Associated Electrics RC8B4.1e Team Kit Manual page 23

:: Battery Tray :: Battery Tray Build Build - - Bag
!
!!!ALERT!!!
ESC Setup needs motor rotation = REV
Reverse Motor Rotation only
(not included)
6727
Servo
Tape
81572
ESC Tray
:: :: Battery Tray Battery Tray Build Build - - Bag
x2 x2
89216
M4
Locknut
Bag 12.1 12.1 - Step 1 - Step 1
!
Reverse
ESC in
program program
box box
4x10mm
Bag 12.1 12.1 - Step 2 - Step 2
(ESC not
included)
x4 x4
81262
4x10mm
FHCS
x2 x2
81574
Battery Battery
Tray Spacer Tray Spacer
89216
M4
Locknut
!
Use 2s
x2 x2
81262
shorty
battery
only
FHCS
6727
Servo
Tape
81572
ESC Tray
4s Shorty Pack
!
Configuration Configuration
Use 4s
shorty
battery
only
81584
Hook and
Loop Strap
x4 x4
25201
3x8mm
FHCS
81574
Battery
Tray Tray
x4 x4
23
x4 x4
81262
4x10mm
FHCS
