:: Front Gearbox :: Front Gearbox Build Build - Bag
Kit Setup:
x2 x2
81520
Arm Mount
Insert, Center
81567
Arm Mount
B
x2 x2
81260
4x14mm
BHCS
:: :: Front Gearbox Front Gearbox Build Build - Bag
81512 x2 x2
Anti-Roll
Bar Link
:: :: Front Gearbox Front Gearbox Build Build - Bag 5.1, 5.2, 5.3
!
Center the anti-roll
bar collet on the anti-
roll bar, then tighten
the 3x3mm set
screw.
!
Front anti-roll
bar gap: 2.0mm
- Bag 5.1, 5.2, 5.3 5.1, 5.2, 5.3 - - Step 3
Droop Screw:
Kit Setup:
81566
Arm Mount
A
81260 x2 x2
4x14mm
BHCS
- Bag 5.1, 5.2, 5.3 5.1, 5.2, 5.3 - - Step 4
81585
Anti-Roll
Bar Pivot
81585
Rod End
Ball
5.1, 5.2, 5.3 - - Step 5
81129
(Front) Anti-Roll
Bar, 2.2mm
!
81585
Anti-Roll
Bar
Center!
Collet
25225
3x3mm
Set Screw
Step 3
!
1.5mm
Start here,
adjust to
101mm
shock length.
81520 x2 x2
Arm Mount
Insert, Center
Step 4
89203
3x16mm
BHCS
Build left and right side!
Suspension
89317
81060 x2 x2
Hinge Droop
Screw
Pin
Note direction
x2 x2
Note direction
x2 x2
81446
Arm Shim
81528
Front Arm,
Lower
!
!
