:: Steering / Chassis
Steering / Chassis Build
x2
x2
25201
3x8mm
FHCS
81518
Steering
Rack
x2
x2
81517
Steering
Bellcrank
Nut
!
3mm hex wrench fits
bellcrank nut hex.
::
:: Front Gearbox
Front Gearbox Build
Build - Bag 5.1, 5.2, 5.3
81468
Diff Pinion
Gear, 44/13
set
:: Front Gearbox
::
Front Gearbox Build
Build - Bag
81381
Diff Shim
13.5x15.8x0.20mm
25620
x2
x2
M3x10mm
SHCS
81510
Anti-Roll
Bar Cap
Build - Bag
- Bag 4.1
4.1 - - Step 4
Step 4
- Bag 5.1, 5.2, 5.3 - - Step 1
81510
Gearbox,
(Inboard)
81510
Dust Cap
- Bag 5.1, 5.2, 5.3
5.1, 5.2, 5.3 - - Step 2
!
STEP 1
81510
Gearbox,
(Outboard)
Step 1
89221
5x4mm
Set Screw
4675
2.5x6mm
FHCS
Step 2
!
STEP 2
81580
RC8B4e
Dogbone
Outdrive,
Front
91559
x2
x2
6x13x5mm
Flanged
Bearing
Racer's Tip:
De-grease and
clean set screw
and cup for best
thread lock.
Step 1:
Add shims on the ring gear
side to TIGHTEN gear mesh.
Subtract shims on this side
to LOOSEN gear mesh.
NOTE:
Start 1x Thick 0.2mm
Step 2:
Add or subtract shims here
to finalize diff side to side
play once gear mesh is
set from Step 1.
Recommended diff "side-to-
side" clearance (gearbox
assembly) 0. 1 0 - 0.25mm.
Start with 1 x 0. 1 mm.
Note:
0. 1 mm shim can be used for
fine tuning of gear mesh
11
