Associated Electrics RC8B4.1e Team Kit Manual page 10

10
:: Steering / Chassis :: Steering / Chassis Build
81577
RC8B4e
Side
Guards
2
25201 x2 x2
3x8mm
FHCS
81644
RC8B4.1
FWB / RWB
Chassis
:: :: Steering / Chassis Steering / Chassis Build
Racer's Tip:
Use black grease
(#6588) to lube
the bellcrank halves
before installation!
81562
Steering
Link Pivot
Ball
89202
3x12mm
BHCS
:: :: Steering / Chassis Steering / Chassis Build
1.5mm
Build - Bag 4.1 - Bag 4.1 - - Step 1 Step 1
1 31540
3x5mm
FHCS
3x5mm FHCS and
then install 3x8mm
FHCS. Tighten after
all screws are installed
Build - Bag - Bag 4.1 4.1 - - Step 2 Step 2
81084
Servo
Saver
Tube
81516
Steering
Bellcrank
81516
Servo
Saver Arm
Build - Bag - Bag 4.1 4.1 - - Step 3 Step 3
x2 x2
81091
x8 x8
Steering
Post
Loosely attach
x2 x2
81262
4x10mm
FHCS
81083
Servo
Saver
Spring
81084
Servo Saver
Tube Spring
Nut & O-Ring
8680 x4 x4
5x8x2.5mm
Bearing
x2 x2
81084
Servo Saver
Tube Shim
x4 x4
31404
6x10x3mm
Bearing
81516
Steering
Bellcrank
