:: Front Gearbox :: Front Gearbox Build Build - Bag
Build left and right side!
31521
2.5x8mm
BHCS
Front Upper
Suspension
Arm Wing
:: :: Steering Blocks Steering Blocks Build Build - Bag 6.1
Build left and right side!
8x16x5mm
81469
FT Universal,
92mm
:: :: Steering Blocks Steering Blocks Build Build - Bag 6.1
Build left and
right side!
!
Tighten pillow ball nut
until pillow ball begins to
bind, then loosen until
pillow ball moves freely.
- Bag 5.1, 5.2, 5.3 - - Step 9 9
!
x3 x3
Add 1.0mm caster clip behind
suspension arm. Adjust final arm
spacing by adding remaining clips
in front of arm until fit is tight and
the arm rotates freely.
81637
81637
Front Upper
Arm, Soft
x4 x4
89214
M4x12mm
FHCS
- Bag 6.1 - - Step 1 Step 1
91565 x2 x2
Bearing,
Flanged
81514
Steering
Block
- Bag 6.1 - - Step 2 Step 2
81067
Pillow
Ball, Steel
x2 x2
81514
Pillow
Ball Cap
81446
Caster Clip,
1.0mm
81446
Caster Clip
81446
Caster Clip
x2 x2
!
!
x2 x2
81070
Pillow
Ball Nut,
Aluminum
81641
Front Upper
B4.1 Hinge
Suspension
Pin, 48mm
Arm Bushing
89221
M5x4mm
Set Screw
81081
89096
Wheel Hex,
Wheel
+0mm
Hex Pin
x2 x2
25202
M3x10mm
FHCS
81640
Steering
Block Arm
+1 deg
