  • Page 2 • Green Slime shock lube (AE Part # 1105) • Needle nose pliers • Hobby knife • Reamer/hole punch • Ride Height Gauge (#1449 recommended) Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 3 Each part in the foldout a special note or has a number assigned to it for ordering instruction in the manual. replacement parts. Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 4 :: Front/Rear Differential Assembly 89115 89120 Diff Diff housing washer 89121 89121 Diff Diff O-Ring 89496 O-Ring Diff 25236 outdrive 8x16mm 16mm bearing :: Front/Rear Differential Assembly (cont.) 89120 89120 Sun gear Diff outdrive Align pin with groove in sun gear :: Front/Rear Differential Assembly (cont.) 89120 Spider...
  • Page 5 :: Front/Rear Differential Assembly (cont.) 89121 89120 Diff Diff 89121 O-Ring washer Diff 89496 O-Ring Diff outdrive 16mm 25236 8x16mm bearing 89113 Diff ring gear :: Front/Rear Differential Assembly (cont.) 89120 89116 Diff Diff outdrive gasket Thin Gasket :: Front/Rear Differential Assembly (cont.) 89120 Sun gear 89208...
  • Page 6 :: Center Differential Assembly 89115 89120 Diff Diff housing washer 89121 89121 Diff Diff O-Ring O-Ring 25236 8x16mm bearing 89496 Diff outdrive 16mm :: Center Differential Assembly (cont.) 89120 Sun gear 89120 Diff 89120 outdrive Spider gear assembly Align pin with groove in sun gear :: Center Differential Assembly (cont.) 89496...
  • Page 7 :: Center Differential Assembly (cont.) 89120 89120 Diff Sun gear washer 89120 Diff 89121 Diff outdrive O-Ring Align pin with groove in sun gear :: Center Differential Assembly (cont.) 89208 3x14mm 89116 fhcs Diff gasket Tighten screws evenly and firmly. Fill with diff fluid to top of gears.
  • Page 8 :: Servo Link Assembly 89078 89267 Straight 32mm steel eyelet turnbuckle 7.5mm 89078 balljoint :: Rear Camber Link Assembly 89076 Camber pivot balls 89269 89076 38mm steel Camber turnbuckle rod end 89076 Camber ball joints 7.7mm Build right and left sides! :: Shock Assembly 89066...
  • Page 9 :: Shock Assembly - (cont.) 89215 Locknut (piston) 89353 Shock piston set (1.3, blank) 89260 89278 Shock shaft, 2.5mm 29mm, (front) piston 89352 washer O-Ring 89261 89358 Shock shaft, 89352 Upper 38mm (rear) Bottom shock tool :: Shock Assembly - (cont.) Short boots for Fill to top with front shocks.
  • Page 10 :: Shock Assembly - (cont.) Front shock: 7mm 89396 Rear shock: 2mm Shock pre-load 89396 clips 89293 Shock Front spring, pre-load silver (3.9lbs) clips (short spring) 89348 Rear spring, 10mm Build two silver (3.3lbs) 89354 (long spring) front and 16mm two rear shock spring cup...
  • Page 11 :: Steering Assembly (cont.) 89016 31404 Servo 6x10mm saver 89117 bearing bolt Diff shim 89015 89016 Servo Servo saver gap setting: saver spring 89015 89016 Servo Servo saver saver bellcrank retainer :: Steering Assembly (cont.) 25204 3x16mm 89272 fhcs Steering rack 89014 Steering...
  • Page 12 :: Steering Assembly (cont.) / Front Gearbox Assembly 89114 Diff pinion 89214 gear 4x12mm 25215 fhcs M3 locknut 25236 8x16mm bearing 89017 Inner gearbox :: Front Gearbox Assembly - (cont.) 89278 89036 2.5mm washer mount Key setscrew onto flat side of shaft. Tighten with no endplay.
  • Page 13 :: Front Gearbox Assembly - (cont.) 89225 89549 3x24mm Front shcs upper arm 89269 38mm 89473 steel Steel turnbuckle shock 89076 standoffs Camber rod ends 89218 3x8mm washer 7.5mm Smooth edge towards 89586 drivers side! Front Build right shock tower and left (front) sides!
  • Page 14 :: Front Suspension Assembly 89102 89105 CVA pin bone 89105 89573 Lightweight u-joint cv axle, steel Axle has additional holes coupler for crosspin to extend Build Two! the life of the Axle. :: Front Suspension Assembly - (cont.) Build right and left sides! Left Side...
  • Page 15 :: Front Suspension Assembly - (cont.) 89029 Note: direction Steering blue block 89206 16 deg bushing 4x10mm (short) bhcs 89032 16 deg. caster 89029 angle bushing Steering block (red) bushing (long) 89207 89032 4x12mm Build right 16 deg. caster bhcs Note: Do not tighten until and left...
  • Page 16 :: Front Suspension Assembly - (cont.) 89039 hinge pin Build right bushing Hinge pin and left bushings sides! (two dot, down) 2 dot 89035 down mount 89228 89218 25215 3x40mm 3x8mm shcs washer locknut :: Front Suspension Assembly - (cont.) Side Side View...
  • Page 17 :: Front Suspension Assembly - (cont.) 25215 locknut 89022 Front bumper 89217 4x14mm fhcs 25204 89214 3x16mm 4x12mm fhcs fhcs :: Rear Gearbox Assembly 89114 89017 Diff pinion Inner gear gearbox Key setscrew onto 25215 flat side of shaft. M3 locknut Tighten with no endplay.
  • Page 18 :: Rear Gearbox Assembly - (cont.) 89039 hinge pin Hinge pin bushing 89211 bushing 3x26mm (2 dot down) fhcs 89258 Chassis 89037 2 dot brace down (rear) mount (C) 89218 25215 89224 3x8mm 3x16mm washer locknut shcs :: Rear Gearbox Assembly - (cont.) 89225 89011 3x24mm...
  • Page 19 :: Rear Gearbox Assembly - (cont.) Diff shims in- stalled to diff, diff installed to 89472 gearbox. Front bulkhead spacer 89224 3x16mm 89117 89017 shcs Diff Outer shim gearbox :: Rear Suspension Assembly 89162 15x21mm bearing 89096 89033 Wheel hex pins carrier 89572...
  • Page 20 :: Rear Suspension Assembly - (cont.) Build right and left sides! 89031 spacers (red) 89575 SC8.2e 31520 dogbone 89041 2.5x6mm (82mm) Outer bhcs hinge pin :: Rear Suspension Assembly - (cont.) 89278 2.5mm washer 89201 89038 2.5x3mm bhcs mount (D) 89218 3x8mm washer...
  • Page 21 :: Rear Suspension Assembly - (cont.) 89202 3x12mm bhcs 89218 3x8mm washer 89592 RC8.2e RTR wing (black) 25192 89540 3x20mm RC8.2 shcs wing mount upper brace 25215 locknut 89540 RC8.2 wing mounts 25215 locknut :: Rear Suspension Assembly - (cont.) 25215 89228 locknut...
  • Page 22 :: Rear Suspension Assembly - (cont.) 25215 locknut 89217 4x14mm fhcs 89214 4x12mm fhcs 25204 3x16mm fhcs :: Center Bulkhead Assembly 89019 Center bulkhead 89122 (top) Brake pads brake pad gap: 4.5mm 89250 Fiber 89122 brake rotor Build Two! Brake bolt...
  • Page 23 :: Center Bulkhead Assembly (cont.) 89226 Do not tighten 3x26mm #89226 3x26mm shcs shcs completely until the next step! 89254 Center diff top plate 89124 Brake 89019 89019 Center Center bulkhead bulkhead (bottom) :: Center Bulkhead Assembly - (cont.) Tighten all screws Tighten all screws Tighten all screws Install dog bones...
  • Page 24 :: Shocks Install 89083 Shock bushing Note the direction of the shock cap when installing onto shock standoffs 25612 M3 locknut with flange Install two front shocks. :: Shocks Install - (cont.) 89454 3x12mm shcs After installation, adjust droop 91069 screw to get a front shock length of 103mm measured center to center Shock mount...
  • Page 25 :: Shocks Install - (cont.) 89454 3x12mm shcs After installation, adjust droop screw to get a rear shock length of 91069 122mm measured center to center Shock mount on the shock cap / shock mount pin. pin, steel :: Radio Tray Assembly 6338 Antenna 89253...
  • Page 26 :: Radio Tray Assembly - (cont.) 89218 25187 31531 Washers 3x14mm 3x6mm 3x8mm bhcs bhcs Transponder Throttle Steering and 3x6mm bhcs not servo servo not inlcluded! 89006 Servo spacers Servo mounts vary per servo manufacturer. Space your servos low to the chassis without touching the bottom.
  • Page 27 :: Radio Tray Assembly - (cont.) 89008 25215 Servo cone 89126 25225 washer locknut 3x3mm collar 89126 Printed here setscrew 89126 Brake bias A - Airtronics Throttle block F - Futaba pivot H - Hitec J - JR 89218 89202 3x8mm 3x12mm washer...
  • Page 28 :: Radio Tray Assembly (cont.) 25203 3x12mm fhcs 89205 3x26mm bhcs 25215 There will be an unused screw hole at the bottom of the receiver box. locknut This will not be used for the RC8.2 :: Radio Tray Assembly (cont.) 0.5mm 89126 Brake...
  • Page 29 :: Radio Tray Assembly (cont.) :: Brake bias adjusters :: 6 :: Rear :: Front :: 2 :: 5 :: 9 :: 1 :: 3 :: 4 ::1 - Turn on transmitter and buggy. Adjust servo ::5 - Pull cams to engage brakes. Set collar ::7 - Set throttle EPA to max.
  • Page 30 :: Air Filter Install Pullstart engine 89142 Air filter outer 25201 element When oiling 3x8mm the filter fhcs 89141 elements, Air filter place both inside a inner plastic bag element and squeeze to help evenly coat 89139 the filter. Air filter 89140 3719 Air filter...
  • Page 31 :: Engine Install (cont.) 25226 4x5mm setscrew 89130 Engine mount 89144 plates Pipe mount 89145 Pipe 25201 89213 wire 3x8mm 4x6mm fhcs fhcs :: Engine Install (cont.) 25226 4x5mm set screw 89207 4x12mm fhcs...
  • Page 32 :: Engine Install (cont.) Pressure line from fuel tank lid to exhaust pipe nipple Fuel line from fuel tank to carburetor :: Engine Install (cont.) 89325 Fuel line clips Adjust angle of carb ball joint to align with Install fuel line clips! throttle servo.
  • Page 33 :: Wheels, Tires, and Body Install Tires: Tires: When gluing tires to wheels, use a Build four fast-curing Tire glue (CA) 89255 (AE Pt#1597). This is available at wheels/ your local hobby shop. Make sure RTR Pre-glued tires to clean the mounting surface of the wheel/tire tire with alchohol for best adhesion.

  • Page 34: Engine Tuning

    :: Building Tips Tires: The tires need to be glued to the wheels using any fast-curing FT Tire glue (CA) (AE Pt#1597). This is available at your local hobby shop. Make sure to clean the mounting surface of the tire with alchohol for best adhesion. Receiver Pack: Your RC8.2 does not come with a receiver pack.
  • Page 35 :: Front End Tips (cont.) Front Camber Link-Outer: The standard short location will work the best for most tracks. Going to the long front link will give you more steering, but can make the car less predictable in bumps and exiting turns. Front Camber Angle: A good starting camber setting is –2 degrees.

  • Page 36: Setup Sheets

    :: Droop Settings (Buggy shown but applicable for all vehicles) Note: Rear hub spacing is not recommended with RTR dog bones. For more adjustability, use CVA’s in place of dog bones. Step 1: With only the bottom of the shocks attatched, the droop screws raised all the way, and the chassis above your working surface so the arms are at full extension, you should be able to easily slide the top of your shock over the standoff screw, while leaving the shock at full extension.
  • Page 37 :: Shocks :: Front and Rear Gear Differential 25612 M3 Locknut With Flange 25236 8x16x5 Bearings 89065 Shock Rod End 89113 Diff Ring Gear, Includes Diff Gasket 89066 Shock O-Rings 89115 Diff Housing 89067 Shock Limiters, Set 89116 Diff Gasket 89083 Shock Bushings 89117...
  • Page 38 :: Top Plate :: Shock Fluid 5420 10 Weight Silicone Shock Fluid 2oz. 2208 Large Hood Pins 5421 20 Weight Silicone Shock Fluid 2oz. 25202 3x10mm FHCS 5422 30 Weight Silicone Shock Fluid 2oz. 25203 3x12mm FHCS 5423 40 Weight Silicone Shock Fluid 2oz.
  • Page 39 :: Front Gearbox 25215 M3 Locknut 89201 89218 89224 25236 8x16x5 Bearing 89278 31531 3x6mm BHCS 89036 89017 FR/RR Gearbox 89039 89035 Arm Mount A 89040 89218 89036 Arm Mount B 89039 Hinge Pin Bushings, Set 89035 89201 89040 Inner Hinge Pin, Set 89114 Diff Pinion Gear 89278...
  • Page 40 :: Rear Gearbox 25215 M3 Locknut 89219 31531 25236 8x16x5 Bearing 31531 3x6mm BHCS 89224 89017 RC8 FR/RR Gearbox, Set 89037 Arm Mount C 89038 Arm Mount D 89472 89039 RC8 Hinge Pin Bushings, Set 31531 89040 Inner Hinge Pin, Set 89017 89114 RC8 Diff Pinion Gear...
  • Page 41 :: Front Shock Tower :: Rear Shock Tower 89039 Hinge Pin Bushings, 1/2/3dot Set 25192 3x20mm SHCS 89202 3x12mm BHCS 25215 M3 Locknut 89218 3x8mm Washer 89011 Body Mount Set 89225 3x24mm SHCS 89218 3x8mm Washer 89473 RC8B Steel Shock Stand-offs 89225 3x24mm SHCS 89586...
  • Page 42 :: Radio Tray 6338 Antenna Tube and Cap 21173 21173 18T Body Clips 25187 3x14mm BHCS 25203 3x12mm FHCS 21173 31531 3x6mm BHCS 89003 RC8 Receiver/Battery Box, Set 6338 89004 RC8 Receiver Box Pads, Set 89005 Aluminum Antenna Mount, Set 89003 89006 RC8 Servo Mount Spacers, Set...
  • Page 43 :: Chassis 25201 3x8mm FHCS 25226 4x5mm Setscrew 89552 89018 RC8 Gearbox Gasket 89022 RC8 Front Bumper 89130 RC8 Engine Mount Plates 89144 RC8 Pipe Mount 89145 RC8 Pipe Mount Wire 89207 4x12mm BHCS 89213 4x6mm FHCS 25201 89224 3x16mm SHCS 89231 3mm Lock Washer 89257...
  • Page 44 :: Wheels / Tires :: Body / Decals 89152 RC8 Wheels (White) 2208 Large Hood Pins 89153 RC8 Wheels (Yellow) 31531 3x6mm BHCS 89255 RTR Pre-Glued Wheel/Tire (White) 89150 RC8 Body w/Window Mask (Clear) 89275 RC8 RTR Body (Black) 89296 RC8 83mm Wheels (White) - Kit 89276 RC8 RTR Body (White)
  • Page 45 :: Clutch :: Exhaust 25237 5x10x4 Bearings 2357 Rear Exhaust Manifold Spring 89127 Clutch Bell, 17T 7733 Exhaust Tubing Coupler 89132 Clutch Bell, 16T - Kit 25094 Header Spring 89133 Clutch Springs 1.0 - Kit 89147 Header Gasket 89134 Clutch Shoes (aluminum) w/ Shims, Set 89175 Black Non-Stick Muffler 89135...
  • Page 46 :: Factory Team and Option Parts :: Factory Team and Option Parts - (cont.) 25392 3mm Blue Locknut, Flanged 89536 RC8.2 Swaybar Pivot Ball w/setscrews 31550 M3 Aluminum Lock Nut 89537 RC8.2 Swaybar Drop Link w/pivots 80930 1/8 Scale Electric Conversion Kit 89541 FT RC8.2 Front Spring Kit 89005...
  • Page 47 :: Reedy Nitro Engines and Parts :: Reedy Batteries Reedy 121VR .21 Off-Road Comp. Nitro Engine AA Alkaline 1.5V (4) Reedy 121VR-ST .21 Comp. Nitro Engine AA 2700mAh NiMH 1.2V Rechargeable Reedy .21 VS Pull Start Nitro Engine Pro RX Battery 1600mAh 7.4V Flat 28000 121 VR Crankshaft Pro RX Battery 1300mAh 6.6V Flat...
  • Page 48 :: 1/8 Kits and RTR’s :: Tools 20501 MGT 4.60 SE RTR (ready-to-run) 1449 Offroad Ride Height Gauge 20502 MGT 8.0 Nitro RTR (ready-to-run) 1541 FT Hex Driver Set, (7 pcs) 20503 Limited Edition MGT 4.60 Nitro RTR, w/flag body 1542 FT .050”...
  • Page 49 :: RePlay Cameras :: Contact Information RP001 Replay XD1080 Complete Camera System RP002 Replay XD720 Complete Camera System Associated Electrics, Inc. RP021 Replay XD1080 Lens Bezel Kit 26021 Commercentre Drive RP022 Replay XD1080 Clear Lens Cover Lake Forest, CA 92630-8853 USA RP023 Replay XD1080 Lens Bezel &...
  • Page 50 :: Notes...
  • Page 51 Driver: RC8.2 RTR Setup Date: Track: Event: Conditions: Rev.1 Setup Sheet Front Suspension Rear Suspension Anti Roll Bar: Steering System: Anti Roll Bar: 2.2mm Black Stock Rack 2.2mm Black 2.5mm Silver Swing Rack 2.5mm Silver 2.8mm Gold Bellcrank Rack 2.8mm Gold 3.0mm Black 3.0mm Black back...
  • Page 52 :: Hardware - 1:1 Scale View Flat Head (fhcs) Cap Head (shcs) Button Head (bhcs) 3x8mm (25201) 2.5x8mm (89222) 2.5x3mm (89201) 3x10mm (25202) 3x8mm (89223) 2.5x6mm (31520) 3x12mm (25203) 3x10mm (25620) 3x6mm (31531) 3x14mm (89208) 3x12mm (89454) 3x10mm (25211) 3x16mm (89224) 3x16mm (89224) 3x12mm (89202) 3x18mm (89209)
  • Page 53 Driver: Date: Track: Event: Conditions: Rev.1 Setup Sheet Front Suspension Rear Suspension Anti Roll Bar: Steering System: Anti Roll Bar: 2.2mm Black Stock Rack 2.2mm Black 2.5mm Silver Swing Rack 2.5mm Silver 2.8mm Gold Bellcrank Rack 2.8mm Gold 3.0mm Black 3.0mm Black back Bumpsteer...
