1 , 7 .2, 7 .3)
19.................Rear Hubs Build
(Bags 8. 1 , 8.2)
20 - 21........Center Bulkhead Build
(Bag 9. 1 )
21 - 22.......Radio Tray Build
(Bag 10. 1 , 11. 1 )
22 - 23.......Battery Tray Build
(Bag 12. 1 )
24.................Wheels / Tires / Body
(Misc.)
25................ Droop Settings
26................ Back Cover
There is a 1:1 hardware foldout page in the
front of the manual. To check the size of a part,
line up your hardare with the correct drawing
until you find the exact size. Each part in the
foldout has a number assigned to it for ordering
replacement parts.
Customer Service
Tel: 949.544.7500
Fax: 949.544.7501
